Daewoo DV - 115 - Page 13

13. Electrical Parts List
Model : DV-115
1 CORD AC AC901 9736908600 KE-25 H03VVH2-F 1820MM 50 C ELECTRO C552L/R CEXF1H339E 50V RM 3.3MF (5X11) TP
2 CONN FFC CN913 9728809200 FFC 1.25X17X110MM K 51 C CHIP CERA C553 HCQK681JBA 50V CH 680PF J 1608
3 TUNER MODULE TU001 9737650201 KST-MB114MA1-0(RDS) 52 C ELECTRO C554 CEXF1E101E 25V RM 100MF (6.3X11) TP
1 PCB DSP AS 13000 9CDC059000 DV-115 53 C CHIP CERA C555 HCQK681JBA 50V CH 680PF J 1608
2 PCB DSP B001 9CD6583900 170X260 54 C ELECTRO C556 CEXF1E101E 25V RM 100MF (6.3X11) TP
3 C ELECTRO C501 CEXF1E470E 25V RM 47MF (5X11) 55 C CHIP CERA C557~562 HCQK681JBA 50V CH 680PF J 1608
4 C CHIP CERA C502 HCBK104KBA 50V X7R 0.1MF K 1608 56 C ELECTRO C563 CEXF1H100E 50V RM 10MF (5X11) TP
5 C CHIP CERA C503 HCQK220JBA 50V CH 22PF J 1608 57 C CHIP CERA C564 HCBK104KBA 50V X7R 0.1MF K 1608
6 C ELECTRO C504 CEXF1E470E 25V RM 47MF (5X11) 58 C ELECTRO C565~566L/R CEXF1H100E 50V RM 10MF (5X11) TP
7 C CHIP CERA C505 HCBK104KBA 50V X7R 0.1MF K 1608 59 C ELECTRO C566 CEXF1H109E 50V RM 1MF (5X11) TP
8 C CHIP CERA C506 HCQK220JBA 50V CH 22PF J 1608 60 C CHIP CERA C567 HCBK104KBA 50V X7R 0.1MF K 1608
9 C CHIP CERA C507 HCBK104KBA 50V X7R 0.1MF K 1608 61 C ELECTRO C570L/R~571L/R CEXF1H100E 50V RM 10MF (5X11) TP
10 C CHIP CERA C508~509 HCQK220JBA 50V CH 22PF J 1608 62 C CHIP CERA C572L/R HCBK102KBA 50V X7R 1000PF K 1608
11 C ELECTRO C510 CEXF1H108E 50V RM 0.1MF (5X11) TP 63 C ELECTRO C578 CEXF1H100E 50V RM 10MF (5X11) TP
12 C CHIP CERA C511~512 HCBK104KBA 50V X7R 0.1MF K 1608 64 C ELECTRO C579A/B/C/L/R/W CEXF1H100E 50V RM 10MF (5X11) TP
13 C ELECTRO C513~514 CEXF1E470E 25V RM 47MF (5X11) 65 C CHIP CERA C580A/B/C/L/R/W HCQK681JBA 50V CH 680PF J 1608
14 C CHIP CERA C513L/R HCQK222JBA 50V CH 2200PF J 1608 66 C CHIP CERA C581A/B/C/L/R/W HCQK681JBA 50V CH 680PF J 1608
15 C ELECTRO C514L/R CEXF1E101E 25V RM 100MF (6.3X11) TP 67 C ELECTRO C582A/B/C/L/R/W CEXF1H100E 50V RM 10MF (5X11) TP
16 C CHIP CERA C515~517 HCBK104KBA 50V X7R 0.1MF K 1608 68 C CHIP CERA C583A/B/C/L/R/W HCBK332KBA 50V X7R 3300PF K 1608
17 C ELECTRO C518 CEXF1E470E 25V RM 47MF (5X11) 69 C CHIP CERA C584L/R/W HCQK101JBA 50V CH 100PF J 1608
