13
No. PARTS NAME PARTS CODE DESCRIPTION Q’TY REMARK
C01 CABINET F 3610811000 SECD, 0.8t 1
C02 PLATE HINGE SUPPORT 3614531500 SPG, 1.6t 1
C03 HINGE DOOR 3612902700 ALDC 1
C04 CAP HINGE DOOR 3610916500 POM 1
C05 SCREW TAPPING 3616030000 F/L BOLT(SE) 5x12 SUS 3
C06 SPRING DOOR 3615113800 D=1.0, N=7 1
C07 CLAMP DOOR 3611204200 HWSR3, D=1.4 1
C08 FLAME DOOR I 3611204700 PP 1
C09 STOPPER DOOR 3615202300 PP 3
C10 SCREW TAPPING 7122401608 T2S TRS 4x16 SUS 2
C11 SCREW TAPPING 7115402008 T1S FLT 4x20 SUS430 NATURAL 15
C12 DOOR GLASS 361A110600 GLASS(DWD-100DR) 1
C13 PROTECTOR GLASS 3618304201 ABS TRANSPATENT 1
C14 FRAME DOOR O 3612204600 ABS 1 CR
C15 COVER HANDLE 3611425620 ABS 1 CR
C16 SPRING HOOK 3615113700 SUS, ID=3, NI=7, D=ø0.9 2
C17 PIN HANDLE 3618200100 SUS, D=3.0, L=39 1
C18 HOCK DOOR 3613100700 Zn-DC 1
C19 HANDLE DOOR 3612608200 ABS 1
C20 SWITCH DOOR LOCK 3619046410 DF F11 110 125V 16A 1
3619046400 DF F01 007 220V 16A 1
To Next Page
