3.3.24. Water pipe and thermostat
1) Install the water pipe onto the cylinder
head.
2) Install the thermostat in the housing.
3) With socket head bolts, install the ther-
mostat housing onto the water pipe.
- 72 -
EQM3084I
3.3.25. Oil cooler
1) Install the oil cooler onto the oil cooler
cover.
Carefully apply the gasket to prevent oil
leakage.
2) Do not damage the gasket and install
the cover onto the cylinder block.
3) Connect a connection pipe between the
water pump and oil cooler.
EQM3018S
3.3.26. Oil filter
1) With the hollow screw, assemble the oil
pipe connected between the oil cooler
and cylinder block.
2) Install a connection pipe between the
oil cooler and oil filter.
3) Install the oil cooler connecting pipe.
4) Install packing and assemble the oil fil-
ter using a filter assembling wrench.
EQM3018S
3.3.27. Injection pump
1) Install the fuel injection pump bracket in
the cylinder block.
2) After measuring the amount of run-out
with an alignment setting jig, disassem-
ble the bracket, adjust the shims, then
reassemble it.
3) Mount the top/bottom adjusting shims
in the bracket and then mount the fuel
injection pump.
EQM3087I
