17. Electrical Parts List(Option List)
TUNER Option List
NO VERSION PCB
TUNER STEP(FM/AM
)
FM BAND AM BAND R987 R988 VOLTAGE
1 USA FRONT 100KHz / 10KHz 87.5 - 108 530 - 1710 OPEN 10K 0 V
2 KOREA, Australia FRONT 100KHz / 9KHz 87.5 - 108 522 - 1620 10K 2.4K 1 V
3 KOREA, Australia FRONT 50KHz / 9KHz 87.5 - 108 522 - 1620 10K 6.8K 2 V
4 JAPAN FRONT 100KHz / 9KHz 76.0 - 108 522 - 1620 6.8K 10K 3 V
5 EUROPE(W/O RDS) FRONT 50KHz / 9KHz 87.5 - 108 522 - 1620 2.4K 10K 4 V
6 EUROPE(W RDS) FRONT 50KHz / 9KHz 87.5 - 108 522 - 1620 10K OPEN 5 V
60
S/N NAME DESCRIPTION S/N NAME DESCRIPTION
1 ASSY 11000 9CDC0604A0
P
CB VIDEO A
S
DV-112 9CDC0604B0
PCB SCART A
S
DV-112
2 B001 9CD6585401 PCB VIDEO 330x247 9CD6586200 PCB SCART 163x139x1.6T Q’ty: 0.5
3 CE457 X X X CEYF1C471V C ELECTRO 16V RSS 470MF
ADD
4 D456 X X X DZN4148--- DIODE 1N4148
ADD
5 D457 X X X DZN4148--- DIODE 1N4148
ADD
6 DZ401 X X X DZTZ5R6B- DIODE ZENER 5.6V B
ADD
7 DZ402 X X X DZTZ5R6B- DIODE ZENER 5.6V B
ADD
8 DZ403 X X X DZTZ5R6B- DIODE ZENER 5.6V B
ADD
9 DZ404 X X X DZTZ5R6B- DIODE ZENER 5.6V B
ADD
10 J454 9736323900 JACK RCA JE031645G X X X
11 J455 X X X 9736324800 JACK SCART 21P
ADD
12 JW401 W581GY1505 WIRE JUMP 15MM W581GY7595 WIRE JUMP 7.5MM
13
JW405
W581GY1505 WIRE JUMP 15MM W581GY7595 WIRE JUMP 7.5MM
14
JW407
W581GY7595 WIRE JUMP 7.5MM W581GY12J5 WIRE JUMP
12.5MM
15
JW408
W581GY12J5 WIRE JUMP
12.5MM
W581GY7595 WIRE JUMP 7.5MM
16
JW409
W581GY1005 WIRE JUMP
10MM
W581GY7595 WIRE JUMP 7.5MM
17
JW410
W581GY7595 WIRE JUMP 7.5MM W581GY6095 WIRE JUMP 6MM
18
JW412
W581GY1505 WIRE JUMP 15MM
XX X
19
R464 X X X RD-AZ680J- R CARBON 68 OHM
ADD
20
R465 X X X RD-AZ391J- R CARBON 390 OHM
ADD
21
Q455 X X X TKRA107M-- TR KRA107M
ADD
22
Q456 X X X TKRC107M-- TR KRC107M
ADD
23
Q457 X X X TZTC3199Y- TR KTC-3199Y
ADD
REMARKNO PCB LOC
COMPONENT SCART
SCART Option List
