Daewoo DLT-32C2 Service Manual

-55-
Service part list
R490 HRFT470JBA R CHIP 1/10 47 OHM J 1608
R496 HRFT103JBA R CHIP 1/10 10K OHM J 1608
R497 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R498 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R5 HRFT103JBA R CHIP 1/10 10K OHM J 1608
R501 HRFT103JBA R CHIP 1/10 10K OHM J 1608
R502 HRFT103JBA R CHIP 1/10 10K OHM J 1608
R507 HRFT470JBA R CHIP 1/10 47 OHM J 1608
R508 HRFT470JBA R CHIP 1/10 47 OHM J 1608
R509 HRFT470JBA R CHIP 1/10 47 OHM J 1608
R510 HRFT470JBA R CHIP 1/10 47 OHM J 1608
R511 HRFT470JBA R CHIP 1/10 47 OHM J 1608
R514 HRFT330JBA R CHIP 1/10 33 OHM J 1608
R515 HRFT330JBA R CHIP 1/10 33 OHM J 1608
R516 HRFT103JBA R CHIP 1/10 10K OHM J 1608
R517 HRFT472JBA R CHIP 1/10 4.7K OHM J 1608
R518 HRFT330JBA R CHIP 1/10 33 OHM J 1608
R519 HRFT330JBA R CHIP 1/10 33 OHM J 1608
R52 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R59 HRFT183JBA R CHIP 1/10 18K OHM J 1608
R6 HRFT103JBA R CHIP 1/10 10K OHM J 1608
R61 HRFT183JBA R CHIP 1/10 18K OHM J 1608
R7 HRFT183JBA R CHIP 1/10 18K OHM J 1608
R709 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R716 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R735 HRFT000JBA R CHIP 1/10 0 OHM J 1608
R82 HRFT473JBA R CHIP 1/10 47K OHM J 1608
R88 HRFT103JBA R CHIP 1/10 10K OHM J 1608
R98 HRFT101JBA R CHIP 1/10 100 OHM J 1608
ZZ200 PTMPJ0G261 PCB MAIN (RHU) AS DLT-26C2SMDB
CE30 CEXF1V471V C ELECTRO 35V RSS 470MF (10X20
CE31 CEXF1V471V C ELECTRO 35V RSS 470MF (10X20
CE36 CEXF1V471V C ELECTRO 35V RSS 470MF (10X20
CE45 CEXF1V471V C ELECTRO 35V RSS 470MF (10X20
CE56 CEXF1C471V C ELECTRO 16V RSS 470MF (8X12)
CE57 CEXF1C471V C ELECTRO 16V RSS 470MF (8X12)
CE58 CEXF1C471V C ELECTRO 16V RSS 470MF (8X12)
CE74 CEXF1C102V C ELECTRO 16V RSS 1000MF (10X2
ZZ200 PTMPJBG261 PCB MAIN M-10 AS DLT-26C2SMDB
P1 485923172S CONN WAFER YW025-04 (STICK)
P8 485923172S CONN WAFER YW025-04 (STICK)
ZZ200 PTMPJRG261 PCB MAIN RADIAL AS DLT-26C2SMDB
C199 CMXL1J334J C MYLAR 63V MEU 0.33MF J (TP
C215 CMXL1J334J C MYLAR 63V MEU 0.33MF J (TP
CE1 CEXF1H100A C ELECTRO 50V RSM 10MF (5X7) T
CE10 CEXF1C220V C ELECTRO RSS 16V 22MF 5*11
CE100 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE11 CEXF1H220V C ELECTRO 50V RSS 22MF (5X11)
CE12 CEXF1C221V C ELECTRO 16V RSS 220MF (8X11.
CE13 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE14 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE15 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE16 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE17 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE18 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE19 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE2 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) T
CE20 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE21 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE22 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE24 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE25 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE26 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE27 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE28 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11)
CE3 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE32 CEXF1E470V C ELECTRO RSS 25V 47MF 5X11 P5
CE33 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11)
LOC PART CODE PART NAME DESCRIPTION
CE34 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11)
CE35 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE37 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE38 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11)
CE39 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11)
CE4 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE40 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE41 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE42 CEXF1E470V C ELECTRO RSS 25V 47MF 5X11 P5
CE43 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11)
CE44 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11)
CE46 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE47 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11)
CE5 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE51 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE52 CEXF1C221V C ELECTRO 16V RSS 220MF (8X11.
CE53 CEXF1E221V C ELECTRO 25V RSS 220MF (8X11.
CE54 CEXF1C221V C ELECTRO 16V RSS 220MF (8X11.
CE55 CEXF1C221V C ELECTRO 16V RSS 220MF (8X11.
CE59 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE6 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE60 CEXF1C221V C ELECTRO 16V RSS 220MF (8X11.
CE61 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE62 CEXF1C221V C ELECTRO 16V RSS 220MF (8X11.
CE63 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X1
CE64 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE65 CEXF1H100A C ELECTRO 50V RSM 10MF (5X7) T
CE66 CEXF1C101A C ELECTRO 16V RSM 100MF 6X7 TP
CE67 CEXF1E221V C ELECTRO 25V RSS 220MF (8X11.
CE68 CEXF1C221V C ELECTRO 16V RSS 220MF (8X11.
CE69 CEXF1C221V C ELECTRO 16V RSS 220MF (8X11.
CE7 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE70 CEXF1C221V C ELECTRO 16V RSS 220MF (8X11.
CE700 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE701 CEXF1H479A C ELECTRO 50V RSM 4.7MF 4X7
CE702 CEXF1H479A C ELECTRO 50V RSM 4.7MF 4X7
CE71 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE72 CEXF1C221V C ELECTRO 16V RSS 220MF (8X11.
CE73 CEXF1C221V C ELECTRO 16V RSS 220MF (8X11.
CE75 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE76 CEXF1C221V C ELECTRO 16V RSS 220MF (8X11.
CE77 CEXF1C221V C ELECTRO 16V RSS 220MF (8X11.
CE78 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE79 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE8 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X1
CE80 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE81 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE82 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE83 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE84 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE85 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE86 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE87 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE88 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11)
CE89 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X1
CE9 CEXF1C220V C ELECTRO RSS 16V 22MF 5*11
CE90 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X1
CE91 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X1
CE92 CEXF1E470V C ELECTRO RSS 25V 47MF 5X11 P5
CE93 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) T
CE94 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) T
CE95 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11)
CE96 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11)
CE97 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE98 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
CE99 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11)
L28 5CPX829K— COIL PEAKING 8.2UH K (RADIAL)
SW1 5S50101Z90 SW TACT THVV502GDA
LOC PART CODE PART NAME DESCRIPTION
