Daewoo COL1319 - Vent Kit Installation; Fitting the Flexible Hose

Vent kit
1.
3.2.
1. Flexible Hose
2. Hose Connector
3. Hose Exit Ring
Fitting the Flexible Hose – the hose must be tted before use
1. First t the hose connector (2) to one end of the hose as follows:
a. Extend one
end of the
exible hose
(1) by about
10cm
b. Screw the hose
connector (2)
onto the end
of the hose in
a clockwise
direction.
c. Extend the
other end of
the exible
hose (1) by
about 10cm
d. Screw the hose
exit ring (3)
onto the other
end of the hose
in a clockwise
direction.
2. Next attached the hose exit ring (3) to the other end of the hose as
follows:
