Daewoo DLP-20D7 - Page 32

-32-
Service part list
I816 1LM317BD2E IC CHIP REGULATOR LM317BD2T ADJ 1.2V 37V 1.5A D2PAK
I820 TFDS4953-C FET CHIP FDS4953 SO-8 -30V -5A REEL
I851 1APW1172-D IC CHIP DC-DC CONVERTER APW1172
L806 HLC472M01D L CHIP COIL 4.7MH M SLF7045
L850 HLC100K01E L CHIP COIL 10UH K 120120
L920 HFRMZA600A F CHIP BEAD ARRARY 60 OHM MZA 3216Y
L921 HFRMZA600A F CHIP BEAD ARRARY 60 OHM MZA 3216Y
L922 HFRMZA600A F CHIP BEAD ARRARY 60 OHM MZA 3216Y
L923 HFRMZA600A F CHIP BEAD ARRARY 60 OHM MZA 3216Y
L924 HFRMZA600A F CHIP BEAD ARRARY 60 OHM MZA 3216Y
L925 HFRMZA600A F CHIP BEAD ARRARY 60 OHM MZA 3216Y
P902 4859297320 CONN WAFER 05002HR-50A01(G)
P905 4859297320 CONN WAFER 05002HR-50A01(G)
P906 4859200970 CONN WAFER SMD DF9B-41S-1V SMD
Q120 T2SC2412KB TR CHIP 2SC2412K-T146-BR
Q506 T2SC2412KB TR CHIP 2SC2412K-T146-BR
Q507 T2SA1037KB TR CHIP 2SA1037AKT146-R
Q508 T2SC2412KB TR CHIP 2SC2412K-T146-BR
Q602 T2SA1037KB TR CHIP 2SA1037AKT146-R
Q701 T2SC2412KB TR CHIP 2SC2412K-T146-BR
Q702 T2SC2412KB TR CHIP 2SC2412K-T146-BR
Q802 T2SC2412KB TR CHIP 2SC2412K-T146-BR
Q803 T2SC2412KB TR CHIP 2SC2412K-T146-BR
Q804 T2SC2412KB TR CHIP 2SC2412K-T146-BR
Q805 T2SC2412KB TR CHIP 2SC2412K-T146-BR
Q820 T2SC2412KB TR CHIP 2SC2412K-T146-BR
Q850 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QA04 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QA08 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QA12 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QA13 T2SA1037KB TR CHIP 2SA1037AKT146-R
QA21 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QA71 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QA72 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QA74 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QA75 T2SC2412KB TR CHIP 2SC2412K-T146-BR
R100 HRFT000-BA R CHIP 1/10 0 OHM 1608
R104 HRFT683JBA R CHIP 1/10 68K OHM J 1608
R105 HRFT103JBA R CHIP 1/10 10K OHM J 1608
R115 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R120 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R131 HRFT472JBA R CHIP 1/10 4.7K OHM J 1608
R135 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R140 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R141 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R143 HRFT102JBA R CHIP 1/10 1K OHM J 1608
R203 HRFT100JBA R CHIP 1/10 10 OHM J 1608
R204 HRFT470JBA R CHIP 1/10 47 OHM J 1608
R206 HRFT470JBA R CHIP 1/10 47 OHM J 1608
R207 HRFT100JBA R CHIP 1/10 10 OHM J 1608
R211 HRFT100JBA R CHIP 1/10 10 OHM J 1608
R212 HRFT470JBA R CHIP 1/10 47 OHM J 1608
R247 HRFT472JBA R CHIP 1/10 4.7K OHM J 1608
R248 HRFT472JBA R CHIP 1/10 4.7K OHM J 1608
R250 HRFT472JBA R CHIP 1/10 4.7K OHM J 1608
R251 HRFT472JBA R CHIP 1/10 4.7K OHM J 1608
R253 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R254 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R255 HRFT000-BA R CHIP 1/10 0 OHM 1608
R296 HRFT000-BA R CHIP 1/10 0 OHM 1608
R297 HRFT000-BA R CHIP 1/10 0 OHM 1608
R298 HRFT000-BA R CHIP 1/10 0 OHM 1608
R302 HRFT224JBA R CHIP 1/10 220K OHM J 1608
R303 HRFT224JBA R CHIP 1/10 220K OHM J 1608
R422 HRFT103JBA R CHIP 1/10 10K OHM J 1608
R504 HRFT152JBA R CHIP 1/10 1.5K OHM J 1608
R505 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R507 HRFT000-BA R CHIP 1/10 0 OHM 1608
