17. Electrical Parts List
DHC-X200/X250
DHC-X200 DHC-X250 DHC-X200 DHC-X250
REMARKSLOCATION PART-CODE PART-DESC
MODEL
PART-DESC NO PART-NAMEREMARKS
MODEL
NO PART-NAME LOCATION PART-CODE
164 R CHIP R514 HRFT105JBA 1/10 1M OHM J 1608 O O 250 R CHIP R620~627 HRFT103JBA 1/10 10K OHM J 1608 O O
165 R CHIP R515 HRFT104JBA 1/10 100K OHM J 1608 O O 251 X-TAL X501 5XE12R288J 12.288MHZ HC-49U O O
166 R CHIP R516 HRFT220JBA 1/10W 22 OHM J 1608 O O 1 PCB MPEG AS 14000 9CDC059100 DV-115 O O
167 R CHIP R517 HRFT103JBA 1/10 10K OHM J 1608 O O 2 PCB MPEG B001 9CD6584000 91X147 O O
168 R CHIP R518 HRFT102JBA 1/10 1K OHM J 1608 O O 3 COIL BEAD BD401~406 58C0000116 HC-3550R O O
169 R CHIP R519~522 HRFT220JBA 1/10W 22 OHM J 1608 O O 4 C CHIP CERA C401 HCBK104KBA 50V X7R 0.1MF K 1608 O O
170 R CHIP R524 HRFT332JBA 1/10 3.3K OHM J 1608 O O 5 C CHIP CERA C402~403 HCQK220JBA 50V CH 22PF J 1608 O O
171 R CHIP R525 HRFT470JBA 1/10 47 OHM J 1608 O O 6 C CHIP CERA C404 HCBK104KBA 50V X7R 0.1MF K 1608 O O
172 R CHIP R526~528 HRFT472JBA 1/10 4.7K OHM J 1608 O O 7 C ELECTRO C405 CEXF1E101E 25V RM 100MF (6.3X11) TP O O
173 R CHIP R529 HRFT103JBA 1/10 10K OHM J 1608 O O 8 C CHIP CERA C406~407 HCBK104KBA 50V X7R 0.1MF K 1608 O O
174 R CHIP R531 HRFT472JBA 1/10 4.7K OHM J 1608 O O 9 C ELECTRO C408 CEXF1H100E 50V RM 10MF (5X11) TP O O
175 R CHIP R532 HRFT103JBA 1/10 10K OHM J 1608 O O 10 C CHIP CERA C409 HCBK105KBA 50V X7R 1MF K 1608 O O
176 R CHIP R533 HRFT122JBA 1/10 1.2K OHM J 1608 O O 11 C CHIP CERA C410~412 HCBK104KBA 50V X7R 0.1MF K 1608 O O
177 R CHIP R534 HRFT332JBA 1/10 3.3K OHM J 1608 O O 12 C ELECTRO C413 CEXF1E101E 25V RM 100MF (6.3X11) TP O O
178 R CHIP R535 HRFT103JBA 1/10 10K OHM J 1608 O O 13 C CHIP CERA C414 HCBK104KBA 50V X7R 0.1MF K 1608 O O
179 R CHIP R536~537 HRFT220JBA 1/10W 22 OHM J 1608 O O 14 C ELECTRO C415 CEXF1E101E 25V RM 100MF (6.3X11) TP O O
180 R CHIP R538 HRFT103JBA 1/10 10K OHM J 1608 O O 15 C CHIP CERA C416 HCBK102KBA 50V X7R 1000PF K 1608 O O
181 R CHIP R539 HRFT470JBA 1/10 47 OHM J 1608 O O 16 C CHIP CERA C417 HCBK473KBA 50V X7R 0.047MF K 1608 O O
182 R CHIP R540 HRFT103JBA 1/10 10K OHM J 1608 O O 17 C CHIP CERA C418 HCQK330JBA 50V CH 33PF J 1608 O O
183 R CHIP R541 HRFT223JBA 1/10 22K OHM J 1608 O O 18 C CHIP CERA C419 HCBK104KBA 50V X7R 0.1MF K 1608 O O
184 R CHIP R542L/R HRFT151JBA 1/10 150 OHM J 1608 O O 19 C CHIP CERA C420 HCQK330JBA 50V CH 33PF J 1608 O O
