22
No. PARTS NAME CODE SPECIFICATIONS Q’TY
REMARK
G01 UNIT FAN MOTOR 36189L3Z20 ISM-7780 6DWWA 24V. 1
G02 COVER DUCT 3611428700 ALDC 1
G03 DUCT B UPPER 361A202100 ALCOST 0.5T 1
G04 CLAMP CORD 3611203330 DABE-2, A=9, B=5,3, L=105 3
G05 FAN AS 3611885900 DI33 FAN 1
G06 SCREW TAPPING 7122400811 T2S TRS 4x8 1
G07 SPECIAL SCREW AS 3616030100 TAPTITE P, TRS 4*16, WASHER 1
G08 FUSE TEMPERATURE 361A800120 128ᴱ(G4A0115C) 15A 250V 1
G09
FRAME HEATER FRANGE
3612209700 SBHG 1.2t 1
G10 DUCT B LOWER 361A202200 AL, 3t 1
G11
PACKING THERMOSTAT
3614009900 SILICON 1
G12 SWITCH THERMOSTAT 3619046500 ON 120ᴱOFF 150ᴱ230V 1
G13 HEATER DRY 3612801400 230V 2100W 1
3612802100 120V 1200W 1
3612801300 110V 1200W 1
G14 THERMISTOR DRY 361AAAAC30 R40=26.065ὶ, R90=4.4278ὶ 1
G15 PACKING RUBBER 3614009800 SILICON 1
G16 CUSHION DRY 3611570500 NBR, 20 x20 x 3T 2
G17 GASKET SEAL A 3612324200 EPDM FOAM, DIA=5, L=1335 1
G18 GASKET SEAL B 3612320810 EPDM FOAM, L=412, 4.9 x 4.4 x 4.8 1
G19 GASKET INLET 3612323800 EVA, 10 x 211 x 1T 1
G20 DUCT GUIDE 361A202300 AL, 3T 1
G21 DUCT AS 361A200850 T120R 1
G22 CLAMP AS(DUCT) 3611203700 DUCT 2
G23 BELLOWS DUCT 3616403000 EPDM 1
G24 H0SE WATER SUPPLY 3613270900 T120R 1
G25 CLAMP SPRING 3611203800 ID=15.5, T=0.6, B=10 2
