31
2. SWITCH DE PRESIÓN
PROBLEMA SITUACIÓN CAUSA REVISIÓN SOLUCIÓN
MODO DE
ERROR
SURTE
AGUA
"E9"
válvula de entrada
está bien, pero entra
agua continumente
frecuencia del nivel
de agua bajo de 15kHz
o arriba de 30kHz
problema del bellows
problema de manguera
manguera tapada
conector safado
switch presion dañado
conector en corto
cambie el
switch presión
cambie manguera
cambie manguera
quite obstrucción
reconecte
cambie el
switch presión
"E2"
"E2"
"E2"
"E2"
"E9"
"E9"
"E9"
revise frecuencia : ver referencia
revise frecuencia : ver referencia
revise fuga
revise la condición de manguera
revise condición del conector
revise frecuencia : ver referencia
conector dañado
Metodo de prueba de frecuencia, en conector.
* E2 : error sobre llenado; nivel de agua es mayor que nivel de desborde por que llena continuamente.
E9 : falla en el switch presion, la frecuencia es menor de 15kHz o mayor de 30kHz en el proceso.
TIERRA(GRIS)
SEÑAL ENTRADA(BLANCO)
SEÑAL SALIDA
(ROSA)
"12P" CONECTOR BLANCO
CONTINUA-
MENTE
abajo
abajo
cambie conector
ERROR