185 R CHIP R543L/R HRFT103JBA 1/10 10K OHM J 1608 O O 20 C CHIP CERA C421~423 HCBK104KBA 50V X7R 0.1MF K 1608 O O
186 R CHIP R544L/R HRFT472JBA 1/10 4.7K OHM J 1608 O O 21 C ELECTRO C424 CEXF1E101E 25V RM 100MF (6.3X11) TP O O
187 R CHIP R545L/R HRFT561JBA 1/10 560 OHM J 1608 O O 22 C CHIP CERA C425~429 HCBK104KBA 50V X7R 0.1MF K 1608 O O
188 R CHIP R546L/R HRFT472JBA 1/10 4.7K OHM J 1608 O O 23 C ELECTRO C430 CEXF1E101E 25V RM 100MF (6.3X11) TP O O
189 R CHIP R548L/R HRFT102JBA 1/10 1K OHM J 1608 O O 24 C CHIP CERA C431~434 HCBK104KBA 50V X7R 0.1MF K 1608 O O
190 R CHIP R549L/R HRFT104JBA 1/10 100K OHM J 1608 O O 25 C CHIP CERA C437~441 HCQK150JBA 50V CH 15PF J 1608 O O
191 R CHIP R550L/R HRFT102JBA 1/10 1K OHM J 1608 O O 26 C CHIP CERA C442 HCBK104KBA 50V X7R 0.1MF K 1608 O O
192 R CHIP R555L/R HRFT473JBA 1/10 47K OHM J 1608 O O 27 C ELECTRO C443 CEXF1E101E 25V RM 100MF (6.3X11) TP O O
193 R CHIP R556L/R HRFT472JBA 1/10 4.7K OHM J 1608 O O 28 C CHIP CERA C444~446 HCBK104KBA 50V X7R 0.1MF K 1608 O O
194 R CHIP R557L/R HRFT471JBA 1/10 470 OHM J 1608 O O 29 C CHIP CERA C447~458 HCQK150JBA 50V CH 15PF J 1608 O O
195 R CHIP R561 HRFT474JBA 1/10 470K OHM J 1608 O O 30 C ELECTRO C459 CEXF1E101E 25V RM 100MF (6.3X11) TP O O
196 R CHIP R562 HRFT472JBA 1/10 4.7K OHM J 1608 O O 31 C CHIP CERA C460~461 HCBK104KBA 50V X7R 0.1MF K 1608 O O
197 R CHIP
R563A/B/C/L/R/W
~566A/B/C/L/R/W
HRFT472JBA 1/10 4.7K OHM J 1608 O O 32 C ELECTRO C462 CEXF1E101E 25V RM 100MF (6.3X11) TP O O
198 R CHIP R566A//B/C/L/R/W HRFT472JBA 1/10 4.7K OHM J 1608 O O 33 C CHIP CERA C467 HCQK221JBA 50V CH 220PF J 1608 O O
199 R CHIP R567A/B/C/L/R/W HRFT102JBA 1/10 1K OHM J 1608 O O 34 C CHIP CERA C468 HCQK330JBA 50V CH 33PF J 1608 O O
200 R CHIP R568A/B/C/L/R/W HRFT104JBA 1/10 100K OHM J 1608 O O 35 C CHIP CERA C469 HCQK221JBA 50V CH 220PF J 1608 O O
201 R CHIP R569A/B/C/L/R/W HRFT102JBA 1/10 1K OHM J 1608 O O 36 CLECTRO C470 CEXF1C221E RM 16V 220MF 6.3X11 TAT O O
202 R CHIP R570L/R/W HRFT392JBA 1/10 3.9K OHM J 1608 O O 37 C CHIP CERA C473 HCBK104KBA 50V X7R 0.1MF K 1608 O O
203 R CHIP R571L/R HRFT472JBA 1/10 4.7K OHM J 1608 O O 38 C ELECTRO C474 CEXF1E101E 25V RM 100MF (6.3X11) TP O O
204 R CHIP R571W HRFT682JBA 1/10 6.8K OHM J 1608 O O 39 C CHIP CERA C475~477 HCBK104KBA 50V X7R 0.1MF K 1608 O O
