Daewoo Cyclone Freedom - Using Your Cordless Vacuum Cleaner; Motorised Floor Tool Operation

7
Cyclone Freedom 22.2V Cordless Vacuum
Cleaner
FLR00010
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Using Your Cordless Vacuum Cleaner
The Motorised Floor Tool (13)
3
1. Before using the Motorised Floor Tool
(13) the first choose the appropriate
brush type for the floor type being
cleaned:
Select the Carpet Brush (18) for
vacuum cleaning carpets, rugs, etc.
Select the Hard Floor Brush (19) for
cleaning vinyl, laminate, tiled floors,
etc.
1
2. To change the brush type, slide the
brush retaining catch (a) right on the
underside of the Motorised Floor
Tool (13) as shown left.
The Hard Floor Brush (19) is
currently fitted in this example.
3. Lift out the Hard Floor Brush (19)
from the Motorised Floor Tool (13)
as shown in (b) left.
2
a
.
b.
4. Whilst installing the Carpet Brush (18), ensure that the squared end (c.) of the
brush is towards the retaining catch and is positioned as shown above left.
5. Once in place, slide back the brush retaining catch and insert the Carpet Floor
Brush (18) into the Motorised Floor Tool (13) as shown above right (d.).
c.
d.
4
5
