◆The Electrical Specification of Oxygen Generation System
Model name
SPECIFICATION
DSB-071AH DSB-092AH/123AH DSB-093AH/123AH
DSB-240A-R/AH-R, DSA-240A-R/AH-R/AH
Cylinder Type Plate Type
Data Data Data Data
Control relay Model name CS11-12SH CS11-12SH CS11-12SH CS11-12SH
Coil voltage DC12V DC12V DC12V DC12V
Contact AC250V 5A AC250V 5A AC250V 5A AC250V 5A
Fuse Model name 50T 50T 50T 50T
Type Time delay type Time delay type Time delay type Time delay type
Voltage AC250V AC250V AC250V AC250V
Ampare 3.15A 3.15A 3.15A 3.15A
Transformer Model name DWA-240V DWA-240V DWA-240V DWA-240V
Power
Pri. AC220~240V 50Hz AC220~240V 50Hz AC220~240V 50Hz AC220~240V 50Hz
Sec. AC15V AC15V AC15V AC15V
Safety device Fuse Fuse Fuse Fuse
Model name AC130 AC130 AC130 AC130
Voltage AC250V AC250V AC250V AC250V
Ampare 1A 1A 1A 1A
Vaccum Model name DAL-5S DAL-5S DAL-5S - DAL-5S
pump Power 1P 220V 50Hz 1P 220V 50Hz 1P 220V 50Hz - 1P 220V 50Hz
Out put 10W 10W 10W - 10W
Capacitor 4uF 220VAC 4uF 220VAC 4uF 220VAC - 4uF 220VAC
main 530Ω 530Ω 530Ω -530Ω
sub 270Ω 270Ω 270Ω -270Ω
Safety device Thermal protector Thermal protector Thermal protector - Thermal protector
Model name ST-22 ST-22 ST-22 - ST-22
Open temp. 135°C 135°C 135°C - 135°C
Close temp. 90°C90°C90°C-90°C
Air Model name - - - - PM18213-NPK09 -
compressor Power - - - - 1P 230V 50Hz -
Out put - - - - 20W -
Capacitor - - - - 2uF 450VAC -
main - - - - -
sub - - - - -
Safety device - - - - Thermal protector -
Model name - - - - 2MMT -
Open temp. - - - - 140°C-
Close temp. - - - - 90°C-
Solenoid Model name - - - - SLVASOA220 -
valve Coil Power - - - - AC220V 50/60Hz -
Ampare - - - - 0.45A -
Winding resistance at 20°C
- - - - 1,650Ω -
Valve
Oriffice diameter
----ø1.9 -
Operating air pressure
- AC Type DC Type - 0~21Kgf/cm
3
-
AC Axial Model name - A8025H22B - - - -
fan motor Power - 1P 220~230V 50/60Hz - - - -
Speed - 2,900rpm - - - -
DC Axial Model name F410H120S - F410H120S F410H120S - F410H120S
fan motor Power DC12V - DC12V DC12V - DC12V
Speed 6,000rpm - 6,000rpm 6,000rpm - 6,000rpm
Component Name
Specification
Winding
resistance
at 20°C
Winding
resistance
at 20°C
43
DSB-182A-R/AH-R/183AH
DSA-183AH-R
