Daewoo DHC-X200 - Page 36

17. Electrical Parts List
DHC-X200/X250
DHC-X200 DHC-X250 DHC-X200 DHC-X250
REMARKSLOCATION PART-CODE PART-DESC
MODEL
PART-DESC NO PART-NAMEREMARKS
MODEL
NO PART-NAME LOCATION PART-CODE
61 R CHIP R949~950 HRFT472JBA 1/10 4.7K OHM J 1608 O 60 R CHIP R916 HRFT562JBA 1/10 5.6K OHM J 1608 O
62 R CHIP R951 HRFT103JBA 1/10 10K OHM J 1608 O 61 R CHIP R917 HRFT123JBA 1/10 12K OHM J 1608 O
63 R CHIP R952 HRFT224JBA 1/10 220K OHM J 1608 O 62 R CHIP R919 HRFT183JBA 1/10 18K OHM J 1608 O
64 R CHIP R953 HRFT103JBA 1/10 10K OHM J 1608 O 63 R CHIP R920 HRFT221JBA 1/10 220 OHM J 1608 O
65 R CHIP R954 HRFT680JBA 1/10 68 OHM J 1608 O 64 R CARBON FILM R921 RD-4Z331J- 1/4 330 OHM J O
66 R CHIP R955 HRFT271JBA 1/10 270 OHM J 1608 O 65 R CHIP R923L/R HRFT472JBA 1/10 4.7K OHM J 1608 O
67 R CHIP R956~958 HRFT103JBA 1/10 10K OHM J 1608 O 66 R CHIP R924L/R HRFT103JBA 1/10 10K OHM J 1608 O
68 R CHIP R960 HRFT122JBA 1/10 1.2K OHM J 1608 O 67 R CHIP R925L/R HRFT472JBA 1/10 4.7K OHM J 1608 O
69 R CHIP R961~962 HRFT152JBA 1/10 1.5K OHM J 1608 O 68 R CHIP R966 HRFT104JBA 1/10 100K OHM J 1608 O
70 R CHIP R963~964 HRFT272JBA 1/10 2.7K OHM J 1608 O 69 R CHIP R983L/R HRFT104JBA 1/10 100K OHM J 1608 O
71 R CHIP R965 HRFT472JBA 1/10 4.7K OHM J 1608 O 70 R CHIP R984L/R HRFT223JBA 1/10 22K OHM J 1608 O
72 R CHIP R968 HRFT122JBA 1/10 1.2K OHM J 1608 O 71 R CHIP R985 HRFT102JBA 1/10 1K OHM J 1608 O
73 R CHIP R969~970 HRFT152JBA 1/10 1.5K OHM J 1608 O 72 R CHIP R986 HRFT474JBA 1/10 470K OHM J 1608 O
74 R CHIP R971~972 HRFT272JBA 1/10 2.7K OHM J 1608 O 73 VR ROTARY VR901 5V1503727B RK09K1110303 50KB O
75 R CHIP R973 HRFT472JBA 1/10 4.7K OHM J 1608 O 74 VR ROTARY VR903 5V1503727B RK09K1110303 50KB O
76 R CHIP R974 HRFT822JBA 1/10 8.2K OHM J 1608 O 1 PCB MIC AS 16000 9CDC0593A0 DV-115 O
77 R CHIP R975 HRFT101JBA 1/10 100 OHM J 1608 O 2 PCB MIC B001 9CD6583501 242X329 O
78 R CHIP R976 HRFT122JBA 1/10 1.2K OHM J 1608 O 3 C ELECTRO C901 CEXF1H479E 50V RM 4.7MF (5X11) TP O
79 R CHIP R977~978 HRFT152JBA 1/10 1.5K OHM J 1608 O 4 C CHIP CERA C902 HCQK101JBA 50V CH 100PF J 1608 O
80 R CHIP R979~980 HRFT272JBA 1/10 2.7K OHM J 1608 O 5 C ELECTRO C903 CEXF1H220E 50V RM 22MF (5X11) TP O
81 R CHIP R981 HRFT472JBA 1/10 4.7K OHM J 1608 O 6 C CHIP CERA C904 HCQK221JBA 50V CH 220PF J 1608 O
82 R CHIP R982 HRFT822JBA 1/10 8.2K OHM J 1608 O 7 C ELECTRO C905 CEXF1H479E 50V RM 4.7MF (5X11) TP O
83 R CHIP R983 HRFT102JBA 1/10 1K OHM J 1608 O 8 C CHIP CERA C906 HCBK102KBA 50V X7R 1000PF K 1608 O
84 R CHIP R984 HRFT000-BA 1/10 0 OHM 1608 O 9 C ELECTRO C907 CEXF1H100E 50V RM 10MF (5X11) TP O
85 R CHIP R987 HRFT103JBA 1/10 10K OHM J 1608 O 10 C CHIP CERA C908 HCBK472KBA 50V X7R 4700PF K 1608 O
86 SW TACT SW901~924 5S50101001 KPT-1105A 1C-1P O 11 C ELECTRO C909 CEXF1H339E 50V RM 3.3MF (5X11) TP O
87 VOL ENCODER VR904 5SH1624368 EC16B241040B O 12 C CHIP CERA C910 HCQK561JBA 50V CH 560PF J 1608 O
88 RESONATOR CERA X901 5PCST10MTW CST10.00MTW O 13 C CHIP CERA C911 HCBK563KBA 50V X7R 0.056MF K 1608 O
1 PCB MIC AS 16000 9CDC0595A0 DV-135 O 14 C ELECTRO C912 CEXF1H100E 50V RM 10MF (5X11) TP O
2 PCB MIC B001 9CD6585300 242X329 O 15 C CHIP CERA C913 HCBK392KBA 50V X7R 3900PF K 1608 O
3 C ELECTRO C901 CEXF1H479E 50V RM 4.7MF (5X11) TP O 16 C CHIP CERA C914 HCBK563KBA 50V X7R 0.056MF K 1608 O
4 C CHIP CERA C902 HCQK101JBA 50V CH 100PF J 1608 O 17 C CHIP CERA C915 HCQK561JBA 50V CH 560PF J 1608 O
5 C ELECTRO C903 CEXF1H220E 50V RM 22MF (5X11) TP O 18 C CHIP CERA C916~917 HCBK472KBA 50V X7R 4700PF K 1608 O
6 C CHIP CERA C904 HCQK221JBA 50V CH 220PF J 1608 O 19 C ELECTRO C918 CEXF1H220E 50V RM 22MF (5X11) TP O
7 C ELECTRO C905 CEXF1H479E 50V RM 4.7MF (5X11) TP O 20 C CHIP CERA C919 HCQK221JBA 50V CH 220PF J 1608 O
8 C CHIP CERA C906 HCBK102KBA 50V X7R 1000PF K 1608 O 21 CLECTRO C920 CEXF1C221E RM 16V 220MF 6.3X11 TAT O
9 C ELECTRO C907 CEXF1H100E 50V RM 10MF (5X11) TP O 22 C CHIP CERA C921~923 HCBK104KBA 50V X7R 0.1MF K 1608 O
10 C CHIP CERA C908 HCBK472KBA 50V X7R 4700PF K 1608 O 23 C ELECTRO C924 CEXF1E101E 25V RM 100MF (6.3X11) TP O
11 C ELECTRO C909 CEXF1H339E 50V RM 3.3MF (5X11) TP O 24 C ELECTRO C925 CEXF1H100E 50V RM 10MF (5X11) TP O
12 C CHIP CERA C910 HCQK561JBA 50V CH 560PF J 1608 O 25 CLECTRO C926 CEXF1C221E RM 16V 220MF 6.3X11 TAT O
13 C CHIP CERA C911 HCBK563KBA 50V X7R 0.056MF K 1608 O 26 C CHIP CERA C927 HCBK103KBA 50V X7R 0.01MF K 1608 O
14 C ELECTRO C912 CEXF1H100E 50V RM 10MF (5X11) TP O 27 CLECTRO C928 CEXF1C221E RM 16V 220MF 6.3X11 TAT O
