38
1) SISTEMA DE SECADO
F
H
IA
B
C
D
E
G J
DIVISION PARTS NAME
A TAPA DUCTO
B MOTOR VENTILADOR
C CALEFACTOR SECADO
D DUCTO B
E VÁLVULA ENTRADA (SECADO)
F TERMOSTAT(Bie-metal)
G TERMISTOR
H DUCTO B
I ENSAMBLE VENTILADOR
J FUSIBLE TEMPERATURA
6. SISTEMA DE SECADO
