Daewoo DLT-32C2 Service Manual

-56-
Service part list
LOC PART CODE PART NAME DESCRIPTION
U15 1K1A7042AP IC RESET KIA7042AP
U70 1K1A7042AP IC RESET KIA7042AP
U9 1K1A7042AP IC RESET KIA7042AP
X1 5XE4R0000C CRYSTAL QUARTZ HC-49/U 4.000MHZ 20P
Z3 5PXXT5R5MB FILTER CERA XT 5.5MHZ-TP
ZZ200 PTMPJAG261 PCB MAIN AXIAL AS DLT-26C2SMDB
ZZ200 PTMPJ1G261 PCB MAIN CHIP A AS DLT-26C2SMDB
110 2193220010 SOLDER CREAM(PB-FREE LST309-M(SN+3.0AG/0.
A001 4859816093 PCB MAIN 234X288(1X1)T1.6
C1 HCQK101JBA C CHIP CERA 50V CH 100PF J 1608
C101 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C102 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C103 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C104 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C106 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C107 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C108 HCBK473KBA C CHIP CERA 50V X7R 0.047MF K 16
C109 HCBK102KBA C CHIP CERA 50V X7R 1000PF K 160
C11 HCQK220JBA C CHIP CERA 50V CH 22PF J 1608
C110 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C111 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C112 HCBK473KBA C CHIP CERA 50V X7R 0.047MF K 16
C113 HCBK473KBA C CHIP CERA 50V X7R 0.047MF K 16
C114 HCBK102KBA C CHIP CERA 50V X7R 1000PF K 160
C115 HCBK473KBA C CHIP CERA 50V X7R 0.047MF K 16
C116 HCBK473KBA C CHIP CERA 50V X7R 0.047MF K 16
C117 HCBK473KBA C CHIP CERA 50V X7R 0.047MF K 16
C118 HCBK473KBA C CHIP CERA 50V X7R 0.047MF K 16
C119 HCBK102KBA C CHIP CERA 50V X7R 1000PF K 160
C120 HCBK473KBA C CHIP CERA 50V X7R 0.047MF K 16
C121 HCBK473KBA C CHIP CERA 50V X7R 0.047MF K 16
C122 HCBK473KBA C CHIP CERA 50V X7R 0.047MF K 16
C123 HCBK473KBA C CHIP CERA 50V X7R 0.047MF K 16
C124 HCBK473KBA C CHIP CERA 50V X7R 0.047MF K 16
C125 HCBK473KBA C CHIP CERA 50V X7R 0.047MF K 16
C126 HCBK473KBA C CHIP CERA 50V X7R 0.047MF K 16
C127 HCBK473KBA C CHIP CERA 50V X7R 0.047MF K 16
C128 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C130 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C131 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C133 HCBK473KBA C CHIP CERA 50V X7R 0.047MF K 16
C134 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C135 HCBK473KBA C CHIP CERA 50V X7R 0.047MF K 16
C137 HCBK473KBA C CHIP CERA 50V X7R 0.047MF K 16
C138 HCBK473KBA C CHIP CERA 50V X7R 0.047MF K 16
C139 HCBK473KBA C CHIP CERA 50V X7R 0.047MF K 16
C140 HCBK473KBA C CHIP CERA 50V X7R 0.047MF K 16
C141 HCBK473KBA C CHIP CERA 50V X7R 0.047MF K 16
C142 HCBK473KBA C CHIP CERA 50V X7R 0.047MF K 16
C143 HCBK473KBA C CHIP CERA 50V X7R 0.047MF K 16
C144 HCBK473KBA C CHIP CERA 50V X7R 0.047MF K 16
C146 HCBK473KBA C CHIP CERA 50V X7R 0.047MF K 16
C147 HCBK473KBA C CHIP CERA 50V X7R 0.047MF K 16
C148 HCBK473KBA C CHIP CERA 50V X7R 0.047MF K 16
C149 HCBK473KBA C CHIP CERA 50V X7R 0.047MF K 16
C151 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C153 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C154 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C155 HCBD105KBA C CHIP CERA 10V X7R 1MF K 1608
C156 HCFD225ZBA C CHIP CERA 10V Y5V 2.2MF Z 1608
C157 HCFD225ZBA C CHIP CERA 10V Y5V 2.2MF Z 1608
C158 HCBD105KBA C CHIP CERA 10V X7R 1MF K 1608
C159 HCFD225ZBA C CHIP CERA 10V Y5V 2.2MF Z 1608
C160 HCFD225ZBA C CHIP CERA 10V Y5V 2.2MF Z 1608
C161 HCFD225ZBA C CHIP CERA 10V Y5V 2.2MF Z 1608
C162 HCFD225ZBA C CHIP CERA 10V Y5V 2.2MF Z 1608
C169 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C170 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C173 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C174 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C175 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C18 HCQK101JBA C CHIP CERA 50V CH 100PF J 1608
