Exploded Views and Parts List
1818
Outdoor unit
Model :DSC-097L
Model :DSC-127L
NO. Part Name Quantity Item Code
1 Air outlet grille 1 KFR20W.1.1-2
2 Front panel 1 KFR20W.1.1-1
3 Left handle 1 SL05-01
4 Top panel 1 KFR20W.1.2-1
5 Fan screw nut M6 (left revolve) 1 GB41-86
6 Outdoor fan 1 KFR20W.1.5.1
7 Outdoor fan motor 1 DQ01-09C
8 Outdoor fan motor supporter 1 KFR20W.1.5-1
9 Condenser 1 AU09CR61FG4.2.1A
10 Partition 1 KFR20W.1.6-1
11 Electrical install board supporter 1 KFR20W.3.2-2
12 Left back side board 1 KFR20W.1.2-2
13 Back cover 1 KFR20W.1.2-9
14 Right back side board 1 KFR20W.1.1-3
15 Electrical install board 1 KFR20W.3.2-1
16 Capacitor fixer 1 BJ06-01
17 Outdoor unit terminal block 1 DQ12-02
18 Power supply cord clip 1 SL01-04
19 Compressor capacitor 1 DQ11-52
20 Fan motor capacitor 1 DQ11-11
21 Capillary 1 AU09CR61FG4.2.1.2A
22 High pressure value 1 DG03-12
23 Low pressure value 1 DG03-02
24 Valve board 1 KFR35W.1.3-3
25 Compressor screw 3 LD06-01
26 Compressor 1 AU09HR61FG4.2.4A
27 1 AU09CR61FG4.2.1.4A
28 Back board 1 KFR25W.1.3(G1-4)
29 Right handle 1 SL05-02
30 1 AU09CR61FG4.2.1.3A
