Daewoo DSC-1245FL - Page 21

Air Conditioner Service Manual
Outdoor unit:
Model: DSC-1285FLH
No.
Part No.
Part Name
Q’ty
Remark
1
Back Grille
1
Optional
2
Top Cover
1
3
Condenser
1
4
Outdoor Motor Supporter
1
5
Outdoor Motor
1
6
Propeller Fan
1
7
Left Grille Supporter
1
8
Front Plate
1
9
Fan Guard
1
10
Compressor And It Accessories
1
11
4-way Valve
1
12
4-way Valve Assembly
1
13
Base
1
14
Right Plate
1
15
Two-way Valve
1
16
Valve Supporter
1
17
Three-way Valve
1
18
Electrical Box Cover
1
19
Cable Clamp(
φ
6)
1
20
Cable Clamp(
φ
8)
1
21
Terminal
1
22
Fan Motor Capacitor
1
23
Compressor Capacitor
1
24
Capacitor Strip
1
25
Electrical Parts Box
1
26
Capillary Assembly
1
27
Partition plate
1
28
Outdoor Sensor
1
Not shown in the Explosion view.
29
Base Carton
1
30
Cabinet Carton
1
31
Base Foam
1
32
Cover Form
1
20
