Daewoo DWA-120C User Manual

5
4.STRUCTURE AND PARTS NAME
1. EXTERNAL STRUCTURE AND PARTS NAME
• DWA-120CT/DWB-120CT/DWA-100CT
1. INSERT GRILLE
3. CABINET
9. BRADE
HORIZONTAL 2
10. DOOR VENTILATION
11. AUTO LOUVER SWITCH
2. FRAME GRILLE
6. THERMOSTAT KNOB
7. TIMER KNOB
8. SELECTOR KNOB
4. BLADE HORIZONTAL 1 5. BLADE VERTICAL
1. GRILLE FRONT
8. BLADE
HORIZONTAL 2
9. DOOR VENTILATION
10. AUTO LOUVER SWITCH
5. AIR FILTER
6.THERMOSTAT KNOB
7. SELECTOR KNOB
2. CABINET 3.BLADE HORIZONTAL 1 4.BLADE VERTICAL
• DWA-120C/DWB-120C/DWA-100C/DWB-090C
