17. Electrical Parts List
DHC-X200/X250
DHC-X200 DHC-X250 DHC-X200 DHC-X250
REMARKSLOCATION PART-CODE PART-DESC
MODEL
PART-DESC NO PART-NAMEREMARKS
MODEL
NO PART-NAME LOCATION PART-CODE
37 R CARBON FILM R463 RD-AZ333J- 1/6 33K OHM J O O 77 C ELECTRO C590 CEXF1H100E 50V RM 10MF (5X11) TP O O
1 PCB REG AS 12000 9CDC0604B0 DV-112 O O 78 C ELECTRO C591 CEXF1V470E 35V RM 47MF (5X11) TP O O
2 PCB REG B001 9CD6585402 330X247 O O 79 C ELECTRO C592 CEXF1H109E 50V RM 1MF (5X11) TP O O
3 C CERA CC931~931 CCXF1H104Z 50V F 0.1MF Z O O 80 C ELECTRO C593L/R~594L/R CEXF1H479E 50V RM 4.7MF (5X11) TP O O
4 C ELECTRO CE931~932 CEXF1H100V 50V RSS 10MF (5X11) TP O O 81 C ELECTRO C595 CEXF1H109E 50V RM 1MF (5X11) TP O O
5 CONN WAFER CW931 9728808701 8P 2MM O O 82 C ELECTRO C596A/B/C/L/R/W CEXF1H479E 50V RM 4.7MF (5X11) TP O O
6 IC REGULATOR IC931~932 1K1A7805AP K1A7805AP O O 83 C ELECTRO C597~598 CEXF1H479E 50V RM 4.7MF (5X11) TP O O
7 WIRE JUMPER JW301~302 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO O O 84 C CHIP CERA C599 HCBK822KBA 50V X7R 8200PF K 1608 O O
8 WIRE JUMPER JW303 W581GY1005 AWG22 1/0.65 SN 10 AUTO O O 85 C ELECTRO C600 CEXF1H338E 5V RM 0.33MF (5X11) TP O O
9 TR Q931~932 TZTA1049Y- A1049Y O O 86 C CHIP CERA C601 HCBK153KBA 50V X7R 0.015MF K 1608 O O
10 R M-OXIDE FILM RM931~932 RS-4Z100J- 1/4 10 OHM J O O 87 C CHIP CERA C602~606 HCQK101JBA 50V CH 100PF J 1608 O O
1 PCB DSP AS 13000 9CDC059000 DV-115 O O 88 C ELECTRO C607 CEXF1H338E 5V RM 0.33MF (5X11) TP O O
2 PCB DSP B001 9CD6583900 170X260 O O 89 C CHIP CERA C608 HCBK153KBA 50V X7R 0.015MF K 1608 O O
3 C ELECTRO C501 CEXF1E470E 25V RM 47MF (5X11) O O 90 C ELECTRO C609~610 CEXF1H339E 50V RM 3.3MF (5X11) TP O O
4 C CHIP CERA C502 HCBK104KBA 50V X7R 0.1MF K 1608 O O 91 C CHIP CERA C612 HCBK822KBA 50V X7R 8200PF K 1608 O O
5 C CHIP CERA C503 HCQK220JBA 50V CH 22PF J 1608 O O 92 C ELECTRO C613 CEXF1H100E 50V RM 10MF (5X11) TP O O
6 C ELECTRO C504 CEXF1E470E 25V RM 47MF (5X11) O O 93 C ELECTRO C614 CEXF1H108E 50V RM 0.1MF (5X11) TP O O
7 C CHIP CERA C505 HCBK104KBA 50V X7R 0.1MF K 1608 O O 94 C CHIP CERA C615~616 HCQK681JBA 50V CH 680PF J 1608 O O
8 C CHIP CERA C506 HCQK220JBA 50V CH 22PF J 1608 O O 95 C ELECTRO C617~618 CEXF1E101E 25V RM 100MF (6.3X11) TP O O
9 C CHIP CERA C507 HCBK104KBA 50V X7R 0.1MF K 1608 O O 96 C CHIP CERA C619L/R HCQK101JBA 50V CH 100PF J 1608 O O
