17. Electrical Parts List
DHC-X200/X250
DHC-X200 DHC-X250 DHC-X200 DHC-X250
REMARKSLOCATION PART-CODE PART-DESC
MODEL
PART-DESC NO PART-NAMEREMARKS
MODEL
NO PART-NAME LOCATION PART-CODE
175 WIRE JUMPER JW203 W581GY6095 AWG22 1/0.65 SN 6 AUTO O O 262 R CARBON FILM R822 RD-AZ681J- 1/6 680 OHM J O O
176 WIRE JUMPER JW204 W581GY1005 AWG22 1/0.65 SN 10 AUTO O O 263 R CARBON FILM R823~824 RD-AZ223J- 1/6 22K OHM J O O
177 WIRE JUMPER JW205~206 W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO O O 264 R CARBON FILM R825 RD-AZ102J- 1/6 1K OHM J O O
178 WIRE JUMPER JW207 W581GY1505 AWG22 1/0.65 GY 15 AUTO O O 265 R CARBON FILM R827 RD-AZ103J- 1/6 10K OHM J O O
179 WIRE JUMPER JW208 W581GY17J5 AWG22 1/0.65 SN 17.5 AUTO O O 266 R CARBON FILM R828 RD-AZ333J- 1/6 33K OHM J O O
180 WIRE JUMPER JW209 W581GY1505 AWG22 1/0.65 GY 15 AUTO O O 267 R CARBON FILM R829 RD-AZ223J- 1/6 22K OHM J O O
181 WIRE JUMPER JW210~211 W581GY1005 AWG22 1/0.65 SN 10 AUTO O O 268 R CARBON FILM R830 RD-AZ154J- 1/6 150K OHM J O O
182 WIRE JUMPER JW212 W581GY6095 AWG22 1/0.65 SN 6 AUTO O O 269 R CARBON FILM R831 RD-4Z479J- 1/4 4.7 OHM J O O
183 WIRE JUMPER JW213 W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO O O 270 R CARBON FILM R833 RD-4Z479J- 1/4 4.7 OHM J O O
184 WIRE JUMPER JW214 W581GY6095 AWG22 1/0.65 SN 6 AUTO O O 271 R CARBON FILM R834 RD-AZ104J- 1/6 100K OHM J O O
185 WIRE JUMPER JW215 W581GY1005 AWG22 1/0.65 SN 10 AUTO O O 272 R CARBON FILM R835 RD-AZ473J- 1/6 47K OHM J O O
186 WIRE JUMPER JW216 W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO O O 273 R CARBON FILM R836 RD-AZ823J- 1/6 82K OHM J O O
187 WIRE JUMPER JW217~220 W581GY1005 AWG22 1/0.65 SN 10 AUTO O O 274 R CARBON FILM R841~842 RD-AZ102J- 1/6 1K OHM J O O
188 WIRE JUMPER JW221~222 W581GY17J5 AWG22 1/0.65 SN 17.5 AUTO O O 275 R CARBON FILM R843~844 RD-AZ561J- 1/6 560 OHM J O O
189 WIRE JUMPER JW223~224 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO O O 276 R CARBON FILM R845~846 RD-AZ183J- 1/6 18K OHM J O O
190 WIRE JUMPER JW225~228 W581GY1005 AWG22 1/0.65 SN 10 AUTO O O 277 R CARBON FILM R847~850 RD-4Z479J- 1/4 4.7 OHM J O O
191 WIRE JUMPER JW230~233 W581GY1005 AWG22 1/0.65 SN 10 AUTO O O 278 R CARBON FILM R853 RD-AZ102J- 1/6 1K OHM J O O
192 WIRE JUMPER JW234~237 W581GY17J5 AWG22 1/0.65 SN 17.5 AUTO O O 279 R CARBON FILM R855 RD-AZ153J- 1/6 15K OHM J O O
193 WIRE JUMPER JW238 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO O O 280 R CARBON FILM R856 RD-AZ183J- 1/6 18K OHM J O O
