13. Electrical Parts List
Model : DV-115
LOCATION PART-CODE PART-DESC
REMARKS
PART-DESC
REMARKS
NO PART-NAMENO PART-NAME LOCATION PART-CODE
206 R CHIP R574L/R/W HRFT101JBA 1/10 100 OHM J 1608 9 C CHIP CERA C949 HCQK101JBA 50V CH 100PF J 1608
207 R CHIP R575~576 HRFT332JBA 1/10 3.3K OHM J 1608 10 C CHIP CERA C950 HCBK103KBA 50V X7R 0.01MF K 1608
208 R CHIP R577L/R HRFT622JBA 1/10 6.2K OHM J 1608 11 C ELECTRO C951 CEXP1H479V 50V REM 4.7MF 4*5
209 R CHIP R578 HRFT103JBA 1/10 10K OHM J 1608 12 C DOUBLE LAYER C952 CDXC0H479A 0.047F/5.5V 70UA 5RE
210 R CHIP R578L/R HRFT104JBA 1/10 100K OHM J 1608 13 C ELECTRO C953 CEXP1C470V 16V REM 47MF
211 R CHIP R579 HRFT222JBA 1/10 2.2K OHM J 1608 14 C CHIP CERA C954 HCBK103KBA 50V X7R 0.01MF K 1608
212 R CHIP R580L/R HRFT472JBA 1/10 4.7K OHM J 1608 15 C CHIP CERA C955 HCBK104KBA 50V X7R 0.1MF K 1608
213 R CHIP R581 HRFT473JBA 1/10 47K OHM J 1608 16 C CHIP CERA C957~959 HCQK101JBA 50V CH 100PF J 1608
214 R CHIP R582L/R HRFT104JBA 1/10 100K OHM J 1608 17 C CHIP CERA C960 HCBK473KBA 50V X7R 0.047MF K 1608
215 R CHIP R583L/R HRFT000-BA 1/10 0 OHM 1608 18 C ELECTRO C961 CEXP1H109V 50V REM 1MF 4*5
216 R CHIP R584L/R~585L/R HRFT472JBA 1/10 4.7K OHM J 1608 19 C CHIP CERA C962 HCBK104KBA 50V X7R 0.1MF K 1608
217 R CHIP R586L/R HRFT104JBA 1/10 100K OHM J 1608 20 C ELECTRO C963 CEXP1H109V 50V REM 1MF 4*5
218 R CHIP R587A/B/C/L/R/W HRFT000-BA 1/10 0 OHM 1608 21 C CHIP CERA C964 HCBK473KBA 50V X7R 0.047MF K 1608
219 R CHIP R588 HRFT104JBA 1/10 100K OHM J 1608 22 CONN AS CN901 9728811200 #26 P2.0 4P 160MM UL 1007
220 R METAL FILM R589 RN-4Z221J- 1/4W 220 OHM J 23 CONN AS CN903 9728809700 #26 P2.0 7P 140MM UL 1007
221 R CHIP R590 HRFT751JBA 1/10 750 OHM J 1608 24 CONN AS CN904 9728811300 #26 P2.0 6P 170MM UL 1007
222 R CHIP R591~593 HRFT101JBA 1/10 100 OHM J 1608 25 CONN AS CN906 9728811500 #26 P2.0 3P 100MM UL 1007
223 R CHIP R594 HRFT152JBA 1/10 1.5K OHM J 1608 26 CONN FFC CN911 9728809400 FFC 1.25X27X360MM K
224 R CHIP R595L/R HRFT101JBA 1/10 100 OHM J 1608 27 CONN FFC CN912 9728809300 FFC 1.25X11X230MM R
225 R CHIP R596A/B/C/L/R/W HRFT224JBA 1/10 220K OHM J 1608 28 CONN WAFER CP901 9CD6264000 52044-1145
226 R METAL FILM R597 RN-4Z221J- 1/4W 220 OHM J 29 CONN WAFER CP903 9CD6264200 52044-2745
227 R CHIP R598 HRFT103JBA 1/10 10K OHM J 1608 30 DIODE D902 DZN4148--- 1N4148 AUTO 52MM
228 R CHIP R598A/B/C/L/R/W HRFT104JBA 1/10 100K OHM J 1608 31 DIODE ZENER D903 DZTZ3R3B-- MTZ 3.3V B
229 R CHIP R599 HRFT102JBA 1/10 1K OHM J 1608 32 DIODE D904 DZN4148--- 1N4148 AUTO 52MM
230 R CHIP R599L/R HRFT104JBA 1/10 100K OHM J 1608 33 DIODE D905 DZN4007--- IN4007