10 C CHIP CERA C508~509 HCQK220JBA 50V CH 22PF J 1608 O O 97 C CHIP CERA C621~624 HCQK681JBA 50V CH 680PF J 1608 O O
11 C ELECTRO C510 CEXF1H108E 50V RM 0.1MF (5X11) TP O O 98 C ELECTRO C625~626 CEXF1E101E 25V RM 100MF (6.3X11) TP O O
12 C CHIP CERA C511~512 HCBK104KBA 50V X7R 0.1MF K 1608 O O 99 C CHIP CERA C627~632 HCQK681JBA 50V CH 680PF J 1608 O O
13 C ELECTRO C513~514 CEXF1E470E 25V RM 47MF (5X11) O O 100 C CHIP CERA C633A/B/C/L/R/W HCQK101JBA 50V CH 100PF J 1608 O O
14 C CHIP CERA C513L/R HCQK222JBA 50V CH 2200PF J 1608 O O 101 C ELECTRO C634A/B/L/R CEXF1H100E 50V RM 10MF (5X11) TP O O
15 C ELECTRO C514L/R CEXF1E101E 25V RM 100MF (6.3X11) TP O O 102 C ELECTRO C634C/W CEXF1H479E 50V RM 4.7MF (5X11) TP O O
16 C CHIP CERA C515~517 HCBK104KBA 50V X7R 0.1MF K 1608 O O 103 C CHIP CERA C635A/B/C/L/R/W HCQK681JBA 50V CH 680PF J 1608 O O
17 C ELECTRO C518 CEXF1E470E 25V RM 47MF (5X11) O O 104 C CHIP CERA C636A/B/C/L/R/W HCQK820JBA 50V CH 82PF J 1608 O O
18 C CHIP CERA C518L/R HCBK104KBA 50V X7R 0.1MF K 1608 O O 105 C ELECTRO C638W CEXF1H479E 50V RM 4.7MF (5X11) TP O O
19 C CHIP CERA C519 HCBK104KBA 50V X7R 0.1MF K 1608 O O 106 C ELECTRO C639A/B/C/L/R CEXF1H479E 50V RM 4.7MF (5X11) TP O O
20 C ELECTRO C520 CEXF1E470E 25V RM 47MF (5X11) O O 107 CONN WAFER CN501 9CD6264300 52045-1145 O O
21 C CHIP CERA C521 HCBK104KBA 50V X7R 0.1MF K 1608 O O 108 CONN WAFER CN502 9728809000 2.0MM 35237-1101 11P O O
22 C CHIP CERA C522~523 HCQK270JBA 50V CH 27PF J 1608 O O 109 CONN WAFER CN503 9728809100 2.0MM 35237-1801 18P O O
23 C ELECTRO C525 CEXF1H100E 50V RM 10MF (5X11) TP O O 110 CONN WAFER CN504 9728811700 2.0MM PH-3A 3P O O
24 C ELECTRO C526 CEXF1E470E 25V RM 47MF (5X11) O O 111 CONN WAFER CN505 9728810900 2.0MM PH-5A 5P O O
25 C CHIP CERA C527 HCBK104KBA 50V X7R 0.1MF K 1608 O O 112 DIODE SW CHIP D501 DZDS160--- KDS160 O O
26 C ELECTRO C528 CEXF1E470E 25V RM 47MF (5X11) O O 113 DIODE SW CHIP D502 DZDS160--- KDS160 O O
27 C CHIP CERA C529 HCBK104KBA 50V X7R 0.1MF K 1608 O O 114 DIODE SW CHIP D505 DZDS160--- KDS160 O O
28 C CHIP CERA C530 HCFK224ZCA Y5V 50V 0.22MF Z 2012 O O 115 DIODE SW CHIP D506 DZDS160--- KDS160 O O
29 C ELECTRO C531 CEXF1H229E 50V RM 2.2MF (5X11) TP O O 116 DIODE SW CHIP D507 DZDS160--- KDS160 O O
30 C ELECTRO C532 CEXF1E470E 25V RM 47MF (5X11) O O 117 DIODE SW CHIP D509 DZDS160--- KDS160 O O
31 C CHIP CERA C533 HCBK104KBA 50V X7R 0.1MF K 1608 O O 118 DIODE ZENER DZ501~502 DZTZ7R5B-- MTZ 7.5B O O