194 WIRE JUMPER JW239~240 W581GY17J5 AWG22 1/0.65 SN 17.5 AUTO O O 281 R CARBON FILM R857~858 RD-AZ104J- 1/6 100K OHM J O O
195 WIRE JUMPER JW241 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO O O 282 R CARBON FILM R859 RD-AZ823J- 1/6 82K OHM J O O
196 WIRE JUMPER JW242~245 W581GY1005 AWG22 1/0.65 SN 10 AUTO O O 283 R CARBON FILM R861 RD-AZ102J- 1/6 1K OHM J O O
197 WIRE JUMPER JW247~250 W581GY1005 AWG22 1/0.65 SN 10 AUTO O O 284 R CARBON FILM R862 RD-AZ561J- 1/6 560 OHM J O O
198 WIRE JUMPER JW252 W581GY17J5 AWG22 1/0.65 SN 17.5 AUTO O O 285 R CARBON FILM R863~864 RD-AZ223J- 1/6 22K OHM J O O
199 WIRE JUMPER JW253 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO O O 286 R CARBON FILM R867 RD-AZ103J- 1/6 10K OHM J O O
200 WIRE JUMPER JW254 W581GY1005 AWG22 1/0.65 SN 10 AUTO O O 287 R CARBON FILM R868 RD-AZ333J- 1/6 33K OHM J O O
201 WIRE JUMPER JW255 W581GY6095 AWG22 1/0.65 SN 6 AUTO O O 288 R CARBON FILM R869 RD-AZ223J- 1/6 22K OHM J O O
202 WIRE JUMPER JW256 W581GY1005 AWG22 1/0.65 SN 10 AUTO O O 289 R CARBON FILM R870 RD-AZ154J- 1/6 150K OHM J O O
203 WIRE JUMPER JW258~259 W581GY17J5 AWG22 1/0.65 SN 17.5 AUTO O O 290 R CARBON FILM R871 RD-4Z479J- 1/4 4.7 OHM J O O
204 WIRE JUMPER JW260 W581GY1005 AWG22 1/0.65 SN 10 AUTO O O 291 R CARBON FILM R873 RD-4Z479J- 1/4 4.7 OHM J O O
205 WIRE JUMPER JW261~262 W581GY6095 AWG22 1/0.65 SN 6 AUTO O O 292 R CARBON FILM R874 RD-AZ104J- 1/6 100K OHM J O O
206 WIRE JUMPER JW263~265 W581GY1505 AWG22 1/0.65 GY 15 AUTO O O 293 R CARBON FILM R875 RD-AZ473J- 1/6 47K OHM J O O
207 WIRE JUMPER JW266 W581GY1005 AWG22 1/0.65 SN 10 AUTO O O 294 R CARBON FILM R881 RD-AZ104J- 1/6 100K OHM J O O
208 WIRE JUMPER JW267 W581GY1505 AWG22 1/0.65 GY 15 AUTO O O 295 R CARBON FILM R882~883 RD-AZ473J- 1/6 47K OHM J O O
209 WIRE JUMPER JW268 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO O O 296 R CARBON FILM R901 RD-4Z475J- 1/4 4.7M OHM J O O
210 WIRE JUMPER JW269~270 W581GY1005 AWG22 1/0.65 SN 10 AUTO O O 297 R CARBON FILM R902 RD-AZ221J- 1/6 220 OHM J O O
211 WIRE JUMPER JW271~272 W581GY1505 AWG22 1/0.65 GY 15 AUTO O O 298 R CARBON FILM R903 RD-AZ223J- 1/6 22K OHM J O O
212 WIRE JUMPER JW273~274 W581GY1005 AWG22 1/0.65 SN 10 AUTO O O 299 R CARBON FILM R904 RD-AZ102J- 1/6 1K OHM J O O
213 WIRE JUMPER JW275 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO O O 300 R CARBON FILM R905~910 RD-AZ563J- 1/6 56K OHM J O O
214 WIRE JUMPER JW276 W581GY6095 AWG22 1/0.65 SN 6 AUTO O O 301 R CARBON FILM R911 RD-AZ682J- 1/6 6.8K OHM J O O