18 C CHIP CERA C518L/R HCBK104KBA 50V X7R 0.1MF K 1608 70 C CHIP CERA C585L/R HCQK330JBA 50V CH 33PF J 1608
19 C CHIP CERA C519 HCBK104KBA 50V X7R 0.1MF K 1608 71 C CHIP CERA C585W HCQK470JBA 50V CH 47PF J 1608
20 C ELECTRO C520 CEXF1E470E 25V RM 47MF (5X11) 72 C ELECTRO C586L/R/W CEXF1H100E 50V RM 10MF (5X11) TP
21 C CHIP CERA C521 HCBK104KBA 50V X7R 0.1MF K 1608 73 C CHIP CERA C587 HCQK681JBA 50V CH 680PF J 1608
22 C CHIP CERA C522~523 HCQK270JBA 50V CH 27PF J 1608 74 C ELECTRO C588 CEXF1H100E 50V RM 10MF (5X11) TP
23 C ELECTRO C525 CEXF1H100E 50V RM 10MF (5X11) TP 75 C CHIP CERA C589 HCQK681JBA 50V CH 680PF J 1608
24 C ELECTRO C526 CEXF1E470E 25V RM 47MF (5X11) 76 C ELECTRO C590 CEXF1H100E 50V RM 10MF (5X11) TP
25 C CHIP CERA C527 HCBK104KBA 50V X7R 0.1MF K 1608 77 C ELECTRO C591 CEXF1V470E 35V RM 47MF (5X11) TP
26 C ELECTRO C528 CEXF1E470E 25V RM 47MF (5X11) 78 C ELECTRO C592 CEXF1H109E 50V RM 1MF (5X11) TP
27 C CHIP CERA C529 HCBK104KBA 50V X7R 0.1MF K 1608 79 C ELECTRO C593L/R~594L/R CEXF1H479E 50V RM 4.7MF (5X11) TP
28 C CHIP CERA C530 HCFK224ZCA 50V Y5V 0.22MF Z 2012 80 C ELECTRO C595 CEXF1H109E 50V RM 1MF (5X11) TP
29 C ELECTRO C531 CEXF1H229E 50V RM 2.2MF (5X11) TP 81 C ELECTRO C596A/B/C/L/R/W CEXF1H479E 50V RM 4.7MF (5X11) TP
30 C ELECTRO C532 CEXF1E470E 25V RM 47MF (5X11) 82 C ELECTRO C597~598 CEXF1H479E 50V RM 4.7MF (5X11) TP
31 C CHIP CERA C533 HCBK104KBA 50V X7R 0.1MF K 1608 83 C CHIP CERA C599 HCBK822KBA 50V X7R 8200PF K 1608
32 C CHIP CERA C534 HCBK102KBA 50V X7R 1000PF K 1608 84 C ELECTRO C600 CEXF1H338E 5V RM 0.33MF (5X11) TP
33 C ELECTRO C535 CEXF1H109E 50V RM 1MF (5X11) TP 85 C CHIP CERA C601 HCBK153KBA 50V X7R 0.015MF K 1608
34 C ELECTRO C536 CEXF1H100E 50V RM 10MF (5X11) TP 86 C CHIP CERA C602~606 HCQK101JBA 50V CH 100PF J 1608
35 C CHIP CERA C537 HCBK104KBA 50V X7R 0.1MF K 1608 87 C ELECTRO C607 CEXF1H338E 5V RM 0.33MF (5X11) TP
36 C ELECTRO C538 CEXF1H100E 50V RM 10MF (5X11) TP 88 C CHIP CERA C608 HCBK153KBA 50V X7R 0.015MF K 1608
37 C CHIP CERA C539~540 HCBK104KBA 50V X7R 0.1MF K 1608 89 C ELECTRO C609~610 CEXF1H339E 50V RM 3.3MF (5X11) TP
38 C ELECTRO C541 CEXF1H229V 50V RSS 2.2MF (5X11) TP 90 C CHIP CERA C612 HCBK822KBA 50V X7R 8200PF K 1608