32 C CHIP CERA C534 HCBK102KBA 50V X7R 1000PF K 1608 O O 119 IC IC501 1T0RX178B- T0RX178B (OPTICAL RX) O O
33 C ELECTRO C535 CEXF1H109E 50V RM 1MF (5X11) TP O O 120 IC IC502 1T0TX178A- T0TX178A (OPTICAL TX) O O
34 C ELECTRO C536 CEXF1H100E 50V RM 10MF (5X11) TP O O 121 IC IC503 174HCU04-- 74HCU04 (INVERTER) O O
35 C CHIP CERA C537 HCBK104KBA 50V X7R 0.1MF K 1608 O O 122 IC IC504 1AK4112A-- AK4112A (DIR) O O
36 C ELECTRO C538 CEXF1H100E 50V RM 10MF (5X11) TP O O 123 IC REGULATOR IC505 1AME1117BG AME1117BCGT (SOT-223) O O
37 C CHIP CERA C539~540 HCBK104KBA 50V X7R 0.1MF K 1608 O O 124 IC IC506 1CS49326-- CS49326 (DD DECODER) O O
38 C ELECTRO C541 CEXF1H229V 50V RSS 2.2MF (5X11) TP O O 125 IC IC507 174HC244-- 74HC244 (BUS DRIVER) O O
39 C CHIP CERA C542 HCBK104KBA 50V X7R 0.1MF K 1608 O O 126 IC IC508 1CS4228A-- CS4228A (CODEC) O O
40 C ELECTRO C543 CEXF1H100E 50V RM 10MF (5X11) TP O O 127 IC REGULATOR IC509 1AME1117CC AME1117CCCT (TO-252) O O
41 C CHIP CERA C544 HCBK104KBA 50V X7R 0.1MF K 1608 O O 128 IC IC510 1CS4341--- CS4341 (DAC) O O
42 C ELECTRO C545 CEXF1E470E 25V RM 47MF (5X11) O O 129 IC CHIP IC511~512 1NJM4558M- NJM4558M O O
43 C ELECTRO C546L/R~547L/R CEXF1H100E 50V RM 10MF (5X11) TP O O 130 IC IC516~518 1NJM2068-- NJM2068 (OP AMP) O O
44 C ELECTRO C547 CEXF1H109E 50V RM 1MF (5X11) TP O O 131 IC CHIP IC519~520 1NJM4558M- NJM4558M O O
45 C CHIP CERA C548~549 HCBK104KBA 50V X7R 0.1MF K 1608 O O 132 IC IC521 1BU4052BCF BU4052 O O
46 C CHIP CERA C548L/R HCQK101JBA 50V CH 100PF J 1608 O O 133 IC CHIP IC523 1NJM4558M- NJM4558M O O
47 C CHIP CERA C549L/R~55OL/r HCQK681JBA 50V CH 680PF J 1608 O O 134 IC IC524 1M62446FP- M62446FP O O
48 C ELECTRO C550 CEXF1H109E 50V RM 1MF (5X11) TP O O 135 IC CHIP IC525~527 1NJM4558M- NJM4558M O O
49 C CHIP CERA C552 HCQK101JBA 50V CH 100PF J 1608 O O 136 JACK RCA JA501 9736324100 JK010055HN O O
50 C ELECTRO C552L/R CEXF1H339E 50V RM 3.3MF (5X11) TP O O 137 COIL CHIP L501~502 HLC479J03A 4.7UH CHIP 2012 O O
51 C CHIP CERA C553 HCQK681JBA 50V CH 680PF J 1608 O O 138 COIL CHIP L503 HLC229J02A 2.2UH CHIP 1608 O O
52 C ELECTRO C554 CEXF1E101E 25V RM 100MF (6.3X11) TP O O 139 COIL CHIP L504 HLC104J01A BEAD 120 OHM 100MHZ 2012 O O
53 C CHIP CERA C555 HCQK681JBA 50V CH 680PF J 1608 O O 140 COIL CHIP L505 HLC479J03A 4.7UH CHIP 2012 O O
54 C ELECTRO C556 CEXF1E101E 25V RM 100MF (6.3X11) TP O O 141 COIL CHIP L506~507 HLC104J01A BEAD 120 OHM 100MHZ 2012 O O
