3 in 1 Portable Air Conditioner
Model No. COL1316
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Parts – Main Unit
Description of Parts – Control Panel
1
2
3
4
5
1. Air Inlet
2. Exhaust (rear)
3. Castors
4. Control Panel 7. Remote Control
5. Air Outlet
6. Tank Drain Cover (bottom rear)
9
11
12
15.Temperature/Time - Button
16.Remote Signal Receiver
17.Mode Button
18.Fan Speed Button
19.Timer Button
6
8. Water Full Indicator
9. Fan Speed Indicators
10. Timer Indicator
11. LED Display
12. Mode Indicators
13. Power ON/OFF Button
14. Temperature/Time + Button
7
13
14
15
16
17
18
19
8
10
