Daewoo DV - 115 - Page 15

13. Electrical Parts List
Model : DV-115
LOCATION PART-CODE PART-DESC
REMARKS
PART-DESC
REMARKS
NO PART-NAMENO PART-NAME LOCATION PART-CODE
64 CONN WAFER CP702 9728808200 VH-3A (W/O CENTER,RED) 116 TR Q704 TZTA1024Y- KTA1024Y (949Y)
65 CONN WAFER CP703 9728808300 VH-3A (W/O CENTER) 117 TR Q705 TKRC107M--
KRC107-M TAPPING(KSR1006)
66 CONN WAFER CP704 9728808500 VH-3A WAFER 118 TR Q706 TZTA1266Y- KTA1266Y- (AUTO)(1015Y)
67 CONN AS CP705 9728810500 #24 P2.0 8P 140MM UL 1007 119 TR Q707~709 TZTC3199Y- KTC-3199Y TAPING
68 CONN WAFER CP706 9728807900 5267-02A WAFER 120 TR Q710 TZTA1266Y- KTA1266Y- (AUTO)(1015Y)
69 CONN WAFER CP707 9728808000 5267-06A WAFER 121 TR Q711 TZTC3200GR
KTC3200GR (AUTO)(2240GR)
70 CONN WAFER CP708 9728808400 VH-2A WAFER 122 TR Q712 TKRA102M-- KRA 102-M (TAPPING)
71 CONN AS CP710 9728810200 #26 P2.0 6P 120MM UL 1007 123 TR Q713 TZTC102M-- KRC102M
72 CONN WAFER CP711 9728808700 2.0MM PH-8A 8P 124 TR Q717~720 TZRA102M-- KRA102M(KEC)
73 CONN WAFER CP903 9CD6263800 52045-2745 125 TR Q721~725 TZRC231M-- KRC231M(KEC)
74 DIODE D701 D1N4007--- IN4007 126 TR Q726 TZTC3200GR
KTC3200GR (AUTO)(2240GR)
75 DIODE ZENER D702 DZTZ3R3B-- MTZ 3.3V B 127 TR Q727 TZRC102M-- KRC102M(KEC)
76 DIODE D703~706 D1N4007--- IN4007 128 TR Q727A/B/C/L/R TZTC3199Y- KTC-3199Y TAPING
77 DIODE D707 DZN4148--- 1N4148 AUTO 52MM 129 TR Q730 TKRC107M--
KRC107-M TAPPING(KSR1006)
78 DIODE ZENER D708 DZTZ15B--- MTZ 15V B 130 R METAL FILM R701~702 RN-4Z109J- 1/4 1 OHM J
79 DIODE D709 DKBPC806-- KBPC806 131 R CARBON FILM R703 RD-AZ182J- 1/6 1.8K OHM J
80 DIODE D710 D1N4007--- IN4007 132 R CARBON FILM R705 RD-AZ221J- 1/6 220 OHM J
81 DIODE D711A/B/C/L/R DZN4148--- 1N4148 AUTO 52MM 133 R CARBON FILM R706 RD-AZ223J- 1/6 22K OHM J
82 DIODE ZENER D712 DZTZ12B--- MTZ 12V 26MM TAPPING 134 R METAL FILM R707 RN-4Z680J- 1/4 68 OHM J
83 DIODE ZENER D713 DZTZ22B--- MTZ 22V B 135 R CARBON FILM R708 RD-AZ102J- 1/6 1K OHM J
84 DIODE D714~717 D1N4007--- IN4007 136 R METAL FILM R709~710 RN-4Z109J- 1/4 1 OHM J
85 DIODE D718~719 DZN4148--- 1N4148 AUTO 52MM 137 R CARBON FILM R711 RD-AZ103J- 1/6 10K OHM J
86 DIODE D720~723 D1N4007--- IN4007 138 R METAL FILM R715~717 RN-4Z109J- 1/4 1 OHM J
87 DIODE D724 DKBPC806-- KBPC806 139 R CARBON FILM R718~719 RD-AZ103J- 1/6 10K OHM J
88 DIODE ZENER D725 DZTZ4R3B-- MTZ4.3B 140 R CARBON FILM R720~722 RD-AZ102J- 1/6 1K OHM J
89 DIODE D726~727 DZN4148--- 1N4148 AUTO 52MM 141 R METAL FILM R723A/B/C/L/R RN01B100JS 1W 10 OHM J SMALL
90 DIODE D729 DZN4148--- 1N4148 AUTO 52MM 142 R METAL FILM R724A/B/C/L/R RN01B100JS 1W 10 OHM J SMALL