55 C CHIP CERA C557~562 HCQK681JBA 50V CH 680PF J 1608 O O 142 COIL CHIP L508L/R HLC104J01A BEAD 120 OHM 100MHZ 2012 O O
56 C ELECTRO C563 CEXF1H100E 50V RM 10MF (5X11) TP O O 143 R CHIP L509L/R HRFT000-BA 1/10 0 OHM 1608 O O
57 C CHIP CERA C564 HCBK104KBA 50V X7R 0.1MF K 1608 O O 144 COIL CHIP L510A/B/C/L/R/W HLC104J01A BEAD 120 OHM 100MHZ 2012 O O
58 C ELECTRO C565 CEXF1H100E 50V RM 10MF (5X11) TP O O 145 COIL CHIP L511~512 HLC104J01A BEAD 120 OHM 100MHZ 2012 O O
59 C ELECTRO C566 CEXF1H109E 50V RM 1MF (5X11) TP O O 146 TR CHIP Q502 TZRA102S-- KRA102S (10X10)PNP O O
60 C ELECTRO C566L/R CEXF1H100E 50V RM 10MF (5X11) TP O O 147 TR CHIP Q503L/R TZRC231S-- KRC231S O O
61 C CHIP CERA C567 HCBK104KBA 50V X7R 0.1MF K 1608 O O 148 TR CHIP Q505 TZRA102S-- KRA102S (10X10)PNP O O
62 C ELECTRO C570L/R~571L/R CEXF1H100E 50V RM 10MF (5X11) TP O O 149 TR CHIP Q506 TZRC102S-- KRC102S O O
63 C CHIP CERA C572L/R HCBK102KBA 50V X7R 1000PF K 1608 O O 150 TR CHIP Q507A/B/C/L/R/W TZRC231S-- KRC231S O O
64 C ELECTRO C578 CEXF1H100E 50V RM 10MF (5X11) TP O O 151 TR FET Q508L/R T2SK117--- 2SK117 O O
65 C ELECTRO C579A/B/C/L/R/W CEXF1H100E 50V RM 10MF (5X11) TP O O 152 TR CHIP Q509 TZRA102S-- KRA102S (10X10)PNP O O
66 C CHIP CERA C580A/B/C/L/R/W HCQK471JBA 50V CH 470PF J 1608 O O 153 TR CHIP Q510 TZRC102S-- KRC102S O O
67 C CHIP CERA C581A/B/C/L/R/W HCQK471JBA 50V CH 470PF J 1608 O O 154 TR CHIP Q511 TZRA102S-- KRA102S (10X10)PNP O O
68 C ELECTRO C582A/B/C/L/R/W CEXF1H100E 50V RM 10MF (5X11) TP O O 155 TR CHIP Q512~513 TZRC231S-- KRC231S O O
69 C CHIP CERA C583A/B/C/L/R/W HCBK332KBA 50V X7R 3300PF K 1608 O O 156 R CHIP R501 HRFT472JBA 1/10 4.7K OHM J 1608 O O
70 C CHIP CERA C584L/R/W HCQK101JBA 50V CH 100PF J 1608 O O 157 R CHIP R503 HRFT221JBA 1/10 220 OHM J 1608 O O
71 C CHIP CERA C585L/R HCQK330JBA 50V CH 33PF J 1608 O O 158 R CHIP R504 HRFT750JBA 1/10 75 OHM J 1608 O O
72 C CHIP CERA C585W HCQK470JBA 50V CH 47PF J 1608 O O 159 R CHIP R505 HRFT101JBA 1/10 100 OHM J 1608 O O
73 C ELECTRO C586L/R/W CEXF1H100E 50V RM 10MF (5X11) TP O O 160 R CHIP R506 HRFT222JBA 1/10 2.2K OHM J 1608 O O
74 C CHIP CERA C587 HCQK681JBA 50V CH 680PF J 1608 O O 161 R CHIP R507 HRFT103JBA 1/10 10K OHM J 1608 O O
75 C ELECTRO C588 CEXF1H100E 50V RM 10MF (5X11) TP O O 162 R CHIP R508 HRFT104JBA 1/10 100K OHM J 1608 O O
76 C CHIP CERA C589 HCQK681JBA 50V CH 680PF J 1608 O O 163 R CHIP R509~513 HRFT220JBA 1/10W 22 OHM J 1608 O O
