Daewoo Cyclone Freedom - Troubleshooting Guide; Unit Fails to Turn On; Low Suction or Poor Pick-up; Vacuum Making a Hissing Sound

15
Cyclone Freedom 22.2V Cordless Vacuum
Cleaner
FLR00010
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Technical Specification
Troubleshooting Guide
Problem
Possible Cause
Possible Solution
Unit fails to turn on.
Internal battery not
charged.
The charger is not
plugged into the mains
socket.
Charge the internal battery.
Ensure the charger is fully
inserted into the socket and
the socket is switched on.
Low suction or poor pick-up.
Dust Compartment is
full.
Filters are clogged.
Low Power Selected
Empty the cylinder.
Check and clean the filters.
Press the Min/Max Power
Button (8)
The vacuum is making a
“hissing” sound.
The airflow is restricted
Empty the Dust Compartment.
Check and clean the filters.
Clear any blockages if
necessary.
Model Number
FLR00010
Mains Charger
Input: AC 100-240V ~ 50/60Hz Output: 27V DC 500mA
Rated Power
150W
Battery
22.2V 2200mAh Li-Ion (6 cells)
Unpacked Weight (approx.)
2.2 Kgs
Dimensions (approx.)
210mm (l) x 128mm (w) x 290mm (h)
Vacuum (max)
8-11kpa
Noise Level (approx.)
72dB
Dust Compartment Capacity
0.8L
