17. Electrical Parts List
DHC-X200/X250
DHC-X200 DHC-X250
PART-DESC REMARKS
MODEL
NO PART-NAME LOCATION PART-CODE
73 R CHIP R986 HRFT474JBA 1/10 470K OHM J 1608 O
74 VR ROTARY VR901 5V1503727B RK09K1110303 50KB O
75 VR ROTARY VR903 5V1503727B RK09K1110303 50KB O
1 PCB POWER SW AS 19000 9CDC0595D0 DV-135 O
2 PCB POWER SW B001 9CD6584503 242X329 O
3 C CERA AC C991 CH1BFE472M AC400V 4700PF M U/C/V O
4 CONN WAFER CP993 9728808200 VH-3A (W/O CENTER,RED) O
5 SW POWER SPST S991 5S40101369 SDDL-005-S PUSH O
1 PCB POWER SW AS 19000 9CDC0593D0 DV-115 O
2 PCB POWER SW B001 9CD6583505 242X329 O
3 C CERA AC C991 CH1BFE472M AC400V 4700PF M U/C/V O
4 CONN WAFER CP993 9728808200 VH-3A (W/O CENTER,RED) O
5 SW POWER SPST S991 5S40101369 SDDL-005-S PUSH O
1 PCB H/P AS 17000 9CDC0595B0 DV-135 O
2 PCB H/P B001 9CD6584501 242X329 O
3 C CHIP CERA C992 HCBK103KBA 50V X7R 0.01MF K 1608 O
4 C CHIP CERA C993~994 HCBK102KBA 50V X7R 1000PF K 1608 O
5 CONN WAFER CP902 9728808800 2.0MM PH-3AW 3P O
6 CONN WAFER CP992 9728808900 2.0MM PH-7A 7P O
7 COIL CHIP L911~912 HLC104J01A BEAD 120 OHM 100MHZ 2012 O
8 COIL CHIP L916 HLC104J01A BEAD 120 OHM 100MHZ 2012 O
9 JACK HEADPHONE PH991 9766319502 HTJ-064-05B GOLD O
1 PCB H/P AS 17000 9CDC0593B0 DV-115 O
2 PCB H/P B001 9CD6583502 242X329 O
3 C CHIP CERA C992 HCBK103KBA 50V X7R 0.01MF K 1608 O
4 C CHIP CERA C993~994 HCBK102KBA 50V X7R 1000PF K 1608 O
5 CONN WAFER CP902 9728808800 2.0MM PH-3AW 3P O
6 CONN WAFER CP992 9728808900 2.0MM PH-7A 7P O
7 DIODE SW CHIP D911~912 DZDS160--- KDS160 O
8 JACK HEADPHONE PH991 9766319502 HTJ-064-05B GOLD O
1 PCB KEY SW AS 18000 9CDC0595C0 DV-135 O
2 PCB KEY SW B001 9CD6584502 242X329 O
3 CONN WAFER CP906 9728808800 2.0MM PH-3AW 3P O
4 LED D907 DLTL16KEE- LTL-16KEE(RED)PI3.1 O
5 SW TACT SW907 5S50101001 KPT-1105A 1C-1P O
1 PCB KEY SW AS 18000 9CDC0593C0 DV-115 O
2 PCB KEY SW B001 9CD6583503 242X329 O
3 CONN WAFER CP906 9728808800 2.0MM PH-3AW 3P O
4 LED D907 DLTL16KEE- LTL-16KEE(RED)PI3.1 O
5 SW TACT SW907 5S50101001 KPT-1105A 1C-1P O
