17. Electrical Parts List
DHC-X200/X250
DHC-X200 DHC-X250 DHC-X200 DHC-X250
REMARKSLOCATION PART-CODE PART-DESC
MODEL
PART-DESC NO PART-NAMEREMARKS
MODEL
NO PART-NAME LOCATION PART-CODE
86 R CHIP R423 HRFT472JBA 1/10 4.7K OHM J 1608 O O 61 R CHIP R951 HRFT103JBA 1/10 10K OHM J 1608 O
87 R CHIP R424 HRFT330JBA 1/10 33 OHM J 1608 O O 62 R CHIP R952 HRFT224JBA 1/10 220K OHM J 1608 O
88 R CHIP R425 HRFT220JBA 1/10W 22 OHM J 1608 O O 63 R CHIP R953 HRFT103JBA 1/10 10K OHM J 1608 O
89 R CHIP R426~427 HRFT330JBA 1/10 33 OHM J 1608 O O 64 R CHIP R954 HRFT680JBA 1/10 68 OHM J 1608 O
90 R CHIP R428 HRFT820JBA 1/10 82 OHM J 1608 O O 65 R CHIP R955 HRFT271JBA 1/10 270 OHM J 1608 O
91 R CHIP R429 HRFT562JBA 1/10 5.6K OHM J 1608 O O 66 R CHIP R956~958 HRFT103JBA 1/10 10K OHM J 1608 O
92 R CHIP R430 HRFT102JBA 1/10 1K OHM J 1608 O O 67 R CHIP R960 HRFT122JBA 1/10 1.2K OHM J 1608 O
93 R CHIP R431 HRFT220JBA 1/10W 22 OHM J 1608 O O 68 R CHIP R961~962 HRFT152JBA 1/10 1.5K OHM J 1608 O
94 R CHIP R432 HRFT102JBA 1/10 1K OHM J 1608 O O 69 R CHIP R963~964 HRFT272JBA 1/10 2.7K OHM J 1608 O
95 R CHIP R433~434 HRFT220JBA 1/10W 22 OHM J 1608 O O 70 R CHIP R965 HRFT472JBA 1/10 4.7K OHM J 1608 O
96 R CHIP R435~436 HRFT820JBA 1/10 82 OHM J 1608 O O 71 R CHIP R968 HRFT122JBA 1/10 1.2K OHM J 1608 O
97 R CHIP R437 HRFT220JBA 1/10W 22 OHM J 1608 O O 72 R CHIP R969~970 HRFT152JBA 1/10 1.5K OHM J 1608 O
98 R CHIP R449 HRFT101JBA 1/10 100 OHM J 1608 O O 73 R CHIP R971~972 HRFT272JBA 1/10 2.7K OHM J 1608 O
99 R CHIP R453~454 HRFT470JBA 1/10 47 OHM J 1608 O O 74 R CHIP R973 HRFT472JBA 1/10 4.7K OHM J 1608 O
100 R CHIP R457 HRFT000-BA 1/10 0 OHM 1608 O O 75 R CHIP R974 HRFT822JBA 1/10 8.2K OHM J 1608 O
101 R CHIP R458~466 HRFT472JBA 1/10 4.7K OHM J 1608 O O 76 R CHIP R975 HRFT101JBA 1/10 100 OHM J 1608 O
102 R CHIP R469~471 HRFT472JBA 1/10 4.7K OHM J 1608 O O 77 R CHIP R976 HRFT122JBA 1/10 1.2K OHM J 1608 O
103 R CHIP R472 HRFT103JBA 1/10 10K OHM J 1608 O O 78 R CHIP R977~978 HRFT152JBA 1/10 1.5K OHM J 1608 O
104 R CHIP R473 HRFT402FBA 1/10 4.0K OHM F 1608(1%) O O 79 R CHIP R979~980 HRFT272JBA 1/10 2.7K OHM J 1608 O
105 R CHIP R474~475 HRFT101JBA 1/10 100 OHM J 1608 O O 80 R CHIP R981 HRFT472JBA 1/10 4.7K OHM J 1608 O