231 R CHIP R600 HRFT474JBA 1/10 470K OHM J 1608 34 DIODE D906 DZN4148--- 1N4148 AUTO 52MM
232 R CHIP R601~602 HRFT332JBA 1/10 3.3K OHM J 1608 35 DIODE ZENER D908 DZTZ6R8B-- MTZ6.8B
233 R CHIP R601A/B/C/L/R/W HRFT101JBA 1/10 100 OHM J 1608 36 FL DISPLAY FL901
DHNA11MM37
NHA-11MM37
234 R CHIP R602A/B/C/L/R/W HRFT473JBA 1/10 47K OHM J 1608 37 IC MICOM IC904 1CXP82852- CXP82852-329Q
235 R CHIP R603A/B/C/L/R HRFT562JBA 1/10 5.6K OHM J 1608 38 IC RMC MODULE IC905 1TM97CT38- TM97CT38P
236 R CHIP R603W HRFT103JBA 1/10 10K OHM J 1608 39 R CHIP L901~903 HRFT000-BA 1/10 0 OHM 1608
237 R CHIP R604A/B/C/L/R HRFT392JBA 1/10 3.9K OHM J 1608 40 TR Q903 TZTC3875-- KTC3875
238 R CHIP R604W HRFT751JBA 1/10 750 OHM J 1608 41 TR CHIP Q904 TZRC102S-- KRC102S
239 R CHIP R605A/B/C/L/R/W HRFT104JBA 1/10 100K OHM J 1608 42 R CHIP R1~37 HRFT104JBA 1/10 100K OHM J 1608
240 R CHIP R606A/B/C/L/R/W HRFT102JBA 1/10 1K OHM J 1608 43 R CHIP R1001 HRFT103JBA 1/10 10K OHM J 1608
241 R CHIP R607 HRFT103JBA 1/10 10K OHM J 1608 44 R CHIP R1002 HRFT473JBA 1/10 47K OHM J 1608
242 R CHIP R608 HRFT223JBA 1/10 22K OHM J 1608 45 R CHIP R1003~1010 HRFT103JBA 1/10 10K OHM J 1608
243 R CHIP R608W HRFT102JBA 1/10 1K OHM J 1608 46 R CHIP R1011~1013 HRFT473JBA 1/10 47K OHM J 1608
244 R CHIP R609 HRFT122JBA 1/10 1.2K OHM J 1608 47 R CHIP R1014 HRFT101JBA 1/10 100 OHM J 1608
245 R CHIP R610 HRFT000-BA 1/10 0 OHM 1608 48 R CHIP R1015 HRFT472JBA 1/10 4.7K OHM J 1608
246 R CHIP R611 HRFT183JBA 1/10 18K OHM J 1608 49 R CHIP R926~928 HRFT473JBA 1/10 47K OHM J 1608
247 R CHIP R612~619 HRFT000-BA 1/10 0 OHM 1608 50 R CHIP R929 HRFT100JBA 1/10 10 OHM J 1608
248 R CHIP R620~627 HRFT103JBA 1/10 10K OHM J 1608 51 R CHIP R930 HRFT104JBA 1/10 100K OHM J 1608
249 X-TAL X501 5XE12R288J 12.288MHZ HC-49U 52 R CHIP R931~933 HRFT101JBA 1/10 100 OHM J 1608
1 PCB FRONT AS 15000 9CDC059300 DV-115 53 R CHIP R934~936 HRFT220JBA 1/10W 22 OHM J 1608
2 PCB FRONT B001 9CD6583500 242X329 54 R CHIP R937~940 HRFT101JBA 1/10 100 OHM J 1608
3 C CHIP CERA C932~933 HCBK103KBA 50V X7R 0.01MF K 1608 55 R CHIP R941~942 HRFT471JBA 1/10 470 OHM J 1608
4 C CHIP CERA C934~939 HCQK101JBA 50V CH 100PF J 1608 56 R CHIP R943 HRFT473JBA 1/10 47K OHM J 1608
5 C ELECTRO C940 CEXP1C470V 16V REM 47MF 57 R CHIP R944 HRFT471JBA 1/10 470 OHM J 1608
6 C CHIP CERA C941 HCBK473KBA 50V X7R 0.047MF K 1608 58 R CHIP R945~946 HRFT473JBA 1/10 47K OHM J 1608
7 C CHIP CERA C946~947 HCQK101JBA 50V CH 100PF J 1608 59 R CHIP R947~948 HRFT102JBA 1/10 1K OHM J 1608
8 C CHIP CERA C948 HCBK103KBA 50V X7R 0.01MF K 1608 60 R CHIP R949~950 HRFT472JBA 1/10 4.7K OHM J 1608
13. Electrical Parts List
Model : DV-115
