8. IC Voltage Chart
Model : DV-115
2. IC403 A43L0616AV-7
PIN PLAY STOP PIN PLAY STOP PIN PLAY STOP PIN PLAY STOP
1 3.3 3.3 14 0.0 0.0 27 0.7 0.0 40 1.0 3.3
2 1.0 0.6 15 3.3 3.3 28 0.7 0.0 41 0.0 0.0
3 1.2 0.6 16 3.3 3.3 29 0.5 0.0 42 0.9 0.5
4 0.0 0.0 17 0.0 0.0 30 0.5 0.0 43 1.0 0.6
5 1.0 0.5 18 0.8 0.0 31 0.4 0.0 44 3.3 3.3
6 1.0 0.6 19 0.8 0.0 32 0.4 0.0 45 1.1 0.5
7 3.3 3.3 20 2.0 2.5 33 0.0 0.0 46 1.5 0.5
8 0.9 0.6 21 0.4 0.0 34 3.3 3.3 47 0.0 0.0
9 0.6 0.6 22 0.4 0.0 35 1.6 1.6 48 1.0 0.6
10 0.0 0.0 23 0.4 0.0 36 0.0 0.0 49 1.0 0.8
11 0.8 0.6 24 0.7 0.7 37 0.0 0.0 50 0.0 0.0
12 1.0 0.6 25 3.3 3.3 38 3.3 3.3
13 3.3 3.3 26 0.0 0.0 39 1.1 0.6
3. IC409 ZR36701
PIN PLAY STOP PIN PLAY STOP PIN PLAY STOP PIN PLAY STOP
1 4.9 4.9 17 2.5 33 4.9 4.9 49 4.9 5.0
2 18 2.5 34 2.0 50 4.9 5.0
3 19 2.5 4.9 35 4.9 5.0 51 4.9 5.0
4 20 36 4.9 5.0 52 4.9 4.9
5 21 2.5 4.9 37 4.9 5.0 53 4.9 5.0
6 4.9 4.9 22 2.5 4.9 38 4.9 5.0 54 4.9 4.9
7 23 2.5 39 4.9 5.0 55 4.9 4.9
8 1.7 1.7 24 4.9 4.9 40 4.9 5.0 56 4.9 4.9
9 25 2.5 41 57
10 4.9 4.9 26 2.5 42 4.9 5.0 58
11 4.9 4.9 27 3.0 3.3 43 4.9 5.0 59
12 28 44 4.9 5.0 60
13 29 1.7 1.7 45 4.9 5.0 61
14 4.9 4.9 30 46 62 4.9 4.9
15 31 4.9 4.9 47 4.9 5.0 63 4.9 4.9
16 32 4.9 4.9 48 4.9 5.0 64
4. IC406 A617308S
PIN PLAY STOP PIN PLAY STOP PIN PLAY STOP PIN PLAY STOP
1 4.0 4.0 9 2.4 2.4 17 2.5 2.5 25 2.2 2.2
2 4.0 4.0 10 2.4 2.4 18 2.5 2.5 26 2.5 2.5
3 4.3 4.3 11 2.5 2.5 19 2.0 2.0 27 2.5 2.5
4 2.9 2.9 12 2.2 2.2 20 2.0 2.0 28 1.7 1.7
5 2.5 2.5 13 1.8 1.8 21 2.5 2.5 29 5.0 5.0
6 2.9 2.9 14 2.2 2.2 22 0.0 0.0 30 5.0 5.0
7 2.0 2.0 15 2.5 2.5 23 2.4 2.4 31 4.0 4.0
8 2.5 2.5 16 0.0 0.0 24 3.5 3.5 32 5.0 5.0
8. IC Voltage Chart
Model : DV-115
11 11
1. IC402 ZR36710
PIN PLAY STOP PIN PLAY STOP PIN PLAY STOP PIN PLAY STOP
1 0.0 0.0 41 0.0 0.0 81 0.0 0.0 121 0.0 0.0
