Rear Panel
1 RF IN
; connects your aerial.
2 Audio L/R
; connects to your TV or VCR and outputs audio signals.
3 T V Scart
; connects a T V SCART cable.
4 RF OUT
; connects an RF to the RF (ANT) input on your TV or VCR.
5 S/PDIF
; outputs the digital audio signals.
6 VCR/DVD SCART
; connects to your VCR/DVD.
