3
2. GENERAL SPECIFICATIONS
ITEM
MODEL
DWC-070C DWC-091C
Function Cooling only
Power source AC 115V, 60Hz, Single phase
Cooling Capacity
Btu/h 7,390 Btu/h 9,000 Btu/h
Kcal/h 1,862 Kcal/h 2,268 Kcal/h
Energy Efficiency Ratio
Btu/wh 10.0 Btu/wh 9,6 Btu/wh
Kcal/wh 2.52 Kcal/wh 2.42 Kcal/wh
Dehumidification Pts/h 2.36 Pts/h 3.04 Pts/h
Electrical Data
Power Input 739 W 938 W
Running Current 7.2A 9.6A
Compressor
Type Rotary
Model QB110CL12A QK141CN12A
Capacitor 35µF-370VAC 40µF-370VAC
Model A9525HS601-1 A9525HS602
Motor
Capacitor 4µF-370VAC 7µF-370VAC
Indoor-Fan Blower-Fan
Outdoor-Fan Propeller-Fan
Dimensions
Unit(W x H x D) 18.5(W) x 13.8(H) x 18.9(D) Inch (470(W )x 350(H) x 480(D) mm)
PACKING(W x H x D) 21.3(W) x 17.3(H) x 21.7(D) inch (540(W )x 440(H) x 550(D) mm)
Weight
Net Weight 63 lbs (28.5Kg) 65 lbs (29.5Kg)
Gross Weight 66 lbs (30.0 Kg) 68 lbs (31.0Kg)
