48
Checking the oil level
CAUTION! Never run the engine with no or too little oil.
This could cause severe damage to the engine. Use
only SAE30 engine oil.
Check the oil level
• Position the lawnmower on a straight, level surface.
• Remove the ignition key (12)
• Remove the oil dipstick (20) by turning it to the left, then
wipe off he dipstick.
• Screw in the dipstick up to the limit stop again in the lling
nozzle.
• Pull out the dipstick and read the oil level horizon-tally.
The oil level must be positioned between the max and min
of the oil dipstick (20).
EN