106 R CHIP R476~481 HRFT750JBA 1/10 75 OHM J 1608 O O 81 R CHIP R982 HRFT822JBA 1/10 8.2K OHM J 1608 O
107 R ARRAY RA401~402 HRTT8X103J MNR 14X0ABJ 470 (10KX4) O O 82 R CHIP R983 HRFT102JBA 1/10 1K OHM J 1608 O
108 R ARRAY RA403 HRTT8X472J MNR 14X0ABJ 470 (4.7KX4) O O 83 R CHIP R984 HRFT000-BA 1/10 0 OHM 1608 O
109 R ARRAY RA404~405 HRTT8X181J MNR 14X0ABJ 470 (180X4) O O 84 R CHIP R987 HRFT103JBA 1/10 10K OHM J 1608 O
110 R ARRAY RA406~410 HRTT8X220J MNR 14X0ABJ 470 (22X4) O O 85 SW TACT SW901~924 5S50101001 KPT-1105A 1C-1P O
111 X-TAL X401 5XE16M000J 16MHZ HC-49/U (RADIAL) O O 86 VOL ENCODER VR904 5SH1624368 EC16B241040B O
112 X-TAL X402 5XE27M000C 27MHZ HC-49/U 20PPM 30PF O O 87 RESONATOR CERA X901 5PCST10MTW CST10.00MTW O
1 PCB FRONT AS 15000 9CDC059500 DV-135 O 1 PCB FRONT AS 15000 9CDC059300 DV-115 O
2 GUIDE FLT 10 9CD2506800 MIPS GRAY O 2 GUIDE FLT 10 9CD2506800 MIPS GRAY O
3 PCB FRONT B001 9CD6584500 242X329 O 3 PCB FRONT B001 9CD6583500 242X329 O
4 C CHIP CERA C932~933 HCBK103KBA 50V X7R 0.01MF K 1608 O 4 C CHIP CERA C932~933 HCBK103KBA 50V X7R 0.01MF K 1608 O
5 C CHIP CERA C934~939 HCQK101JBA 50V CH 100PF J 1608 O 5 C CHIP CERA C934~939 HCQK101JBA 50V CH 100PF J 1608 O
6 C ELECTRO C940 CEXP1C470V 16V REM 47MF O 6 C ELECTRO C940 CEXP1C470V 16V REM 47MF O
7 C CHIP CERA C941 HCBK473KBA 50V X7R 0.047MF K 1608 O 7 C CHIP CERA C941 HCBK473KBA 50V X7R 0.047MF K 1608 O
8 C CHIP CERA C946~947 HCQK101JBA 50V CH 100PF J 1608 O 8 C CHIP CERA C946~947 HCQK101JBA 50V CH 100PF J 1608 O
9 C CHIP CERA C948 HCBK103KBA 50V X7R 0.01MF K 1608 O 9 C CHIP CERA C948 HCBK103KBA 50V X7R 0.01MF K 1608 O
10 C CHIP CERA C949 HCQK101JBA 50V CH 100PF J 1608 O 10 C CHIP CERA C949 HCQK101JBA 50V CH 100PF J 1608 O
11 C CHIP CERA C950 HCBK103KBA 50V X7R 0.01MF K 1608 O 11 C CHIP CERA C950 HCBK103KBA 50V X7R 0.01MF K 1608 O
12 C ELECTRO C951 CEXP1H479V 50V REM 4.7MF 4*5 O 12 C ELECTRO C951 CEXP1H479V 50V REM 4.7MF 4*5 O
13 C DOUBLE LAYER C952 CDXC0H479A 0.047F/5.5V 70UA 5RE O 13 C DOUBLE LAYER C952 CDXC0H479A 0.047F/5.5V 70UA 5RE O
14 C ELECTRO C953 CEXP1C470V 16V REM 47MF O 14 C ELECTRO C953 CEXP1C470V 16V REM 47MF O
15 C CHIP CERA C954 HCBK103KBA 50V X7R 0.01MF K 1608 O 15 C CHIP CERA C954 HCBK103KBA 50V X7R 0.01MF K 1608 O