LOC PART CODE PART NAME DESCRIPTION REMARK
R509 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R514 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R515 HRFT153JBA R CHIP 1/10 15K OHM J 1608
R516 HRFT153JBA R CHIP 1/10 15K OHM J 1608
R518 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R519 HRFT750JBA R CHIP 1/10 75 OHM J 1608
R521 HRFT103JBA R CHIP 1/10 10K OHM J 1608
R522 HRFT103JBA R CHIP 1/10 10K OHM J 1608
R529 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R530 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R531 HRFT181JBA R CHIP 1/10 180 OHM J 1608
R532 HRFT102JBA R CHIP 1/10 1K OHM J 1608
R533 HRFT102JBA R CHIP 1/10 1K OHM J 1608
R534 HRFT472JBA R CHIP 1/10 4.7K OHM J 1608
R538 HRFT473JBA R CHIP 1/10 47K OHM J 1608
R540 HRFT100JBA R CHIP 1/10 10 OHM J 1608
R541 HRFT393JBA R CHIP 1/10 39K OHM J 1608
R543 HRFT222JBA R CHIP 1/10 2.2K OHM J 1608
R545 HRFT473JBA R CHIP 1/10 47K OHM J 1608
R552 HRFT103JBA R CHIP 1/10 10K OHM J 1608
R553 HRFT103JBA R CHIP 1/10 10K OHM J 1608
R554 HRFT103JBA R CHIP 1/10 10K OHM J 1608
R555 HRFT103JBA R CHIP 1/10 10K OHM J 1608
R556 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R559 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R560 HRFT222JBA R CHIP 1/10 2.2K OHM J 1608
R561 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R565 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R566 HRFT103JBA R CHIP 1/10 10K OHM J 1608
R567 HRFT103JBA R CHIP 1/10 10K OHM J 1608
R568 HRFT103JBA R CHIP 1/10 10K OHM J 1608
R569 HRFT103JBA R CHIP 1/10 10K OHM J 1608
R574 HRFT103JBA R CHIP 1/10 10K OHM J 1608
R577 HRFT273JBA R CHIP 1/10 27K OHM J 1608
R581 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R592 HRFT102JBA R CHIP 1/10 1K OHM J 1608
R704 HRFT100JBA R CHIP 1/10 10 OHM J 1608
R705 HRFT223JBA R CHIP 1/10 22K OHM J 1608
R706 HRFT102JBA R CHIP 1/10 1K OHM J 1608
R708 HRFT104JBA R CHIP 1/10 100K OHM J 1608
R709 HRFT100JBA R CHIP 1/10 10 OHM J 1608
R710 HRFT202JBA R CHIP 1/10 2K OHM J 1608
R712 HRFT102JBA R CHIP 1/10 1K OHM J 1608
R715 HRFT472JBA R CHIP 1/10 4.7K OHM J 1608
R716 HRFT472JBA R CHIP 1/10 4.7K OHM J 1608
R720 HRFT122JBA R CHIP 1/10 1.2K OHM J 1608
R787 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R803 HRFT332JBA R CHIP 1/10 3.3K OHM J 1608
R804 HRFT123JBA R CHIP 1/10 12K OHM J 1608
R805 HRFT103JBA R CHIP 1/10 10K OHM J 1608
R807 HRFT103JBA R CHIP 1/10 10K OHM J 1608
R808 HRFT103JBA R CHIP 1/10 10K OHM J 1608
R809 HRFT103JBA R CHIP 1/10 10K OHM J 1608
R810 HRFT332JBA R CHIP 1/10 3.3K OHM J 1608
R811 HRFT123JBA R CHIP 1/10 12K OHM J 1608
R814 HRFT472JBA R CHIP 1/10 4.7K OHM J 1608
R815 HRFT472JBA R CHIP 1/10 4.7K OHM J 1608
R830 HRFT103JBA R CHIP 1/10 10K OHM J 1608
R831 HRFT393JBA R CHIP 1/10 39K OHM J 1608
R845 HRFT100JBA R CHIP 1/10 10 OHM J 1608
R846 HRFT103JBA R CHIP 1/10 10K OHM J 1608
R851 HRFT332JBA R CHIP 1/10 3.3K OHM J 1608
R852 HRFT123JBA R CHIP 1/10 12K OHM J 1608
R860 HRFT332JBA R CHIP 1/10 3.3K OHM J 1608
R861 HRFT123JBA R CHIP 1/10 12K OHM J 1608
R880 HRFT362JBA R CHIP 1/10 3.6K OHM J 1608
R881 HRFT202JBA R CHIP 1/10 2K OHM J 1608
R885 HRFT512JBA R CHIP 1/10 5.1K OHM J 1608
LOC PART CODE PART NAME DESCRIPTION REMARK
