-30-
Service part list
R843 HRFT332JBA R CHIP 1/10 3.3K OHM J 1608
R844 HRFT123JBA R CHIP 1/10 12K OHM J 1608
R853 HRFT103JBA R CHIP 1/10 10K OHM J 1608
R863 HRFT103JBA R CHIP 1/10 10K OHM J 1608
R889 HRFT222JBA R CHIP 1/10 2.2K OHM J 1608
R890 HRFT241JBA R CHIP 1/10 240 OHM J 1608
R912 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R913 HRFT103JBA R CHIP 1/10 10K OHM J 1608
R915 HRFT103JBA R CHIP 1/10 10K OHM J 1608
R918 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R921 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R925 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R928 HRFT101JBA R CHIP 1/10 100 OHM J 1608
RA01 HRFT750JBA R CHIP 1/10 75 OHM J 1608
RA20 HRFT750JBA R CHIP 1/10 75 OHM J 1608
RA21 HRFT750JBA R CHIP 1/10 75 OHM J 1608
RA30 HRFT750JBA R CHIP 1/10 75 OHM J 1608
RA31 HRFT750JBA R CHIP 1/10 75 OHM J 1608
RA33 HRFT750JBA R CHIP 1/10 75 OHM J 1608
RA58 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RA62 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RA68 HRFT750JBA R CHIP 1/10 75 OHM J 1608
RA69 HRFT000-BA R CHIP 1/10 0 OHM 1608
RA70 HRFT000-BA R CHIP 1/10 0 OHM 1608
RA71 HRFT000-BA R CHIP 1/10 0 OHM 1608
RA78 HRFT750JBA R CHIP 1/10 75 OHM J 1608
RA79 HRFT750JBA R CHIP 1/10 75 OHM J 1608
RA80 HRFT000-BA R CHIP 1/10 0 OHM 1608
RA81 HRFT000-BA R CHIP 1/10 0 OHM 1608
RA82 HRFT000-BA R CHIP 1/10 0 OHM 1608
RA86 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RA87 HRFT101JBA R CHIP 1/10 100 OHM J 1608
RA89 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RA96 HRFT101JBA R CHIP 1/10 100 OHM J 1608
RC81 HRFT000-BA R CHIP 1/10 0 OHM 1608
RC82 HRFT000-BA R CHIP 1/10 0 OHM 1608
ZZ200 PTMPJ0G177 PCB MAIN (RHU) AS DLP-20J1LHS
C631 CEXF1C102V C ELECTRO 16V RSS 1000MF (10X20) TP
C822 CEXF1C102V C ELECTRO 16V RSS 1000MF (10X20) TP
C825 CEXF1C102V C ELECTRO 16V RSS 1000MF (10X20) TP
C826 CEXF1E471V C ELECTRO 25V 470MF 10X12.5
C828 CEXF1C102V C ELECTRO 16V RSS 1000MF (10X20) TP
ZZ200 PTMPJBG177 PCB MAIN M-10 AS DLP-20J1LHS
P201 485923202S CONN WAFER YW025-07 (STICK)
P502 485923182S CONN WAFER YW025-05 (STICK)
P701 485923172S CONN WAFER YW025-04 (STICK)
ZZ200 PTMPJRG177 PCB MAIN RADIAL AS DLP-20J1LHS
C102 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
C106 CEXF1C220A C ELECTRO 16V RSM 22MF (5X7)
C121 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C205 CEXF1C220A C ELECTRO 16V RSM 22MF (5X7)
C230 CEXF1C220A C ELECTRO 16V RSM 22MF (5X7)
C232 CEXF1C220A C ELECTRO 16V RSM 22MF (5X7)
C238 CEXF1C220A C ELECTRO 16V RSM 22MF (5X7)
C249 CEXF1C220A C ELECTRO 16V RSM 22MF (5X7)
C261 CEXF1C220A C ELECTRO 16V RSM 22MF (5X7)
C508 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
C517 CEXF1C101A C ELECTRO 16V RSM 100MF 6X7 TP
C520 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
C524 CMXM2A682J C MYLAR 100V 6800PF J (TP)
C525 CEXF1H109A C ELECTRO 50V RSM 1MF (4X7) TP
C527 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
C529 CMXL1J334J C MYLAR 63V MEU 0.33MF J (TP)
C534 CEXF1H229A C ELECTRO 50V RSM 2.2MF (4X7) TP
C537 CEXF1H229A C ELECTRO 50V RSM 2.2MF (4X7) TP
C538 CEXF1H229A C ELECTRO 50V RSM 2.2MF (4X7) TP
C542 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
C543 CEXF1H229A C ELECTRO 50V RSM 2.2MF (4X7) TP
LOC PART CODE PART NAME DESCRIPTION REMARK
