5. ELECTRoNIC fIELD pARTS LIST AND SpECIfICATIoN
No Part Name Part Code
classification
SPECIFICATIONS
Q'ty
1 SWITCH DOOR LOCK 3619047200 Common DL-S1.250V16A.BITRON 1
2 Valve Inlet 3615414820 Common 220-240V 1-WAY HOT PP-BRACKET 1
3 Valve Inlet 36154L3B00 New 220-240V.VDE.BITRON.3WAY V2:STEAM 1
4 Reactor AS 3615800100 Common DWD-800W RT--046B 1
5 Valve Inlet 36154L3A00 New 220-240V,4WAY,Steam&Dry 1
6 Unit Drain Pump AS
36189M2T00 New 40W,Circulation Pump (Pump 2EA + Bracket) 1
36189S1500
AC220V/60HZ HANYU,AL,30W,SINGLE
PUMP,FILTER NEW
36189S1600
AC220~240V/50HZHANYU,AL,30W,SINGLE
PUMP,FILTER NEW
36189S1700
AC220V/60HZ HANYU,AL,30W,DUAL
PUMP,FILTER NEW
36189S1800
AC120V/60HZ HANYU,CU,30W,DUAL
PUMP,FILTER NEW
36189S1900
AC120V/60HZ HANYU,CU,30W,SINGLE
PUMP,FILTER NEW
7 Sensor Pressure 3614825240 New
Inlet
1
8 EMI Filter 3611910900 New DFC-2710D 250V~ 10A 50/60HZ 1
9 Unit Steam AS 36189M2U00 New 230V 900W 1
10 Harness AS
3612799A00 New UNIVERSAL_COMBO FULL OPTION 1
3612799B00 DD_COMBO FULL OPTION
3612799C00 UNIVERSAL_WASH FULL OPTION
3612799D00 DD_WASH FULL OPTION
11 Heater Wash 3612803700 Common 230V 2000W.1R5A721002.IRCA FUSE 2EA 1
12 Thermistor Wash 361AAAAB10 Common R25=1.704K R80=11.981K 1
13 Unit Motor Universal 36189L4H10 Common DC220/50 G&J 2P PI340 45T(CCA) 1
14 Damper Friction 361A700110 Common 70N AKS ST=170-260 DL=197.5 LOW NOISE 4
15 Unit Bubble Pump AS 36189M2V00 New L=760 1
16 Unit Stator BLDC 36189L6200 New 28T 1
17 Unit Rotor BLDC 36189L6300 New 1
18 SWITCH THERMOSTAT 3619046500 Common ON120°C OFF150°C 230V 15A VDE 1
19 Heater Dry 3612801400 Common
230V 2.1KW 25.19OHM 6.1W/SQ
INCOLOY800 1R1A034002
1
20 FUSE TEMPERATURE 361A800120 Common 128°C DF-128S 15A 250V VDE 1
21 Thermistor Dry 361AAAAD00 New L=200 tube 1
22 CORD POWER AS 3611339950 Common H05VV-F 1.5SQ 250V 16A 1.6M EU-2PIN 6KG 1
23 Unit Fan Motor 36189M2Q00 New 24V DC 14W 1