LOCATION PART-CODE PART-DESC
REMARKS
PART-DESC
REMARKS
NO PART-NAMENO PART-NAME LOCATION PART-CODE
61 R CHIP R951 HRFT103JBA 1/10 10K OHM J 1608 12 C ELECTRO C718 CEXF1E472E 25V RM 4700MF (16X31.5)
62 R CHIP R952 HRFT224JBA 1/10 220K OHM J 1608 13 C ELECTRO C719 CEXF1E102E 25V RM 1000MF (10X20)
63 R CHIP R953 HRFT103JBA 1/10 10K OHM J 1608 14 C ELECTRO C720~721 CEXF1E471E 25V RM 470MF (10X12.5)
64 R CHIP R954 HRFT680JBA 1/10 68 OHM J 1608 15 C MYLAR C722~724 CMXM2A473J 100V 0.047MF J (TP)
65 R CHIP R955 HRFT271JBA 1/10 270 OHM J 1608 16 C ELECTRO C725 CEXF1C682E 16V RM 6800MF (16X35.5)
66 R CHIP R956~958 HRFT103JBA 1/10 10K OHM J 1608 17 C CERA C726 CCXF1H104Z 50V F 0.1MF Z
67 R CHIP R960 HRFT122JBA 1/10 1.2K OHM J 1608 18 C ELECTRO C727 CEXF1C471E 16V RM 470MF (8X11.5)
68 R CHIP R961~962 HRFT152JBA 1/10 1.5K OHM J 1608 19 C CERA C728 CCXF1H104Z 50V F 0.1MF Z
69 R CHIP R963~964 HRFT272JBA 1/10 2.7K OHM J 1608 20 C MYLAR C729~731 CMXM2A473J 100V 0.047MF J (TP)
70 R CHIP R965 HRFT472JBA 1/10 4.7K OHM J 1608 21 C ELECTRO C740 CEXF1H100E 50V RM 10MF (5X11) TP
71 R CHIP R968 HRFT122JBA 1/10 1.2K OHM J 1608 22 C MYLAR C741A/B/C/L/R CMXM2A104J 100V 0.1MF J (TP)
72 R CHIP R969~970 HRFT152JBA 1/10 1.5K OHM J 1608 23 C CERA C742A/B/C/L/R CCXF1H103Z 50V F 0.01MF Z (TAPPING)
73 R CHIP R971~972 HRFT272JBA 1/10 2.7K OHM J 1608 24 C ELECTRO C743 CEXF1H479E 50V RM 4.7MF (5X11) TP
74 R CHIP R973 HRFT472JBA 1/10 4.7K OHM J 1608 25 C ELECTRO C744 CEXF1H100E 50V RM 10MF (5X11) TP
75 R CHIP R974 HRFT822JBA 1/10 8.2K OHM J 1608 26 C ELECTRO C745 CEXF1E101E 25V RM 100MF (6.3X11) TP
76 R CHIP R975 HRFT101JBA 1/10 100 OHM J 1608 27 C CERA C746 CCXF1H473Z 50V F 0.047MF Z (TAPPING)
77 R CHIP R976 HRFT122JBA 1/10 1.2K OHM J 1608 28 C ELECTRO C747 CEXF1E101E 25V RM 100MF (6.3X11) TP
78 R CHIP R977~978 HRFT152JBA 1/10 1.5K OHM J 1608 29 C ELECTRO C751 CEXF1H108E 50V RM 0.1MF (5X11) TP
79 R CHIP R979~980 HRFT272JBA 1/10 2.7K OHM J 1608 30 C CERA C752A/B/C/L/R CCZB1H471K 50V B 470PF K
80 R CHIP R981 HRFT472JBA 1/10 4.7K OHM J 1608 31 C ELECTRO C753~754 CEXF1H108E 50V RM 0.1MF (5X11) TP
81 R CHIP R982 HRFT822JBA 1/10 8.2K OHM J 1608 32 C ELECTRO C755A CEXF1H229E 50V RM 2.2MF (5X11) TP
82 R CHIP R983 HRFT102JBA 1/10 1K OHM J 1608 33 C ELECTRO C755B/C/L/R CEXF1H229V 50V RSS 2.2MF (5X11) TP
83 R CHIP R984 HRFT000-BA 1/10 0 OHM 1608 34 C CERA C756A/B/C/L/R CCZB1H221K 50V B 220PF K
84 R CHIP R987 HRFT103JBA 1/10 10K OHM J 1608 35 C ELECTRO C757A/B/C/L/R CEXF1H330E 50V RM 33MF (5X11) TP
85 SW TACT SW901~906 5S50101001 KPT-1105A 1C-1P 36 C CERA C758A/B/C/L/R CZCH1H309K CH 50V 3PF K AXL 26MM