215 WIRE JUMPER JW277~278 W581GY1005 AWG22 1/0.65 SN 10 AUTO O O 302 R CARBON FILM R912 RD-AZ103J- 1/6 10K OHM J O O
216 COIL SPRING L801~802 5L00000732 PI10X1.0X7T (R) CW O O 303 R M-OXIDE FILM RM881 RS-4Z473J- 1/4 47K OHM J O O
217 COIL SPRING L821 5L00000732 PI10X1.0X7T (R) CW O O 304 R M-OXIDE FILM RM901~902 RS-4Z109J- 1/4 1 OHM J O O
218 COIL SPRING L841~842 5L00000732 PI10X1.0X7T (R) CW O O 305 R M-OXIDE FILM RM903 RS-4Z680J- 1/4 68 OHM J O O
219 COIL SPRING L861 5L00000732 PI10X1.0X7T (R) CW O O 306 R FUSIBLE RM904~905 RF01Y478J- 1W 0.47 OHM J O O
220 TRANS POWER PT901 5TP8028855 EI=28X12 8.5V 150MA 230V O O 307 R FUSIBLE RM906~907 RF-2F478J- 1/2 0.47 OHM J O O
221 TR Q801~802 TZRC231M-- KRC231M(KEC) O O 308 R M-OXIDE FILM RM908 RS-4Z109J- 1/4 1 OHM J O O
222 TR Q803 TZRC102M-- KRC102M(KEC) O O 309 SW RELAY RY801 5SC0201103 HR-CR323 2C-1P DC12V O O
223 TR Q804 TZRA102M-- KRA102M(KEC) O O 310 SW RELAY RY901 5SC2001A01 SDT-S-105LMR O O
224 TR Q805 TKRC107M-- KRC 107-M (TAPPING) O O 311 SW RELAY RY902 5SC0101370 SDT-S-112LMR O O
225 TR Q821 TZRA102M-- KRA102M(KEC) O O 312 WIRE LEAD W901 WP-ZWH2017 #22 17/0.16 WH 10-200-10 O O
226 TR Q822 TZRC231M-- KRC231M(KEC) O O 1 PCB VIDEO AS 11000 9CDC0604A0 DV-112 O O
227 TR Q823 TZRA102M-- KRA102M(KEC) O O 2 PCB VIDEO B001 9CD6585401 330X247 O O
228 TR Q841~842 TZRC231M-- KRC231M(KEC) O O 3 C CERA CC451 CXCH1H101J 50V CH 100PF J (TAPPING) O O
229 TR Q843 TZRC102M-- KRC102M(KEC) O O 4 C CERA CC452~453 CCXF1H103Z 50V F 0.01MF Z (TAPPING) O O
230 TR Q844 TZRA102M-- KRA102M(KEC) O O 5 C CERA CC454 CCXF1H473Z 50V F 0.047MF Z (TAPPING) O O
231 TR Q862 TZRA102M-- KRA102M(KEC) O O 6 C ELECTRO CE451~453 CEXF1E470V 25V RSS 47MF (5X11) TP O O
232 TR Q881~882 TZTC3199Y- KTC-3199Y TAPING O O 7 C ELECTRO CE454~455 CEYF1C471V 16V RSS 470MF 10X12.5 O O
233 TR Q883 TZTA1266Y- KTA1266Y- (AUTO)(1015Y) O O 8 C ELECTRO CE456 CEXF1E101V 25V RSS 100MF (6.3X11) TP O O
234 TR Q901 TKRC107M-- KRC 107-M (TAPPING) O O 9 CONN AS CN451 9728810301 #26 1007 11P 600MM O O
235 TR Q903 TZTA1024Y- KTA1024Y (949Y) O O 10 CONN WAFER CW451 9728808600 2.0MM PH-6AW 6P O O
236 TR Q904 TKRC107M-- KRC 107-M (TAPPING) O O 11 DIODE D451~455 DZN4148--- 1N4148 AUTO 52MM O O
237 R CARBON FILM R401~402 RD-AZ471J- 1/6 470 OHM J O O 12 IC SWITCH IC451 1LA7952--- LA7952 O O
238 R CARBON FILM R403~404 RD-AZ104J- 1/6 100K OHM J O O 13 JACK RCA J451 9736323700 JE0200596N O O
239 R CARBON FILM R405~406 RD-AZ471J- 1/6 470 OHM J O O 14 JACK S VIDEO J452 9736324000 C50160272N O O