91 DIODE ZENER D730 DZTZ5R6B-- UZ-5.6B 143 R CARBON FILM R726A/B/C/L/R RD-AZ223J- 1/6 22K OHM J
92 DIODE D731~741 DZN4148--- 1N4148 AUTO 52MM 144 R CARBON FILM R729 RD-AZ153J- 1/6 15K OHM J
93 DIODE D743~744 DZN4148--- 1N4148 AUTO 52MM 145 R METAL FILM R730 RN-4Z473J- 1/4 47K OHM J
94 DIODE ZENER D745 DZTZ9R1B-- TZ-9.1V 146 R CARBON FILM R731~732 RD-AZ473J- 1/6 47K OHM J
95 DIODE D746 DZN4148--- 1N4148 AUTO 52MM 147 R CARBON FILM R734 RD-4Z473J- 1/4 47K OHM J
96 FUSE GLASS TUBE F701 5FSGB1022L SEMKO TL 1A 250V MF51 148 R CARBON FILM R735 RD-AZ104J- 1/6 100K OHM J
97 FUSE GLASS TUBE F702 5FSGB2022L SEMKO TL 2A 250V MF51 149 R CARBON FILM R736 RD-4Z473J- 1/4 47K OHM J
98 FUSE GLASS TUBE F703 5FSGB4022L SEMKO TL 4A 250V MF51 150 R CARBON FILM R740 RD-AZ102J- 1/6 1K OHM J
99 HOLDER FUSE CLIP FC701~706 9734600800 PI5.2 - REEL 151 R CARBON FILM R742A/B/C/L/R RD-AZ102J- 1/6 1K OHM J
100 TERMINAL GND G701~702 9CD6450500 SNP 0.3T 152 R CARBON FILM R743 RD-AZ474J- 1/6 470K OHM J
101 IC REGULATOR IC701 1K1A7805AP K1A7805AP 153 R CARBON FILM R745 RD-AZ102J- 1/6 1K OHM J
102 IC PROTECTOR IC702 11CPN15--- ICP-N15 154 R CARBON FILM R747 RD-AZ474J- 1/6 470K OHM J
103 IC REGULATOR IC703 1K1A7812AP K1A7812AP 155 R CARBON FILM R750 RD-AZ102J- 1/6 1K OHM J
104 IC IC704 1K1A7912AP KIA7912AP (MOLD) 156 R CARBON FILM R751 RD-AZ474J- 1/6 470K OHM J
105 IC REGULATOR IC705 1K1A7805AP K1A7805AP 157 R CARBON FILM R754A/B/C/L/R RD-AZ182J- 1/6 1.8K OHM J
106 IC POWER IC709 1STK402250 STK 402-250 158 R CARBON FILM R755A/B/C/L/R RD-AZ563J- 1/6 56K OHM J
107 IC POWER IC710 1STK402050 STK 402-050 159 R CARBON FILM R756A/B/C/L/R RD-AZ563J- 1/6 56K OHM J
108 IC OP AMP IC711 1NJM4558D- NJM4558D 160 R CARBON FILM R757A/B/C/L/R RD-AZ202J- 1/6 2K OHM J
109 IC SWITCH IC712 1NJU7313AM
NJU7313AM (SW ARRAY SOP) 161 R CARBON FILM R758A/B/C/L/R RD-AZ202J- 1/6 2K OHM J
110
JACK SPK TERMINA
L
JA701 9736324300 P40420428P 162 R METAL FILM R759A/B/C/L/R RN01B228JS 1W 0.22 OHM J SMALL
111
JACK SPK TERMINA
L
JA702 9736324400 P40620702P 163 R METAL FILM R760~761 RN-4Z101J- 1/4 100 OHM J
112 AC OUTLET JA703 9736324500 A302D0061P 164 R CARBON FILM R762~763 RD-AZ103J- 1/6 10K OHM J
113 JACK RCA JA704~705 9736323600 JK0600460 165 R CARBON FILM R764 RD-AZ203J- 1/6 20K OHM J
114 COIL SPRING L723A/B/C/L/R 5L00000732 PI10X1.0X7T (R) CW 166 R METAL FILM R765 RN-4Z101J- 1/4 100 OHM J
115 TR Q702 TKRC107M--
KRC107-M TAPPING(KSR1006) 167 R CARBON FILM R766 RD-AZ203J- 1/6 20K OHM J
13. Electrical Parts List
Model : DV-115
LOCATION PART-CODE PART-DESC
REMARKS