86 SW TACT SW908~924 5S50101001 KPT-1105A 1C-1P 37 C CERA C759A/B/C/L/R CCXF1H223Z 50V F 0.022MF Z (TAPPING)
87 VOL ENCODER VR904 5SH1624368 EC16B241040B 38 C CERA C760 CCXF1H223Z 50V F 0.022MF Z (TAPPING)
88 RESONATOR CERA X901
5PCST10MT
W
CST10.00MTW 39 C ELECTRO C761 CEXF1H100E 50V RM 10MF (5X11) TP
1 PCB H/P AS 17000 9CDC0593B0 DV-115 40 C CERA C762 CCXF1H223Z 50V F 0.022MF Z (TAPPING)
2 PCB H/P B001 9CD6583502 242X329 41 C ELECTRO C763 CEXF1H100E 50V RM 10MF (5X11) TP
3 C CHIP CERA C992 HCBK103KBA 50V X7R 0.01MF K 1608 42 C ELECTRO C764~765 CEXF1V101E 35V RM 100MF (6.3X11) TP
4 C CHIP CERA C993~994 HCBK102KBA 50V X7R 1000PF K 1608 43 C ELECTRO C766 CEXF1H100E 50V RM 10MF (5X11) TP
5 CONN WAFER CP902 9728808800 2.0MM PH-3AW 3P 44 C CERA C767 CCXF1H223Z 50V F 0.022MF Z (TAPPING)
6 CONN WAFER CP992 9728808900 2.0MM PH-7A 7P 45 C ELECTRO C768 CEXF1V101E 35V RM 100MF (6.3X11) TP
7 DIODE SW CHIP D911~912 DZDS160--- KDS160 46 C CERA C769 CCXF1H223Z 50V F 0.022MF Z (TAPPING)
8 JACK HEADPHONE PH991 9766319502 HTJ-064-05B GOLD 47 C ELECTRO C770 CEXF1H100E 50V RM 10MF (5X11) TP
1 PCB KEY SW AS 18000 9CDC0593C0 DV-115 48 C ELECTRO C771 CEXF1V101E 35V RM 100MF (6.3X11) TP
2 PCB KEY SW B001 9CD6583503 242X329 49 C CERA C772~773 CCXF1H103Z 50V F 0.01MF Z (TAPPING)
3 CONN WAFER CP906 9728808800 2.0MM PH-3AW 3P 50 C CERA C780L/R~785L/R CZCH1H101J CH 50V 100PF J AXL 52MM
4 LED D907 DLTL16KEE- LTL-16KEE(RED)PI3.1 51 C CERA C786~787 CCXF1H103Z 50V F 0.01MF Z (TAPPING)
5 SW TACT SW907 5S50101001 KPT-1105A 1C-1P 52 C CERA C790~791 CCXF1H104Z 50V F 0.1MF Z
1 PCB MAIN AS 10000 9CDC058900 DV-115 53 C ELECTRO C792~793 CEXF1H479E 50V RM 4.7MF (5X11) TP
2 PCB MAIN B001 9CD6583600 247X330 54 C ELECTRO C793L/R~794L/R CEXF1H100E 50V RM 10MF (5X11) TP
3 C ELECTRO C702 CEXF1E102E 25V RM 1000MF (10X20) 55 C ELECTRO C795 CEXF1C682E 16V RM 6800MF (16X35.5)
4 C CERA AC C703 CH1BFE472M 4.0KV 4700PF M SD AC250V 56 C CERA C795A/B/C/L/R CCZB1H222K
50V HIKB 2200PF K AXL 52M
5 C ELECTRO C705 CEXF1H100E 50V RM 10MF (5X11) TP 57 C CERA C796 CZCH1H101J CH 50V 100PF J AXL 52MM
6 C MYLAR C707 CMXM2E104J 250V 0.1MF J 58 CONN WAFER CN702 9CD6263900 52045-1745
7 C MYLAR C709~710 CMXM2E104J 250V 0.1MF J 59 CONN AS CN706 9728810400
#18 P3.96 3P 210MM UL1007
8 C ELECTRO C711~712 CEXF1V472E 35V RM 4700MF (18X35.5) 60 CONN AS CN993 9728809800 #22 P7.92 2P 460MM UL1617
9 C ELECTRO C713 CEXF1J331E 63V RM 330MF (6.3X11) 61 CONN WAFER CP502 9728807700 35336-1110 WAFER
10 C ELECTRO C714 CEXF1H109E 50V RM 1MF (5X11) TP 62 CONN WAFER CP503 9728807800 35336-1810 WAFER
11 C MYLAR C715~717 CMXM2A473J 100V 0.047MF J (TP) 63 CONN WAFER CP701 9728808100
GP390-03P-TS-M(W/O CENTER