C180 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C181 HCBK102KBA C CHIP CERA 50V X7R 1000PF K 160
C2 HCBK102KBA C CHIP CERA 50V X7R 1000PF K 160
C204 HCBK221KBA C CHIP CERA 50V X7R 220PF K 1608
C21 HCBK102KBA C CHIP CERA 50V X7R 1000PF K 160
C222 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C225 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C228 HCBK222KBA C CHIP CERA 50V X7R 2200PF K 160
C23 HCBD105KBA C CHIP CERA 10V X7R 1MF K 1608
C232 HCQK101JBA C CHIP CERA 50V CH 100PF J 1608
C233 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 160
C24 HCBD105KBA C CHIP CERA 10V X7R 1MF K 1608
C243 HCQK101JBA C CHIP CERA 50V CH 100PF J 1608
C244 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 160
C245 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C25 HCBD105KBA C CHIP CERA 10V X7R 1MF K 1608
C26 HCQK100JBA C CHIP CERA 50V CH 10PF J 1608
C27 HCBD105KBA C CHIP CERA 10V X7R 1MF K 1608
C273 HCBD105KBA C CHIP CERA 10V X7R 1MF K 1608
C274 HCBD105KBA C CHIP CERA 10V X7R 1MF K 1608
C28 HCBD105KBA C CHIP CERA 10V X7R 1MF K 1608
C284 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C287 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C29 HCBD105KBA C CHIP CERA 10V X7R 1MF K 1608
C295 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C296 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C300 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C305 HCQK220JBA C CHIP CERA 50V CH 22PF J 1608
C352 HCQK101JBA C CHIP CERA 50V CH 100PF J 1608
C353 HCQK101JBA C CHIP CERA 50V CH 100PF J 1608
C4 HCQK101JBA C CHIP CERA 50V CH 100PF J 1608
C42 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C43 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C44 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C45 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C46 HCQK101JBA C CHIP CERA 50V CH 100PF J 1608
C5 HCBK102KBA C CHIP CERA 50V X7R 1000PF K 160
C50 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 160
C52 HCFF474ZBA C CHIP CERA Y5V 16V 0.47MF Z 160
C55 HCBH224KBA C CHIP CERA 25V X7R 0.22MF K 160
C56 HCQK220JBA C CHIP CERA 50V CH 22PF J 1608
C57 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 160
C6 HCBK102KBA C CHIP CERA 50V X7R 1000PF K 160
C64 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 160
C67 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C68 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C69 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C70 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C700 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C701 HCBK392KBA C CHIP CERA 50V X7R 3900PF K 160
C702 HCBK392KBA C CHIP CERA 50V X7R 3900PF K 160
C71 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C72 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C73 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C74 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C75 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C76 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C77 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C78 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C79 HCBK102KBA C CHIP CERA 50V X7R 1000PF K 160
C80 HCQK180JBA C CHIP CERA 50V CH 18PF J 1608
C81 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C88 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C89 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C9 HCQK100JBA C CHIP CERA 50V CH 10PF J 1608
C91 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C92 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C93 HCQK180JBA C CHIP CERA 50V CH 18PF J 1608
LOC PART CODE PART NAME DESCRIPTION

Daewoo DLT-32C2 Specifications

General

Brand	Daewoo
Model	DLT-32C2
Category	LCD TV
Language	English