PART-DESC
REMARKS
NO PART-NAMENO PART-NAME LOCATION PART-CODE
168 R METAL FILM R767 RN-4Z101J- 1/4 100 OHM J 38 DIODE SW CHIP D909~910 DZDS160--- KDS160
169 R CARBON FILM R772L/R~777L/R RD-AZ471J- 1/6 470 OHM J 39 IC CHIP IC901 1NJM4558M- NJM4558M
170 R CARBON FILM R778L/R~783L/R RD-AZ275J- 1/6 2.7M OHM J 40 IC IC902 1ES56033-- ES56033
171 R CARBON FILM R784L/R~785L/R RD-AZ104J- 1/6 100K OHM J 41 IC CHIP IC903 1NJM4558M- NJM4558M
172 R CARBON FILM R786L/R RD-AZ101J- 1/6 100 OHM J 42 JACK MIC JA901 9736324200 H20480060S
173 R CARBON FILM R788L/R RD-AZ101J- 1/6 100 OHM J 43 TR Q901 TZTC3200GR
KTC3200GR (AUTO)(2240GR)
174 R CARBON FILM R789L/R RD-AZ104J- 1/6 100K OHM J 44 TR CHIP Q905L/R TZRC231S-- KRC231S
175 R CARBON FILM R790~792 RD-AZ101J- 1/6 100 OHM J 45 TR CHIP Q906 TZRA102S-- KRA102S (10X10)PNP
176 R METAL FILM R793L/R RN01B331JS 1W 330 OHM J SMALL 46 TR CHIP Q907 TZRC104S-- KRC104S
177 R CARBON FILM R799 RD-AZ472J- 1/6 4.7K OHM J 47 R CHIP R901 HRFT561JBA 1/10 560 OHM J 1608
178 R CARBON FILM R799A/B/C/L/R RD-AZ333J- 1/6 33K OHM J 48 R CHIP R902 HRFT103JBA 1/10 10K OHM J 1608
179 SW RELAY RY701 5SC2001A01 SDT-S-105LMR 49 R CHIP R903 HRFT473JBA 1/10 47K OHM J 1608
180 SW RELAY RY702 5SC0201103 HR-CR323 2C-1P DC12V 50 R CHIP R904 HRFT561JBA 1/10 560 OHM J 1608
181 SW RELAY RY703 5SC0101370 SDT-S-112LMR 51 R CHIP R905 HRFT563JBA 1/10 56K OHM J 1608
182 TRANS POWER T701 5TP8028855 EI=28X12 8.5V 150MA 230V 52 R CHIP R906 HRFT392JBA 1/10 3.9K OHM J 1608
1 PCB MIC AS 16000 9CDC0593A0 DV-115 53 R CHIP R908 HRFT103JBA 1/10 10K OHM J 1608
2 PCB MIC B001 9CD6583501 242X329 54 R CHIP R909 HRFT123JBA 1/10 12K OHM J 1608
3 C ELECTRO C901 CEXF1H479E 50V RM 4.7MF (5X11) TP 55 R CHIP R910 HRFT103JBA 1/10 10K OHM J 1608
4 C CHIP CERA C902 HCQK101JBA 50V CH 100PF J 1608 56 R CHIP R911~912 HRFT153JBA 1/10 15K OHM J 1608
5 C ELECTRO C903 CEXF1H220E 50V RM 22MF (5X11) TP 57 R CHIP R913 HRFT123JBA 1/10 12K OHM J 1608
6 C CHIP CERA C904 HCQK221JBA 50V CH 220PF J 1608 58 R CHIP R914 HRFT103JBA 1/10 10K OHM J 1608
7 C ELECTRO C905 CEXF1H479E 50V RM 4.7MF (5X11) TP 59 R CHIP R915 HRFT153JBA 1/10 15K OHM J 1608
8 C CHIP CERA C906 HCBK102KBA 50V X7R 1000PF K 1608 60 R CHIP R916 HRFT562JBA 1/10 5.6K OHM J 1608
9 C ELECTRO C907 CEXF1H100E 50V RM 10MF (5X11) TP 61 R CHIP R917 HRFT123JBA 1/10 12K OHM J 1608
10 C CHIP CERA C908 HCBK472KBA 50V X7R 4700PF K 1608 62 R CHIP R919 HRFT183JBA 1/10 18K OHM J 1608
11 C ELECTRO C909 CEXF1H339E 50V RM 3.3MF (5X11) TP 63 R CHIP R920 HRFT221JBA 1/10 220 OHM J 1608
12 C CHIP CERA C910 HCQK561JBA 50V CH 560PF J 1608 64 R CARBON FILM R921 RD-4Z331J- 1/4 330 OHM J