205 R CHIP R572LR~573L/R HRFT153JBA 1/10 15K OHM J 1608 O O 40 C ELECTRO C478 CEXF1E101E 25V RM 100MF (6.3X11) TP O O
206 R CHIP R572W HRFT562JBA 1/10 5.6K OHM J 1608 O O 41 C CHIP CERA C479 HCQK221JBA 50V CH 220PF J 1608 O O
207 R CHIP R573W HRFT822JBA 1/10 8.2K OHM J 1608 O O 42 C CHIP CERA C480 HCQK330JBA 50V CH 33PF J 1608 O O
208 R CHIP R574L/R/W HRFT101JBA 1/10 100 OHM J 1608 O O 43 C CHIP CERA C481 HCQK221JBA 50V CH 220PF J 1608 O O
209 R CHIP R575~576 HRFT332JBA 1/10 3.3K OHM J 1608 O O 44 CLECTRO C482 CEXF1C221E RM 16V 220MF 6.3X11 TAT O O
210 R CHIP R577L/R HRFT622JBA 1/10 6.2K OHM J 1608 O O 45 C CHIP CERA C483 HCQK221JBA 50V CH 220PF J 1608 O O
211 R CHIP R578 HRFT103JBA 1/10 10K OHM J 1608 O O 46 C CHIP CERA C484 HCQK330JBA 50V CH 33PF J 1608 O O
212 R CHIP R578L/R HRFT104JBA 1/10 100K OHM J 1608 O O 47 C CHIP CERA C485 HCQK221JBA 50V CH 220PF J 1608 O O
213 R CHIP R579 HRFT222JBA 1/10 2.2K OHM J 1608 O O 48 CLECTRO C486 CEXF1C221E RM 16V 220MF 6.3X11 TAT O O
214 R CHIP R580L/R HRFT472JBA 1/10 4.7K OHM J 1608 O O 49 C CHIP CERA C487 HCQK221JBA 50V CH 220PF J 1608 O O
215 R CHIP R581 HRFT473JBA 1/10 47K OHM J 1608 O O 50 C CHIP CERA C488 HCQK330JBA 50V CH 33PF J 1608 O O
216 R CHIP R582L/R HRFT104JBA 1/10 100K OHM J 1608 O O 51 C CHIP CERA C489 HCQK221JBA 50V CH 220PF J 1608 O O
217 R CHIP R583L/R HRFT000-BA 1/10 0 OHM 1608 O O 52 CLECTRO C490 CEXF1C221E RM 16V 220MF 6.3X11 TAT O O
218 R CHIP R584L/R~585L/R HRFT472JBA 1/10 4.7K OHM J 1608 O O 53 C CHIP CERA C491 HCQK221JBA 50V CH 220PF J 1608 O O
219 R CHIP R586L/R HRFT104JBA 1/10 100K OHM J 1608 O O 54 C CHIP CERA C492 HCQK330JBA 50V CH 33PF J 1608 O O
220 R CHIP R587A/B/C/L/R/W HRFT000-BA 1/10 0 OHM 1608 O O 55 C CHIP CERA C493 HCQK221JBA 50V CH 220PF J 1608 O O
221 R CHIP R588 HRFT104JBA 1/10 100K OHM J 1608 O O 56 CLECTRO C494 CEXF1C221E RM 16V 220MF 6.3X11 TAT O O
222 R METAL FILM R589 RN-4Z221J- 1/4W 220 OHM J O O 57 C CHIP CERA C495 HCQK221JBA 50V CH 220PF J 1608 O O
223 R CHIP R590 HRFT751JBA 1/10 750 OHM J 1608 O O 58 C CHIP CERA C496 HCQK330JBA 50V CH 33PF J 1608 O O
224 R CHIP R591~593 HRFT101JBA 1/10 100 OHM J 1608 O O 59 C CHIP CERA C497 HCQK221JBA 50V CH 220PF J 1608 O O
225 R CHIP R594 HRFT152JBA 1/10 1.5K OHM J 1608 O O 60 CLECTRO C498 CEXF1C221E RM 16V 220MF 6.3X11 TAT O O
226 R CHIP R595L/R HRFT101JBA 1/10 100 OHM J 1608 O O 61 IC MICOM IC401 1C1610---- C1610 O O
