-31-
Service part list
D102 DBA282---- DIODE BA282
D602 D1N4148--- DIODE 1N4148 (TAPPING)
DA28 85801060GY WIRE COPPER 1/0.6 TIN COATING
DA41 DUZ5R1B--- DIODE ZENER UZ-5.1B
DA42 DUZ5R1B--- DIODE ZENER UZ-5.1B
DA43 DUZ5R1B--- DIODE ZENER UZ-5.1B
DA44 DUZ5R1B--- DIODE ZENER UZ-5.1B
DA45 DUZ5R1B--- DIODE ZENER UZ-5.1B
L101 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
L203 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
L204 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
L205 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
L207 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
L208 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
L210 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
L213 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
L214 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
L505 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
L506 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
L507 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
L508 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
L509 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
L510 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
L512 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
L513 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
L514 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
L515 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
L516 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
L517 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
L518 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
L519 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
L523 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
L531 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
L851 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
L903 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
L904 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
L905 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
L906 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
LA43 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM)
LA44 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM)
LA451 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM)
LA461 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM)
R721 RD-AZ181J- R CARBON FILM 1/6 180 OHM J
R722 RD-AZ221J- R CARBON FILM 1/6 220 OHM J
R723 RD-AZ331J- R CARBON FILM 1/6 330 OHM J
R724 RD-AZ471J- R CARBON FILM 1/6 470 OHM J
R812 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R813 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
ZZ200 PTMPJ1G177
PCB MAIN CHIP MOUNT A AS
DLP-20J1LHS
10 2193220010 SOLDER CREAM(PB-FREE) LST309-M(SN+3.0AG/0.5CU)
C123 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
C201 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C204 HCQK150JBA C CHIP CERA 50V CH 15PF J 1608
C208 HCQK150JBA C CHIP CERA 50V CH 15PF J 1608
C209 HCBK223KBA C CHIP CERA 50V X7R 0.022MF K 1608
C212 HCQK150JBA C CHIP CERA 50V CH 15PF J 1608
C221 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C237 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C240 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C242 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C245 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C254 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C256 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C272 HCQK220JBA C CHIP CERA 50V CH 22PF J 1608
C273 HCQK220JBA C CHIP CERA 50V CH 22PF J 1608
C518 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C526 HCBH224KBA C CHIP CERA 25V X7R 0.22MF K 1608
C528 HCBK223KBA C CHIP CERA 50V X7R 0.022MF K 1608
LOC PART CODE PART NAME DESCRIPTION REMARK
C530 HCQK101JBA C CHIP CERA 50V CH 100PF J 1608
C531 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
C535 HCBH224KBA C CHIP CERA 25V X7R 0.22MF K 1608
C536 HCBH224KBA C CHIP CERA 25V X7R 0.22MF K 1608
C550 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
C553 HCBH224KBA C CHIP CERA 25V X7R 0.22MF K 1608
C554 HCBH224KBA C CHIP CERA 25V X7R 0.22MF K 1608
C557 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C560 HCBH224KBA C CHIP CERA 25V X7R 0.22MF K 1608
C561 HCBH224KBA C CHIP CERA 25V X7R 0.22MF K 1608
C571 HCQK470JBA C CHIP CERA 50V CH 47PF J 1608
C572 HCQK470JBA C CHIP CERA 50V CH 47PF J 1608
C573 HCQK470JBA C CHIP CERA 50V CH 47PF J 1608
C591 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C594 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C595 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C596 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C702 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C704 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C804 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C812 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C824 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C845 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C882 HCBK222KBA C CHIP CERA 50V X7R 2200PF K 1608
C883 HCQK101JBA C CHIP CERA 50V CH 100PF J 1608
C884 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
C885 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CA08 HCQK101JBA C CHIP CERA 50V CH 100PF J 1608
CA09 HCQK101JBA C CHIP CERA 50V CH 100PF J 1608
CA11 HCQK101JBA C CHIP CERA 50V CH 100PF J 1608
CA13 HCQK101JBA C CHIP CERA 50V CH 100PF J 1608
CA20 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CA29 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CA34 HCQK270JBA C CHIP CERA 50V CH 27PF J 1608
CA40 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CA44 HCBK471KBA C CHIP CERA 50V X7R 470PF K 1608
CA451 HCBK392KBA C CHIP CERA 50V X7R 3900PF K 1608
CA461 HCBK392KBA C CHIP CERA 50V X7R 3900PF K 1608
CA471 HCBK392KBA C CHIP CERA 50V X7R 3900PF K 1608
CA481 HCBK392KBA C CHIP CERA 50V X7R 3900PF K 1608
CA49 HCBK471KBA C CHIP CERA 50V X7R 470PF K 1608
CA50 HCBK471KBA C CHIP CERA 50V X7R 470PF K 1608
CA51 HCBK471KBA C CHIP CERA 50V X7R 470PF K 1608
CA77 HCBK472KBA C CHIP CERA 50V X7R 4700PF K 1608
D801 DBAV70---B DIODE CHIP BAV70
D805 DBAV70---B DIODE CHIP BAV70
D850 DM2FM3---C DIODE CHIP SCHOTTKY M2FM3 M2F TYPE
DA17 DZ02W5R6VA DIODE CHIP ZENER Z02W5.6V
DA18 DZ02W5R6VA DIODE CHIP ZENER Z02W5.6V
DA19 DZ02W5R6VA DIODE CHIP ZENER Z02W5.6V
DA25 DZ02W5R6VA DIODE CHIP ZENER Z02W5.6V
DA26 DZ02W5R6VA DIODE CHIP ZENER Z02W5.6V
DA27 DZ02W5R6VA DIODE CHIP ZENER Z02W5.6V
DA30 DZ02W5R6VA DIODE CHIP ZENER Z02W5.6V
DA32 DZ02W5R6VA DIODE CHIP ZENER Z02W5.6V
DA37 DZ02W5R6VA DIODE CHIP ZENER Z02W5.6V
DA38 DZ02W5R6VA DIODE CHIP ZENER Z02W5.6V
I402 1CD74HC52D IC CHIP LOGIC CD74HC4052M SOIC 16 REEL
I501 1TDA155F81 IC CHIP MICOM TDA15521E/N1/F81
I503 139VF0207Q IC CHIP FLASH MEMORY SST39VF020-70
I504 1TDA9178TE
IC CHIP PICTURE IMPROVEMENT
TDA9178TE
I508 1DTC34LF86 IC CHIP RECEIVER DTC34LF86A
I603 1TDA1308TC IC CHIP HEDPHONE DRIVER TDA1308T
I801 TFDS4953-C FET CHIP FDS4953 SO-8 -30V -5A REEL
I803 1AP117E33C IC CHIP REGULATOR AP1117E33A 3.3V SOT-223
I807 1BA6161F-C IC CHIP SW REG BA6161F 30~35V 100KHZ SOP8 REEL
I809 1AP117E18C IC CHIP REGULATOR AP1117E18A 1.8V SOT-223
I811 1AP117EA-C IC CHIP REGULATOR AP1117EA ADJ SOT-223
LOC PART CODE PART NAME DESCRIPTION REMARK