13 C CHIP CERA C911 HCBK563KBA 50V X7R 0.056MF K 1608 65 R CHIP R922 HRFT000-BA 1/10 0 OHM 1608
14 C ELECTRO C912 CEXF1H100E 50V RM 10MF (5X11) TP 66 R CHIP R923L/R HRFT472JBA 1/10 4.7K OHM J 1608
15 C CHIP CERA C913 HCBK392KBA 50V X7R 3900PF K 1608 67 R CHIP R924L/R HRFT103JBA 1/10 10K OHM J 1608
16 C CHIP CERA C914 HCBK563KBA 50V X7R 0.056MF K 1608 68 R CHIP R925L/R HRFT472JBA 1/10 4.7K OHM J 1608
17 C CHIP CERA C915 HCQK561JBA 50V CH 560PF J 1608 69 R CHIP R966 HRFT104JBA 1/10 100K OHM J 1608
18 C CHIP CERA C916~917 HCBK472KBA 50V X7R 4700PF K 1608 70 R CHIP R983L/R HRFT104JBA 1/10 100K OHM J 1608
19 C ELECTRO C918 CEXF1H220E 50V RM 22MF (5X11) TP 71 R CHIP R984L/R HRFT223JBA 1/10 22K OHM J 1608
20 C CHIP CERA C919 HCQK221JBA 50V CH 220PF J 1608 72 R CHIP R985 HRFT102JBA 1/10 1K OHM J 1608
21 CLECTRO C920 CEXF1C221E RM 16V 220MF 6.3X11 TAT 73 R CHIP R986 HRFT474JBA 1/10 470K OHM J 1608
22 C CHIP CERA C921~923 HCBK104KBA 50V X7R 0.1MF K 1608 74 VR ROTARY VR901 5V1503727B RK09K1110303 50KB
23 C ELECTRO C924 CEXF1E101E 25V RM 100MF (6.3X11) TP 75 VR ROTARY VR903 5V1503727B RK09K1110303 50KB
24 C ELECTRO C925 CEXF1H100E 50V RM 10MF (5X11) TP 1 PCB MPEG AS 14000 9CDC059100 DV-115
25 CLECTRO C926 CEXF1C221E RM 16V 220MF 6.3X11 TAT 2 PCB MPEG B001 9CD6584000 91X147
26 C CHIP CERA C927 HCBK103KBA 50V X7R 0.01MF K 1608 3 COIL BEAD BD401~406 58C0000116 HC-3550R
27 CLECTRO C928 CEXF1C221E RM 16V 220MF 6.3X11 TAT 4 C CHIP CERA C401 HCBK104KBA 50V X7R 0.1MF K 1608
28 C CHIP CERA C929 HCBK103KBA 50V X7R 0.01MF K 1608 5 C CHIP CERA C402~403 HCQK220JBA 50V CH 22PF J 1608
29 C CHIP CERA C930L/R HCBK102KBA 50V X7R 1000PF K 1608 6 C CHIP CERA C404 HCBK104KBA 50V X7R 0.1MF K 1608
30 C ELECTRO C931L/R CEXF1H479E 50V RM 4.7MF (5X11) TP 7 C ELECTRO C405 CEXF1E101E 25V RM 100MF (6.3X11) TP
31 C ELECTRO C967 CEXF1H108E 50V RM 0.1MF (5X11) TP 8 C CHIP CERA C406~407 HCBK104KBA 50V X7R 0.1MF K 1608
32 C ELECTRO C968L/R CEXF1H100E 50V RM 10MF (5X11) TP 9 C ELECTRO C408 CEXF1H100E 50V RM 10MF (5X11) TP
33 C CHIP CERA C969 HCBK103KBA 50V X7R 0.01MF K 1608 10 C CHIP CERA C409 HCBK105KBA 50V X7R 1MF K 1608
34 CONN AS CN905 9728811400 P2.0 3P 270MM SHIELD 11 C CHIP CERA C410~412 HCBK104KBA 50V X7R 0.1MF K 1608
35 CONN WAFER CP904 9728808600 2.0MM PH-6AW 6P 12 C ELECTRO C413 CEXF1E101E 25V RM 100MF (6.3X11) TP
36 CONN AS CP907 9728809500 #26 P2.0 8P 180MM UL 1007 13 C CHIP CERA C414 HCBK104KBA 50V X7R 0.1MF K 1608
37 DIODE ZENER D901 DZTZ5R6B-- UZ-5.6B 14 C ELECTRO C415 CEXF1E101E 25V RM 100MF (6.3X11) TP