39 C CHIP CERA C542 HCBK104KBA 50V X7R 0.1MF K 1608 91 C ELECTRO C613 CEXF1H100E 50V RM 10MF (5X11) TP
40 C ELECTRO C543 CEXF1H100E 50V RM 10MF (5X11) TP 92 C ELECTRO C614 CEXF1H108E 50V RM 0.1MF (5X11) TP
41 C CHIP CERA C544 HCBK104KBA 50V X7R 0.1MF K 1608 93 C CHIP CERA C615~616 HCQK681JBA 50V CH 680PF J 1608
42 C ELECTRO C545 CEXF1E470E 25V RM 47MF (5X11) 94 C ELECTRO C617~618 CEXF1E101E 25V RM 100MF (6.3X11) TP
43 C ELECTRO C546L/R~547L/R CEXF1H100E 50V RM 10MF (5X11) TP 95 C CHIP CERA C619L/R HCQK101JBA 50V CH 100PF J 1608
44 C ELECTRO C547 CEXF1H109E 50V RM 1MF (5X11) TP 96 C CHIP CERA C621~624 HCQK681JBA 50V CH 680PF J 1608
45 C CHIP CERA C548~549 HCBK104KBA 50V X7R 0.1MF K 1608 97 C ELECTRO C625~626 CEXF1E101E 25V RM 100MF (6.3X11) TP
46 C CHIP CERA C548L/R HCQK101JBA 50V CH 100PF J 1608 98 C CHIP CERA C627~632 HCQK681JBA 50V CH 680PF J 1608
47 C CHIP CERA C549L/R~550L/R HCQK681JBA 50V CH 680PF J 1608 99 C CHIP CERA C633A/B/C/L/R/W HCQK101JBA 50V CH 100PF J 1608
48 C ELECTRO C550 CEXF1H109E 50V RM 1MF (5X11) TP 100 C ELECTRO C634A/B/L/R CEXF1H100E 50V RM 10MF (5X11) TP
49 C CHIP CERA C552 HCQK101JBA 50V CH 100PF J 1608 101 C ELECTRO C634C/W CEXF1H479E 50V RM 4.7MF (5X11) TP
LOCATION PART-CODE PART-DESC
REMARKS
PART-DESC
REMARKS
NO PART-NAMENO PART-NAME LOCATION PART-CODE
13. Electrical Parts List
Model : DV-115
LOCATION PART-CODE PART-DESC
REMARKS
PART-DESC
REMARKS
NO PART-NAMENO PART-NAME LOCATION PART-CODE
102 C CHIP CERA C635A/B/C/L/R/W HCQK681JBA 50V CH 680PF J 1608 154 R CHIP R504 HRFT750JBA 1/10 75 OHM J 1608
103 C CHIP CERA C636A/B/C/L/R/W HCQK820JBA 50V CH 82PF J 1608 155 R CHIP R505 HRFT101JBA 1/10 100 OHM J 1608
104 C ELECTRO C638W CEXF1H479E 50V RM 4.7MF (5X11) TP 156 R CHIP R506 HRFT222JBA 1/10 2.2K OHM J 1608
105 C ELECTRO C639A/B/C/L/R CEXF1H479E 50V RM 4.7MF (5X11) TP 157 R CHIP R507 HRFT103JBA 1/10 10K OHM J 1608
106 CONN WAFER CN501 9CD6264300 52045-1145 158 R CHIP R508 HRFT104JBA 1/10 100K OHM J 1608
107 CONN WAFER CN502 9728809000 2.0MM 35237-1101 11P 159 R CHIP R509~513 HRFT220JBA 1/10W 22 OHM J 1608
108 CONN WAFER CN503 9728809100 2.0MM 35237-1801 18P 160 R CHIP R514 HRFT105JBA 1/10 1M OHM J 1608