16 C CHIP CERA C955 HCBK104KBA 50V X7R 0.1MF K 1608 O 16 C CHIP CERA C955 HCBK104KBA 50V X7R 0.1MF K 1608 O
17 C CHIP CERA C957~959 HCQK101JBA 50V CH 100PF J 1608 O 17 C CHIP CERA C957~959 HCQK101JBA 50V CH 100PF J 1608 O
18 C CHIP CERA C960 HCBK473KBA 50V X7R 0.047MF K 1608 O 18 C CHIP CERA C960 HCBK473KBA 50V X7R 0.047MF K 1608 O
19 C ELECTRO C961 CEXP1H109V 50V REM 1MF 4*5 O 19 C ELECTRO C961 CEXP1H109V 50V REM 1MF 4*5 O
20 C CHIP CERA C962 HCBK104KBA 50V X7R 0.1MF K 1608 O 20 C CHIP CERA C962 HCBK104KBA 50V X7R 0.1MF K 1608 O
21 C ELECTRO C963 CEXP1H109V 50V REM 1MF 4*5 O 21 C ELECTRO C963 CEXP1H109V 50V REM 1MF 4*5 O
22 C CHIP CERA C964 HCBK473KBA 50V X7R 0.047MF K 1608 O 22 C CHIP CERA C964 HCBK473KBA 50V X7R 0.047MF K 1608 O
23 CONN AS CN901 9728811200 #26 P2.0 4P 160MM UL 1007 O 23 CONN AS CN901 9728811200 #26 P2.0 4P 160MM UL 1007 O
24 CONN AS CN903 9728809700 #26 P2.0 7P 140MM UL 1007 O 24 CONN AS CN903 9728809700 #26 P2.0 7P 140MM UL 1007 O
25 CONN AS CN904 9728811300 #26 P2.0 6P 170MM UL 1007 O 25 CONN AS CN904 9728811300 #26 P2.0 6P 170MM UL 1007 O
26 CONN AS CN906 9728811500 #26 P2.0 3P 100MM UL 1007 O 26 CONN AS CN906 9728811500 #26 P2.0 3P 100MM UL 1007 O
27 CONN FFC CN911 9728809400 FFC 1.25X27X360MM K O 27 CONN FFC CN911 9728809400 FFC 1.25X27X360MM K O
28 CONN FFC CN912 9728809300 FFC 1.25X11X230MM R O 28 CONN FFC CN912 9728809300 FFC 1.25X11X230MM R O
29 CONN WAFER CP901 9CD6264000 52044-1145 O 29 CONN WAFER CP901 9CD6264000 52044-1145 O
30 CONN WAFER CP903 9CD6264200 52044-2745 O 30 CONN WAFER CP903 9CD6264200 52044-2745 O
31 DIODE SW CHIP D902 DZDS160--- KDS160 O 31 DIODE D902 DZN4148--- 1N4148 AUTO 52MM O
32 DIODE ZENER D903 DZTZ3R3B-- MTZ 3.3V B O 32 DIODE ZENER D903 DZTZ3R3B-- MTZ 3.3V B O
33 DIODE SW CHIP D904 DZDS160--- KDS160 O 33 DIODE D904 DZN4148--- 1N4148 AUTO 52MM O
34 DIODE D905 DZN4007--- IN4007 O 34 DIODE D905 DZN4007--- IN4007 O
35 DIODE SW CHIP D906 DZDS160--- KDS160 O 35 DIODE D906 DZN4148--- 1N4148 AUTO 52MM O
36 DIODE ZENER D908 DZTZ6R8B-- MTZ6.8B O 36 DIODE ZENER D908 DZTZ6R8B-- MTZ6.8B O
37 FL DISPLAY FL901 DHNA11MM37 NHA-11MM37 O 37 FL DISPLAY FL901 DHNA11MM37 NHA-11MM37 O
