8. HOW TO DISASSEMBLE
1 Before service of 1. Stop the unit, remove the power cord from the receptacles.
any part. 2. Move the unit to the safe location for the suitable work.
2 Ass’y Fan Motor 1. Remove Front Grill
- Fan Motor - Remove Filter Pre.
- Propeller Fan - Remove screw(1 point) in Front Grill.
- Blower Fan 2. Remove Cabinet from the unit.
- Remove screws (8 point) from the unit’s sides.
3. Remove Scroll upper.
4. Remove Plate Scroll
- Remove screws (3 point) from Plate Scroll’s sides.
5. Remove Ass’y Control Box
- Remove screws (3 point).
- Remove wires in the each components.
6. Remove wires in the Panel Housing.
7. Remove screws (7 point) from Ass’y Fan Motor’s sides.
- Ass’y Fan Motor is assembly of Fan Motor, Propeller and Blower Fan, Orifice
and Panel Housing.
8. Lift the Ass’y Fan Motor from the unit.
9. Remove hex-nut (2 point) from the shaft of Fan Motor.
10. Remove Propeller Fan from the shaft of Fan Motor.
11. Remove Blower Fan from the shaft of Fan Motor.
12. Remove Fan Motor from Panel Housing.
- Remove screws (4 point).
3 Ass’y Control Box 1. Same as the procedure 1 to 5 in the Item 2.
-
Rotary Switch (selector)
- Thermostat
- Capacitor
- Power Cord
4 O.L.P 1. Same as the procedure 1 to 2 in the Item 2.
2. Remove Terminal Cover from Compressor.
- Remove hex-nut (1 point).
Please refer to the chapter 11 (Exploded diagram and parts list).