C545 CEXF1H229A C ELECTRO 50V RSM 2.2MF (4X7) TP
C547 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
C548 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
C558 CEXF1C101A C ELECTRO 16V RSM 100MF 6X7 TP
C559 CEXF1C101A C ELECTRO 16V RSM 100MF 6X7 TP
C563 CEXF1C101A C ELECTRO 16V RSM 100MF 6X7 TP
C567 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
C569 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
C577 CEXF1C101A C ELECTRO 16V RSM 100MF 6X7 TP
C583 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
C597 CEXF1C101A C ELECTRO 16V RSM 100MF 6X7 TP
C601 CEXF1H339V C ELECTRO 50V RSS 3.3MF (5X11) TP
C603 CEXF1C221V C ELECTRO 16V RSS 220MF (8X11.5) TP
C604 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C606 CEXF1E470V C ELECTRO RSS 25V 47MF 5X11 P5.0 TA
C608 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C624 CEXF1C101A C ELECTRO 16V RSM 100MF 6X7 TP
C626 CEXF1C101A C ELECTRO 16V RSM 100MF 6X7 TP
C703 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
C802 CEXF1H479A C ELECTRO 50V RSM 4.7MF 4X7
C806 CEXF1C101A C ELECTRO 16V RSM 100MF 6X7 TP
C814 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
C815 CEXF1H479A C ELECTRO 50V RSM 4.7MF 4X7
C827 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
C841 CEXF1H479A C ELECTRO 50V RSM 4.7MF 4X7
C842 CEXF1H479A C ELECTRO 50V RSM 4.7MF 4X7
C844 CEXF1H220V C ELECTRO 50V RSS 22MF (5X11) TP
C850 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
C851 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
C860 CEXF1H479A C ELECTRO 50V RSM 4.7MF 4X7
C861 CEXE1C471E C ELECTRO 16V RM 470MF (8X11.5) TP
C880 CEXF1C101A C ELECTRO 16V RSM 100MF 6X7 TP
C881 CEXE1C471E C ELECTRO 16V RM 470MF (8X11.5) TP
C890 CEXF1H479A C ELECTRO 50V RSM 4.7MF 4X7
C903 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
C905 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
C909 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
C917 CEXE1C471E C ELECTRO 16V RM 470MF (8X11.5) TP
CA25 CEXF1C101A C ELECTRO 16V RSM 100MF 6X7 TP
CA30 CEXF1C101A C ELECTRO 16V RSM 100MF 6X7 TP
CA35 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
CA67 CEXF1C101A C ELECTRO 16V RSM 100MF 6X7 TP
L206 5CPX479K-- COIL PEAKING 4.7UH K (RADIAL)
L209 58C0000116 COIL BEAD HC-3550R
L601 58C0000116 COIL BEAD HC-3550R
L807 58C0000116 COIL BEAD HC-3550R
L902 5CPX479K-- COIL PEAKING 4.7UH K (RADIAL)
LA10 58C0000116 COIL BEAD HC-3550R
LA32 5PXF1B471M FILTER EMI CFI 06 B 1H 470PF
LA33 5PXF1B471M FILTER EMI CFI 06 B 1H 470PF
LA35 5PXF1B471M FILTER EMI CFI 06 B 1H 470PF
LA36 5PXF1B471M FILTER EMI CFI 06 B 1H 470PF
LA37 5PXF1B471M FILTER EMI CFI 06 B 1H 470PF
LA38 5PXF1B471M FILTER EMI CFI 06 B 1H 470PF
LA41 5PXF1B471M FILTER EMI CFI 06 B 1H 470PF
LA42 5PXF1B471M FILTER EMI CFI 06 B 1H 470PF
Q813 T2SA1980Y- TR 2SA1980(N)Y
Q814 T2SC5343Y- TR 2SC5343(N)Y
Q815 T2SA1980Y- TR 2SA1980(N)Y
Q816 T2SC5343Y- TR 2SC5343(N)Y
SW701 5S50101Z90 SW TACT THVV502GDA
SW702 5S50101Z90 SW TACT THVV502GDA
SW703 5S50101Z90 SW TACT THVV502GDA
SW704 5S50101Z90 SW TACT THVV502GDA
SW705 5S50101Z90 SW TACT THVV502GDA
ZZ200 PTMPJAG177 PCB MAIN AXIAL AS DLP-20J1LHS
A001 4859805896 PCB MAIN 234X189 K4V
D101 D1N4148--- DIODE 1N4148 (TAPPING)
LOC PART CODE PART NAME DESCRIPTION REMARK