15 C CHIP CERA C913 HCBK392KBA 50V X7R 3900PF K 1608 O 28 C CHIP CERA C929 HCBK103KBA 50V X7R 0.01MF K 1608 O
16 C CHIP CERA C914 HCBK563KBA 50V X7R 0.056MF K 1608 O 29 C CHIP CERA C930L/R HCBK102KBA 50V X7R 1000PF K 1608 O
17 C CHIP CERA C915 HCQK561JBA 50V CH 560PF J 1608 O 30 C ELECTRO C931L/R CEXF1H479E 50V RM 4.7MF (5X11) TP O
18 C CHIP CERA C916~917 HCBK472KBA 50V X7R 4700PF K 1608 O 31 C ELECTRO C967 CEXF1H108E 50V RM 0.1MF (5X11) TP O
19 C ELECTRO C918 CEXF1H220E 50V RM 22MF (5X11) TP O 32 C ELECTRO C968L/R CEXF1H100E 50V RM 10MF (5X11) TP O
20 C CHIP CERA C919 HCQK221JBA 50V CH 220PF J 1608 O 33 C CHIP CERA C969 HCBK103KBA 50V X7R 0.01MF K 1608 O
21 CLECTRO C920 CEXF1C221E RM 16V 220MF 6.3X11 TAT O 34 CONN AS CN905 9728811400 P2.0 3P 270MM SHIELD O
22 C CHIP CERA C921~923 HCBK104KBA 50V X7R 0.1MF K 1608 O 35 CONN WAFER CP904 9728808600 2.0MM PH-6AW 6P O
23 C ELECTRO C924 CEXF1E101E 25V RM 100MF (6.3X11) TP O 36 CONN AS CP907 9728809500 #26 P2.0 8P 180MM UL 1007 O
24 C ELECTRO C925 CEXF1H100E 50V RM 10MF (5X11) TP O 37 DIODE ZENER D901 DZTZ5R6B-- UZ-5.6B O
25 CLECTRO C926 CEXF1C221E RM 16V 220MF 6.3X11 TAT O 38 DIODE SW CHIP D909~910 DZDS160--- KDS160 O
26 C CHIP CERA C927 HCBK103KBA 50V X7R 0.01MF K 1608 O 39 IC CHIP IC901 1NJM4558M- NJM4558M O
27 CLECTRO C928 CEXF1C221E RM 16V 220MF 6.3X11 TAT O 40 IC IC902 1ES56033-- ES56033 O
28 C CHIP CERA C929 HCBK103KBA 50V X7R 0.01MF K 1608 O 41 IC CHIP IC903 1NJM4558M- NJM4558M O
29 C CHIP CERA C930L/R HCBK102KBA 50V X7R 1000PF K 1608 O 42 JACK MIC JA901 9736324200 H20480060S O
30 C ELECTRO C931L/R CEXF1H479E 50V RM 4.7MF (5X11) TP O 43 TR Q901 TZTC3200GR KTC3200GR (AUTO)(2240GR) O
31 C ELECTRO C967 CEXF1H108E 50V RM 0.1MF (5X11) TP O 44 TR CHIP Q905L/R TZRC231S-- KRC231S O
32 C ELECTRO C968L/R CEXF1H100E 50V RM 10MF (5X11) TP O 45 TR CHIP Q906 TZRA102S-- KRA102S (10X10)PNP O
33 C CHIP CERA C969 HCBK103KBA 50V X7R 0.01MF K 1608 O 46 TR CHIP Q907 TZRC104S-- KRC104S O
34 CONN AS CN905 9728811400 P2.0 3P 270MM SHIELD O 47 R CHIP R901 HRFT561JBA 1/10 560 OHM J 1608 O
35 CONN AS CN907 9728809500 #26 P2.0 8P 180MM UL 1007 O 48 R CHIP R902 HRFT103JBA 1/10 10K OHM J 1608 O
36 CONN WAFER CP904 9728808600 2.0MM PH-6AW 6P O 49 R CHIP R903 HRFT473JBA 1/10 47K OHM J 1608 O