227 R CHIP R596A/B/C/L/R/W HRFT224JBA 1/10 220K OHM J 1608 O O 62 IC DECODER IC402 1ZR36710-- ZR36710 DFP O O
228 R METAL FILM R597 RN-4Z221J- 1/4W 220 OHM J O O 63 IC SDRAM IC403 1HY57V1616 HY57V1616 O O
229 R CHIP R598 HRFT103JBA 1/10 10K OHM J 1608 O O 64 IC ROM IC404~405 1A290021L- A290021L O O
230 R CHIP R598A/B/C/L/R/W HRFT104JBA 1/10 100K OHM J 1608 O O 65 IC SRAM IC406 11S61C1024 IS61C1024/L O O
231 R CHIP R599 HRFT102JBA 1/10 1K OHM J 1608 O O 66 IC EEPROM IC407 1XC24C02-- XC24C02 O O
232 R CHIP R599L/R HRFT104JBA 1/10 100K OHM J 1608 O O 67 IC RESET IC408 1K1A7039AF KIA7039AF O O
233 R CHIP R600 HRFT474JBA 1/10 470K OHM J 1608 O O 68 IC ATAPI I/F IC409 1ZR36701-- ZR36701P O O
234 R CHIP R601~602 HRFT332JBA 1/10 3.3K OHM J 1608 O O 69 IC VIDEO ENCODER IC410 1CS4955--- CS4955 O O
235 R CHIP R601A/B/C/L/R/W HRFT101JBA 1/10 100 OHM J 1608 O O 70 IC REGULATOR IC411 1AME1117CC AME1117CCCT (TO-252) O O
236 R CHIP R602A/B/C/L/R/W HRFT473JBA 1/10 47K OHM J 1608 O O 71 JACK ATAPI JK401 9736324700 40P ATAPI O O
237 R CHIP R603A/B/C/L/R HRFT562JBA 1/10 5.6K OHM J 1608 O O 72 COIL CHIP L401 HLC279J03A 2.7UH CHIP 3216 O O
238 R CHIP R603W HRFT103JBA 1/10 10K OHM J 1608 O O 73 COIL CHIP L402~407 HLC189J02A 1.8UH CHIP 3216 O O
239 R CHIP R604A/B/C/L/R HRFT392JBA 1/10 3.9K OHM J 1608 O O 74 CONN WAFER PN401 9728810700 2.0MM PH-11AW 11P O O
240 R CHIP R604W HRFT751JBA 1/10 750 OHM J 1608 O O 75 CONN WAFER PN402 9728810800 2.0MM PH-4A 4P O O
241 R CHIP R605A/B/C/L/R/W HRFT104JBA 1/10 100K OHM J 1608 O O 76 CONN AS PN403 9728810100 #24 P2.0 5P 120MM UL 1007 O O
242 R CHIP R606A/B/C/L/R/W HRFT102JBA 1/10 1K OHM J 1608 O O 77 CABLE ATAPI PN404 9728811100 ATAPI CABLE 40P 250MM O O
243 R CHIP R607 HRFT103JBA 1/10 10K OHM J 1608 O O 78 R CHIP R401~402 HRFT472JBA 1/10 4.7K OHM J 1608 O O
244 R CHIP R608 HRFT223JBA 1/10 22K OHM J 1608 O O 79 R CHIP R404 HRFT472JBA 1/10 4.7K OHM J 1608 O O
245 R CHIP R608W HRFT102JBA 1/10 1K OHM J 1608 O O 80 R CHIP R405 HRFT181JBA 1/10 180 OHM J 1608 O O
246 R CHIP R609 HRFT122JBA 1/10 1.2K OHM J 1608 O O 81 R CHIP R406~411 HRFT472JBA 1/10 4.7K OHM J 1608 O O
247 R CHIP R610 HRFT000-BA 1/10 0 OHM 1608 O O 82 R CHIP R412 HRFT102JBA 1/10 1K OHM J 1608 O O
248 R CHIP R611 HRFT183JBA 1/10 18K OHM J 1608 O O 83 R CHIP R413~416 HRFT103JBA 1/10 10K OHM J 1608 O O
249 R CHIP R612~619 HRFT000-BA 1/10 0 OHM 1608 O O 84 R CHIP R420 HRFT270JCA 1/10 27 OHM J 2012 O O
