44
◆The Electrical Specification of Plasma System
Model name
SPECIFICATION
9K/12K 18K 24K
Component Name Specification Data Data Data
Control relay Model name CS11-12SH CS11-12SH CS11-12SH
Coil voltage DC12V DC12V DC12V
Contact AC250V 5A AC250V 5A AC250V 5A
Fuse Model name 50T 50T 50T
Type Time delay type Time delay type Time delay type
Voltage AC250V AC250V AC250V
Ampare 3.15A 3.15A 3.15A
Filter power Model name Filter power1 Filter power2 Filter power2
Power AC220~240V 50Hz AC220~240V 50Hz AC220~240V 50Hz
Ampare 10A 16A 16A
Inductance factor 6,400nH/N2 6,500pH/N2 6,500pH/N2
Ferrite core size OD29xID18xH15 OD36xID23xH15 OD36xID23xH15
Filter PCB Model name Filter PCB1 Filter PCB2 Filter PCB3
Power AC220~240V 50Hz AC220~240V 50Hz AC220~240V 50Hz
Ampare 1A 1A 2A
Inductance at 1KHz 15mH 15mH 5mH
High voltage Model name NAHG-003 NAHG-004 NAHG-005/NAHG-006
generator Power AC220~240V 50Hz AC220~240V 50Hz AC220~240V 50Hz
Out voltage DC5.6KV(+3.6KV, -2.0KV) DC5.6KV(+3.6KV, -2.0KV) DC5.6KV(+3.6KV, -2.0KV)
Micro switch Model name SZM-V16-2FA-63/MS1115 SZM-V16-2FA-63/MS1115 SZM-V16-2FA-63/MS1115
Tppe SPST SPST SPST
Voltage AC250V AC250V AC250V
Ampare 16A / 15A 16A / 15A 16A / 15A