240 R CARBON FILM R407~408 RD-AZ104J- 1/6 100K OHM J O O 15 JACK RCA J453 9736323800 JE0301645N O O
241 R CARBON FILM R409~410 RD-AZ471J- 1/6 470 OHM J O O 16 JACK RCA J454 9736323900 JE0301645G O O
242 R CARBON FILM R411~412 RD-AZ104J- 1/6 100K OHM J O O 17 WIRE JUMPER JW401 W581GY1505 AWG22 1/0.65 GY 15 AUTO O O
243 R CARBON FILM R413~414 RD-AZ471J- 1/6 470 OHM J O O 18 WIRE JUMPER JW402~404 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO O O
244 R CARBON FILM R415~416 RD-AZ104J- 1/6 100K OHM J O O 19 WIRE JUMPER JW405 W581GY1505 AWG22 1/0.65 GY 15 AUTO O O
245 R CARBON FILM R417~418 RD-AZ471J- 1/6 470 OHM J O O 20 WIRE JUMPER JW406~407 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO O O
246 R CARBON FILM R419~420 RD-AZ104J- 1/6 100K OHM J O O 21 WIRE JUMPER JW408 W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO O O
247 R CARBON FILM R421~422 RD-AZ471J- 1/6 470 OHM J O O 22 WIRE JUMPER JW409 W581GY1005 AWG22 1/0.65 SN 10 AUTO O O
248 R CARBON FILM R423~428 RD-AZ104J- 1/6 100K OHM J O O 23 WIRE JUMPER JW410~411 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO O O
249 R CARBON FILM R429~432 RD-AZ101J- 1/6 100 OHM J O O 24 WIRE JUMPER JW412 W581GY1505 AWG22 1/0.65 GY 15 AUTO O O
250 R CARBON FILM R433~434 RD-AZ104J- 1/6 100K OHM J O O 25 TR Q451~452 TZTC3199Y- KTC-3199Y TAPING O O
251 R CARBON FILM R435~439 RD-AZ101J- 1/6 100 OHM J O O 26 TR Q453~454 TKRC107M-- KRC 107-M (TAPPING) O O
252 R CARBON FILM R801~802 RD-AZ102J- 1/6 1K OHM J O O 27 R CARBON FILM R451 RD-AZ104J- 1/6 100K OHM J O O
253 R CARBON FILM R803~804 RD-AZ561J- 1/6 560 OHM J O O 28 R CARBON FILM R452 RD-AZ221J- 1/6 220 OHM J O O
254 R CARBON FILM R805~806 RD-AZ183J- 1/6 18K OHM J O O 29 R CARBON FILM R453~455 RD-AZ750J- 1/6 75 OHM J O O
255 R CARBON FILM R807~810 RD-4Z479J- 1/4 4.7 OHM J O O 30 R CARBON FILM R456 RD-AZ680J- 1/6 68 OHM J O O
256 R CARBON FILM R813~814 RD-4Z151J- 1/4 150 OHM J O O 31 R CARBON FILM R457 RD-AZ473J- 1/6 47K OHM J O O
257 R CARBON FILM R816 RD-AZ102J- 1/6 1K OHM J O O 32 R CARBON FILM R458 RD-AZ391J- 1/6 390 OHM J O O
258 R CARBON FILM R817 RD-AZ153J- 1/6 15K OHM J O O 33 R CARBON FILM R459 RD-AZ680J- 1/6 68 OHM J O O
259 R CARBON FILM R818~819 RD-AZ104J- 1/6 100K OHM J O O 34 R CARBON FILM R460 RD-AZ473J- 1/6 47K OHM J O O
260 R CARBON FILM R820 RD-AZ183J- 1/6 18K OHM J O O 35 R CARBON FILM R461 RD-AZ391J- 1/6 390 OHM J O O
261 R CARBON FILM R821 RD-AZ102J- 1/6 1K OHM J O O 36 R CARBON FILM R462 RD-AZ473J- 1/6 47K OHM J O O
54
