(5) U9 (KIA7042P) : RESET IC
(6) U5 (TSA3100J) : PHOTO TRIAC
KIA70
42P
OUTLINE
INPUT
GROUND
OUTPUT
VCC
!
#
@
OUT
GND
4
5
1
2
3
1. AC output (MT2)
2. AC output (MT1)
3. GATE
4. DC input (+)
5. DC input (-)