38 IC MICOM IC904 1CXP82852- CXP82852-329Q O 38 IC MICOM IC904 1CXP82852- CXP82852-329Q O
39 IC RMC MODULE IC905 1TM97CT38- TM97CT38P O 39 IC RMC MODULE IC905 1TM97CT38- TM97CT38P O
40 R CHIP L903 HRFT000-BA 1/10 0 OHM 1608 O 40 R CHIP L901~903 HRFT000-BA 1/10 0 OHM 1608 O
41 TR Q903 TZTC3875-- KTC3875 O 41 TR Q903 TZTC3875-- KTC3875 O
42 TR CHIP Q904 TZRC102S-- KRC102S O 42 TR CHIP Q904 TZRC102S-- KRC102S O
43 R CHIP R1001 HRFT103JBA 1/10 10K OHM J 1608 O 43 R CHIP R1~37 HRFT104JBA 1/10 100K OHM J 1608 O
44 R CHIP R1002 HRFT473JBA 1/10 47K OHM J 1608 O 44 R CHIP R1001 HRFT103JBA 1/10 10K OHM J 1608 O
45 R CHIP R1003~1010 HRFT103JBA 1/10 10K OHM J 1608 O 45 R CHIP R1002 HRFT473JBA 1/10 47K OHM J 1608 O
46 R CHIP R1011~1013 HRFT473JBA 1/10 47K OHM J 1608 O 46 R CHIP R1003~1010 HRFT103JBA 1/10 10K OHM J 1608 O
47 R CHIP R1014 HRFT101JBA 1/10 100 OHM J 1608 O 47 R CHIP R1011~1013 HRFT473JBA 1/10 47K OHM J 1608 O
48 R CHIP R1015 HRFT472JBA 1/10 4.7K OHM J 1608 O 48 R CHIP R1014 HRFT101JBA 1/10 100 OHM J 1608 O
49 R CHIP R926~928 HRFT473JBA 1/10 47K OHM J 1608 O 49 R CHIP R1015 HRFT472JBA 1/10 4.7K OHM J 1608 O
50 R CHIP R929 HRFT100JBA 1/10 10 OHM J 1608 O 50 R CHIP R926~928 HRFT473JBA 1/10 47K OHM J 1608 O
51 R CHIP R930 HRFT104JBA 1/10 100K OHM J 1608 O 51 R CHIP R929 HRFT100JBA 1/10 10 OHM J 1608 O
52 R CHIP R931~933 HRFT101JBA 1/10 100 OHM J 1608 O 52 R CHIP R930 HRFT104JBA 1/10 100K OHM J 1608 O
53 R CHIP R934~936 HRFT220JBA 1/10W 22 OHM J 1608 O 53 R CHIP R931~933 HRFT101JBA 1/10 100 OHM J 1608 O
54 R CHIP R937~940 HRFT101JBA 1/10 100 OHM J 1608 O 54 R CHIP R934~936 HRFT220JBA 1/10W 22 OHM J 1608 O
55 R CHIP R941~942 HRFT471JBA 1/10 470 OHM J 1608 O 55 R CHIP R937~940 HRFT101JBA 1/10 100 OHM J 1608 O
56 R CHIP R943 HRFT473JBA 1/10 47K OHM J 1608 O 56 R CHIP R941~942 HRFT471JBA 1/10 470 OHM J 1608 O
57 R CHIP R944 HRFT471JBA 1/10 470 OHM J 1608 O 57 R CHIP R943 HRFT473JBA 1/10 47K OHM J 1608 O
58 R CHIP R945~946 HRFT473JBA 1/10 47K OHM J 1608 O 58 R CHIP R944 HRFT471JBA 1/10 470 OHM J 1608 O
59 R CHIP R947~948 HRFT102JBA 1/10 1K OHM J 1608 O 59 R CHIP R945~946 HRFT473JBA 1/10 47K OHM J 1608 O
60 R CHIP R949~950 HRFT472JBA 1/10 4.7K OHM J 1608 O 60 R CHIP R947~948 HRFT102JBA 1/10 1K OHM J 1608 O