37 DIODE ZENER D901 DZTZ5R6B-- UZ-5.6B O 50 R CHIP R904 HRFT561JBA 1/10 560 OHM J 1608 O
38 IC CHIP IC901 1NJM4558M- NJM4558M O 51 R CHIP R905 HRFT563JBA 1/10 56K OHM J 1608 O
39 IC IC902 1ES56033-- ES56033 O 52 R CHIP R906 HRFT392JBA 1/10 3.9K OHM J 1608 O
40 IC CHIP IC903 1NJM4558M- NJM4558M O 53 R CHIP R908 HRFT103JBA 1/10 10K OHM J 1608 O
41 JACK MIC JA901 9736324200 H20480060S O 54 R CHIP R909 HRFT123JBA 1/10 12K OHM J 1608 O
42 COIL CHIP L914~915 HLC104J01A BEAD 120 OHM 100MHZ 2012 O 55 R CHIP R910 HRFT103JBA 1/10 10K OHM J 1608 O
43 TR Q901 TZTC3200GR KTC3200GR (AUTO)(2240GR) O 56 R CHIP R911~912 HRFT153JBA 1/10 15K OHM J 1608 O
44 TR CHIP Q905L/R TZRC231S-- KRC231S O 57 R CHIP R913 HRFT123JBA 1/10 12K OHM J 1608 O
45 TR CHIP Q906 TZRA102S-- KRA102S (10X10)PNP O 58 R CHIP R914 HRFT103JBA 1/10 10K OHM J 1608 O
46 TR CHIP Q907 TZRC104S-- KRC104S O 59 R CHIP R915 HRFT153JBA 1/10 15K OHM J 1608 O
47 R CHIP R901 HRFT561JBA 1/10 560 OHM J 1608 O 60 R CHIP R916 HRFT562JBA 1/10 5.6K OHM J 1608 O
48 R CHIP R902 HRFT103JBA 1/10 10K OHM J 1608 O 61 R CHIP R917 HRFT123JBA 1/10 12K OHM J 1608 O
49 R CHIP R903 HRFT473JBA 1/10 47K OHM J 1608 O 62 R CHIP R919 HRFT183JBA 1/10 18K OHM J 1608 O
50 R CHIP R904 HRFT561JBA 1/10 560 OHM J 1608 O 63 R CHIP R920 HRFT221JBA 1/10 220 OHM J 1608 O
51 R CHIP R905 HRFT563JBA 1/10 56K OHM J 1608 O 64 R CARBON FILM R921 RD-4Z331J- 1/4 330 OHM J O
52 R CHIP R906 HRFT392JBA 1/10 3.9K OHM J 1608 O 65 R CHIP R922 HRFT000-BA 1/10 0 OHM 1608 O
53 R CHIP R908 HRFT103JBA 1/10 10K OHM J 1608 O 66 R CHIP R923L/R HRFT472JBA 1/10 4.7K OHM J 1608 O
54 R CHIP R909 HRFT123JBA 1/10 12K OHM J 1608 O 67 R CHIP R924L/R HRFT103JBA 1/10 10K OHM J 1608 O
55 R CHIP R910 HRFT103JBA 1/10 10K OHM J 1608 O 68 R CHIP R925L/R HRFT472JBA 1/10 4.7K OHM J 1608 O
56 R CHIP R911~912 HRFT153JBA 1/10 15K OHM J 1608 O 69 R CHIP R966 HRFT104JBA 1/10 100K OHM J 1608 O
57 R CHIP R913 HRFT123JBA 1/10 12K OHM J 1608 O 70 R CHIP R983L/R HRFT104JBA 1/10 100K OHM J 1608 O
58 R CHIP R914 HRFT103JBA 1/10 10K OHM J 1608 O 71 R CHIP R984L/R HRFT223JBA 1/10 22K OHM J 1608 O
59 R CHIP R915 HRFT153JBA 1/10 15K OHM J 1608 O 72 R CHIP R985 HRFT102JBA 1/10 1K OHM J 1608 O
58
