- Wiggle the blade guard (E) up and down 3-5 times, and then tighten the nuts (A) with the combina-
tion spanner.
Replacing the drive belt
- Loosen the three nuts (A) holding the upper belt guard. Turn the belt tensioner (B) to position "O"
to release the tension.
- Remove the upper belt guard.
- Now remove the rear belt guard.
- Replace the drive belt. Turn the belt tensioner (B) to position "1" to tighten the drive belt.
WARNING! Never start the engine when ! the belt pulley and clutch are removed
for maintenance. Do not start the machine without the cutting arm or cutting
head tted. Otherwise the clutch could come loose and cause personal injuries.
34