2 0.0 0.0 42 0.7 0.0 82 1.0 0.6 122 0.0 0.0
3 2.8 2.8 43 0.4 0.0 83 3.3 3.3 123 0.0 0.0
4 2.8 2.8 44 0.5 0.0 84 1.7 1.7 124 1.7 1.7
5 2.8 2.8 45 0.4 0.0 85 3.3 3.3 125 0.0 0.0
6 2.8 2.8 46 0.5 0.0 86 3.3 3.3 126 1.5 1.5
7 3.3 3.3 47 0.4 0.0 87 0.0 0.0 127 0.0 0.0
8 3.3 3.3 48 3.3 3.3 88 1.4 1.2 128 1.3 1.3
9 2.8 2.8 49 0.4 0.0 89 3.2 3.2 129 1.5 1.5
10 2.8 2.8 50 2.0 2.5 90 3.0 3.0 130 5.0 5.0
11 2.8 2.8 51 0.4 0.0 91 1.6 1.6 131 0.0 0.0
12 2.5 2.5 52 0.8 0.0 92 1.5 2.0 132 1.7 1.7
13 0.0 0.0 53 0.0 0.0 93 0.0 0.0 133 3.3 3.3
14 2.1 2.1 54 3.0 3.3 94 1.5 1.5 134 0.0 0.0
15 2.6 2.6 55 3.1 3.3 95 1.0 1.0 135 0.0 0.0
16 2.6 2.6 56 3.1 3.3 96 1.7 1.7 136 1.9 1.9
17 2.6 2.6 57 1.5 0.0 97 1.0 1.0 137 0.0 0.0
18 3.3 3.3 58 3.3 3.3 98 3.3 3.3 138 3.3 3.3
19 2.3 2.3 59 3.2 3.2 99 1.0 1.0 139 3.3 3.3
20 2.2 2.2 60 3.1 3.3 100 1.0 1.0 140 3.3 3.3
21 1.8 1.8 61 0.0 0.0 101 1.0 1.0 141 5.0 5.0
22 2.3 2.6 62 1.1 0.6 102 0.0 0.0 142 0.0 3.3
23 0.0 0.0 63 3.3 3.3 103 3.3 3.3 143 0.0 0.0
24 2.5 2.3 64 1.0 0.6 104 0.0 0.0 144 4.0 4.0
25 2.5 2.5 65 1.0 3.3 105 0.0 0.0 145 0.0 0.0
26 2.5 2.5 66 0.8 0.8 106 0.0 0.0 146 4.3 5.0
27 5.0 5.0 67 0.9 0.5 107 0.0 0.0 147 1.7 1.7
28 3.3 3.3 68 0.0 0.0 108 0.0 0.0 148 2.0 3.3
29 5.0 5.0 69 0.6 0.6 109 0.0 0.0 149 2.5 5.0
30 3.3 3.6 70 1.0 0.6 110 0.0 0.0 150 3.3 3.3
31 1.0 1.0 71 0.9 0.6 111 0.0 0.0 151 2.3 0.0
32 3.3 3.3 72 1.1 0.5 112 0.0 0.0 152 2.3 0.0
33 3.3 3.3 73 3.3 3.3 113 3.3 3.3 153 2.3 5.0
34 5.0 5.0 74 1.0 0.6 114 1.1 0.0 154 2.3 5.0
35 0.0 0.0 75 1.5 0.5 115 0.0 0.0 155 3.3 3.3
36 0.0 0.0 76 1.0 0.5 116 0.0 0.0 156 2.3 0.0
37 3.3 3.3 77 1.0 0.6 117 1.6 1.6 157 2.3 5.0
38 0.7 0.0 78 1.2 0.6 118 1.6 1.6 158 2.3 0.0
39 0.7 0.7 79 1.0 0.8 119 1.6 1.6 159 0.0 0.0
40 0.0 0.0 80 0.0 0.0 120 0.0 0.0 160 0.0 0.0
