¡ DSB-090L/DSB-120L/DSA-100L/DSA-120L PARTS LIST(INDOOR UNIT)
No PART CODE PART NAME Q'TY SPEC REMARK
1 3100400201 BODY 1 ABS or HIPS
2 3108001200 MOTOR FCU 1 220V 50/60Hz
3 3101500400 CUSHION MOTOR 2 CR
4 3106400200 BEARING PLASTIC ASS'Y 1
5 3100014400 C.F.F. ASS'Y 1 SAN+G. F20%
6 7485401012 SET SCREW 1 6S-4 X 10-E
7 3100014300 EVA. ASS'Y 1
8 3108100401 PAN DRAIN 1 ABS
9 3106500800 BLADE VERTICAL MN 12 ABS
10 3106300800 BAR BLADE 2 ABS
11 3100700800 BUSHING L 1 POM
12 3100700700 BUSHING R 1 POM
13 3107600300 FLAP 1 ABS
14 3108000100 MOTOR STEPPING 1 MG28GA
15 3100017500 CONTROL BOX ASS'Y 1 BUYER
15-1 3100503101 BOX CONTROL 1 P.P+G.F20%
15-2 5EPV050100 TRANS 1 DWA220A-50/60Hz
15-3 3106900300 CAPACITOR SH.M.B 1 1.0µF 400VAC
15-4 3104397100 CONTROL PCB ASS'Y 1 FR-4
15-5 3104397200 LED PCB ASS'Y 1 FR-4
15-6 3108901120 TERMINAL BLOCK 1 323-HDS106
15-7 3104896300 SENSOR I.D ASS'Y 1 PTM-KD43C-D2
15-8 3102797900 HARNESS 1 I.D EARTH
15-9 3103400300 KNOB RESET SWITCH 1 ABS
15-10 3100024000 MODE SELECT ASS'Y 1 TS-11 & HARNESS
15-11 3101397130 POWER CORD ASS'Y 1 BUYER
15-12 7111301611 TAPPING SCREW 2 TIS PAN 3 X 16 MFZN
16 3102200401 FRAME 1 ABS
17 3103600300 LAMP INDICATE 1 MIPS
18 3105500500 WINDOW SENSOR 1 ACRIL
19 3100901000 CAP FRAME L 1 ABS
20 3100900900 CAP FRAME C 1 ABS
21 3100900800 CAP FRAME R 1 ABS
22 3101401701 COVER TER-BLOCK 1 ABS
23 3100017800 FILTER ELECTRO ASS'Y 1
24 3100017900 FILTER CARBON ASS'Y 1
25 3100017700 FILTER PRE ASS'Y 2
26 3108400110 REMOCON ASS'Y 1 BUYER
27 3102401500 INSERT GRILLE 1 ABS
28 3107500200 EMBLEM 1 URETANE
29 3100602400 BRACKET PIPE 1 HIPS
30 3101201200 CLAMP BRACKET PIPE 1 HIPS
31 3104503900 PLATE MOUNTING 1 SBHG1
32 3106001600 SPECIAL SCREW 1
T2 4 X 16 MFNI LOCKING
33 7S422 X 40B1 SPECIAL SCREW 13
TT2 TRS SE 4 X 12 MFZN
ƒINO 15, 15-11, 16, 26, 28 Will be changed depend on export destination & buyer requirements.
To Next Page