109 CONN WAFER CN504 9728811700 2.0MM PH-3A 3P 161 R CHIP R515 HRFT104JBA 1/10 100K OHM J 1608
110 CONN WAFER CN505 9728810900 2.0MM PH-5A 5P 162 R CHIP R516 HRFT220JBA 1/10W 22 OHM J 1608
111 DIODE SW CHIP D501~502 DZDS160--- KDS160 163 R CHIP R517 HRFT103JBA 1/10 10K OHM J 1608
112 DIODE SW CHIP D505~507 DZDS160--- KDS160 164 R CHIP R518 HRFT102JBA 1/10 1K OHM J 1608
113 DIODE SW CHIP D509 DZDS160--- KDS160 165 R CHIP R519~522 HRFT220JBA 1/10W 22 OHM J 1608
114 DIODE ZENER DZ501~502 DZTZ7R5B-- MTZ 7.5B 166 R CHIP R524 HRFT332JBA 1/10 3.3K OHM J 1608
115 IC IC501 1T0RX178B- T0RX178B (OPTICAL RX) 167 R CHIP R525 HRFT470JBA 1/10 47 OHM J 1608
116 IC IC502 1T0TX178A- T0TX178A (OPTICAL TX) 168 R CHIP R526~528 HRFT472JBA 1/10 4.7K OHM J 1608
117 IC IC503 174HCU04-- 74HCU04 (INVERTER) 169 R CHIP R529 HRFT103JBA 1/10 10K OHM J 1608
118 IC IC504 1AK4112A-- AK4112A (DIR) 170 R CHIP R531 HRFT472JBA 1/10 4.7K OHM J 1608
119 IC REGULATOR IC505 1AME1117BG AME1117BCGT (SOT-223) 171 R CHIP R532 HRFT103JBA 1/10 10K OHM J 1608
120 IC IC506 1CS49326-- CS49326 (DD DECODER) 172 R CHIP R533 HRFT122JBA 1/10 1.2K OHM J 1608
121 IC IC507 174HC244-- 74HC244 (BUS DRIVER) 173 R CHIP R534 HRFT332JBA 1/10 3.3K OHM J 1608
122 IC IC508 1CS4228A-- CS4228A (CODEC) 174 R CHIP R535 HRFT103JBA 1/10 10K OHM J 1608
123 IC REGULATOR IC509 1AME1117CC AME1117CCCT (TO-252) 175 R CHIP R536~537 HRFT220JBA 1/10W 22 OHM J 1608
124 IC IC510 1CS4341--- CS4341 (DAC) 176 R CHIP R538 HRFT103JBA 1/10 10K OHM J 1608
125 IC CHIP IC511~512 1NJM4558M- NJM4558M 177 R CHIP R539 HRFT470JBA 1/10 47 OHM J 1608
126 IC IC516~518 1NJM2068-- NJM2068 (OP AMP) 178 R CHIP R540 HRFT103JBA 1/10 10K OHM J 1608
127 IC CHIP IC519~520 1NJM4558M- NJM4558M 179 R CHIP R541 HRFT223JBA 1/10 22K OHM J 1608
128 IC IC521 1BU4052BCF BU4052 180 R CHIP R542L/R HRFT151JBA 1/10 150 OHM J 1608
129 IC CHIP IC523 1NJM4558M- NJM4558M 181 R CHIP R543L/R HRFT103JBA 1/10 10K OHM J 1608
130 IC IC524 1M62446FP- M62446FP 182 R CHIP R544L/R HRFT472JBA 1/10 4.7K OHM J 1608
131 IC CHIP IC525~527 1NJM4558M- NJM4558M 183 R CHIP R545L/R HRFT561JBA 1/10 560 OHM J 1608
