Daewoo COL1579 - Page 16

16
3 in 1 Portable Air Conditioner with Heating
Model No. COL1579
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Troubleshooting Guide
Problem
Possible Cause
Possible Solution
The unit does not
power up
No power supply
Power on and turn on the unit
Water tank is full
Drain the water tank
Timer function is active
Cancel timer function
Room temperature is too high
(Heating mode)
Reset temperature on unit
Room temperature is too low
(Cooling mode)
Reset temperature on unit
Unit not
performing well
The doors or windows are not
closed
Make sure all the windows and
doors are closed
Filter is dirty
Remove and clean the filter
Air Inlet or Cool Air Louvre is
blocked
Remove any blockage or debris from
the inlet/outlet
Compressor not
working
Overheat protection device has
operated
Check venting then allow the unit to
cool for 5 minutes before restarting
Remote control
not working
Operating distance is too far
Move closer to the unit
Batteries are flat
Replace batteries
Unit is noisy
The unit is located on an uneven
surface
Position the unit on a flat level
surface
E0 Code displayed
Room temperature sensor
failed.
Call after sales service for advice.
E1 Code displayed
Condenser temperature sensor
failed
Call after sales service for advice.
E2 Code displayed
Water tank full
Drain the water tank
E3 Code displayed
Evaporator temperature sensor
failed
Call after sales service for advice.
Technical Specification
Model Number
COL1579
Supply Voltage
220-240V~ 50Hz
Rated Power
Cooling: 1346W
Heating: 1391W
Rated Current
Cooling: 5.9A
Heating: 6.3A
Protection Class
I (This Appliance Must Be Earthed)
Unpacked Weight
33 Kgs (approx.)
Capacity
Cooling: 12000 BTU/h (3500W)
Heating: 9000BTU/h (2638W)
Refrigerant
R290 (226g)
Operating Pressure
Discharge 2.6MPa
Suction 1.0MPa
Maximum Pressure
Discharge 3.2MPa
Suction 1.2MPa
IP Rating
IPX0
Sound Power Level
65dB (A)
