CAUTION:
After installing, DO NOT REMOVE LEGS.
HOW TO FIX LEG TO BASE-HOLE FOR
INSTALLATION
• When you install this unit, be sure to
assemble LEGS(4EA) to base
under(Fig.4).
• Place this unit on its rear side on a
carton to prevent damage to the body.
• Insert the leg(4EA) into the base
under hole as it was. By first inserting
its two hooks.
• Turn right and screw on leg.
• Make the allows of leg and base
under face with each other at each
corner.
HOOK (2EA)
1. Inserting
2. Turn right
3. Screw on.
Figure 4.
