Daewoo DSC-097L User Manual

5.Loosen the earth screw in
evaporator.
8.Separate the electrical box
from the indoor unit.
4.Take all the connector of the
PCB upper side out.
3.Loosen the screw of the
inside terminal board ,
separate the board.
6.Pull softly the indoor pipe
temperature sensor out from
the pipe casing.
No Parts Procedure Remark
2.Loosen the screw of the
inside terminal board ,
separate the board.
7.Push the hook outside to take
the electrical box out easily.
DISASSEMBLY AND REASSEMBLY
1010
