Daewoo DHC-X200 - Page 39

17. Electrical Parts List(Option List)
Karaoke Option List
S/N NAME DESCRIPTION S/N NAME DESCRIPTION
1 16000 9CDC0595A0 PCB MIC AS DV-135 X X X
16000 9CDC0593A0 PCB MIC AS DV-115 X X X
2 MAIN CW404 9728808700 WAFER 2.0MM PH-08A X X X
3 MAIN CW404 X X X 9728812000 WAFER 2.0MM PH-04A
4 FRONT CN904 9728811300 CONN AS P2.0 6P 170MM 9728811900 CONN AS P2.0 4P 170MM
3 DSP R585L HRFT472JBA R CHIP 4.7K OHM X X X
4 DSP R585R HRFT472JBA R CHIP 4.7K OHM X X X
REMARKNO PCB LOC
W KARAOKE W/O KARAOKE
61
NO PCB LOCATION S/N NAME DESCRIPTION W RDS W/O RDS REMARK
1 FRONT R987 HRFT103JBA R CHIP 1/10 10K OHM O X
2 BACK TU001 9737650201 TUNER MODULE KST-MB114MA1-0 O X
3 BACK CN913 9728809200 FFC FFC 1.25X17X110MM K O X
4 MAIN CW401 9CD6263900 FFC WAFER 52045-1745 O X
5 BACK TU001 9737650301 TUNER MODULE KST-MB011MA1-0 X O
6 BACK CN913 9728811600 FFC FFC 1.25X15X110MM K X O
7 MAIN CW401 9CD6264100 FFC WAFER 52045-1545 X O
S/N NAME DESCRIPTION S/N NAME DESCRIPTION
1 BACK AC901 9736908600 CORD AC KE-25 H03VVH2-F 9736908700 CORD AC KE-01P NSPT-2
2 MAIN R901 X X X RD-2Y475J- R CARBON FILM 1/2W 4.7M OHM
3 MAIN Q902 X X X TKRC107M-- TR KRC107M
4 MAIN DZ903 X X X DZTZ15B--- DIODE ZENER MTZ 15V B
16 MAIN F901 5FSGB2022L FUSE SEMKO 250V 2A TL 5F1GB3122L FUSE UL/CSA TL 250V 3.15A
18 MAIN CW401 9CD6263900 WAFER 52045-1745 9CD6264100 WAFER 52045-1545 TUNER
19 MAIN PT901 5TP8028855 P/T SUB 28X12 8.5V 150mA 5TP1028856 P/T SUB 28X12 8.5V 150mA
20 BOT PT902 5TP8086859 P/T MAIN 86X50 230V/50Hz 5TP1086860 P/T MAIN 86X50 127V/60Hz
21 FRONT R987 HRFT103JBA R CHIP 1/10 10K OHM J X X X TUNER
22 FRONT R988 X X X HRFT103JBA R CHIP 1/10 10K OHM J TUNER
23 BACK TU001 9737650201 TUNER MODULE KST-MB114MA1-0 9737650101 TUNER MODULE KST-MB011MA0-0 TUNER
24 BACK CN913 9728809200 FFC 1.25X17X110MM K 9728811600 FFC 1.25X15X110MM K TUNER
REMARKNO PCB LOC
EUROPE(RDS) AMERICA
RDS Option List
CE vs UL Option List