132 JACK RCA JA501 9736324100 JK010055HN 184 R CHIP R546L/R HRFT472JBA 1/10 4.7K OHM J 1608
133 COIL CHIP L501~502 HLC479J03A 4.7UH CHIP 2012 185 R CHIP R548L/R HRFT102JBA 1/10 1K OHM J 1608
134 COIL CHIP L503 HLC229J02A 2.2UH CHIP 1608 186 R CHIP R549L/R HRFT104JBA 1/10 100K OHM J 1608
135 COIL CHIP L504 HLC104J01A BEAD 120 OHM 100MHZ 2012 187 R CHIP R550L/R HRFT102JBA 1/10 1K OHM J 1608
136 COIL CHIP L505 HLC479J03A 4.7UH CHIP 2012 188 R CHIP R555L/R HRFT473JBA 1/10 47K OHM J 1608
137 COIL CHIP L506~507 HLC104J01A BEAD 120 OHM 100MHZ 2012 189 R CHIP R556L/R HRFT472JBA 1/10 4.7K OHM J 1608
138 COIL CHIP L508L/R HLC104J01A BEAD 120 OHM 100MHZ 2012 190 R CHIP R557L/R HRFT471JBA 1/10 470 OHM J 1608
139 R CHIP L509L/R HRFT000-BA 1/10 0 OHM 1608 191 R CHIP R561 HRFT474JBA 1/10 470K OHM J 1608
140 COIL CHIP L510A/B/C/L/R/W HLC104J01A BEAD 120 OHM 100MHZ 2012 192 R CHIP R562 HRFT472JBA 1/10 4.7K OHM J 1608
141 COIL CHIP L511~512 HLC104J01A BEAD 120 OHM 100MHZ 2012 193 R CHIP R563A/B/C/L/R/W HRFT472JBA 1/10 4.7K OHM J 1608
142 TR CHIP Q502 TZRA102S-- KRA102S (10X10)PNP 194 R CHIP R564A/B/C/L/R/W HRFT472JBA 1/10 4.7K OHM J 1608
143 TR CHIP Q503L/R TZRC231S-- KRC231S 195 R CHIP R565A/B/C/L/R/W HRFT472JBA 1/10 4.7K OHM J 1608
144 TR CHIP Q505 TZRA102S-- KRA102S (10X10)PNP 196 R CHIP R566A/B/C/L/R/W HRFT472JBA 1/10 4.7K OHM J 1608
145 TR CHIP Q506 TZRC102S-- KRC102S 197 R CHIP R567A/B/C/L/R/W HRFT102JBA 1/10 1K OHM J 1608
146 TR CHIP Q507A/B/C/L/R/W TZRC231S-- KRC231S 198 R CHIP R568A/B/C/L/R/W HRFT104JBA 1/10 100K OHM J 1608
147 TR FET Q508L/R T2SK117--- 2SK117 199 R CHIP R569A/B/C/L/R/W HRFT102JBA 1/10 1K OHM J 1608
148 TR CHIP Q509 TZRA102S-- KRA102S (10X10)PNP 200 R CHIP R570L/R/W HRFT392JBA 1/10 3.9K OHM J 1608
149 TR CHIP Q510 TZRC102S-- KRC102S 201 R CHIP R571L/R HRFT472JBA 1/10 4.7K OHM J 1608
150 TR CHIP Q511 TZRA102S-- KRA102S (10X10)PNP 202 R CHIP R571W HRFT682JBA 1/10 6.8K OHM J 1608
151 TR CHIP Q512~513 TZRC231S-- KRC231S 203 R CHIP R572L/R~573L/R HRFT153JBA 1/10 15K OHM J 1608
152 R CHIP R501 HRFT472JBA 1/10 4.7K OHM J 1608 204 R CHIP R572W HRFT562JBA 1/10 5.6K OHM J 1608
153 R CHIP R503 HRFT221JBA 1/10 220 OHM J 1608 205 R CHIP R573W HRFT822JBA 1/10 8.2K OHM J 1608
