Daewoo DWD-FD1022 - 4 Direction for Disassembly

11
DIRECTION FOR DISASSABLY
DOOR LOCK SWITCH
1) Open the door and remove the gaske clamp. 2) Remove the gasket from the front cabinet.
HEATER AND THERMISTOR
1) Remove five screws on the COVER B and separate
the COVER B from washing machine.
2) Remove the connectors of the HEATER.
3) Remove two screws, and remove the door lock
switch.
4. DIRECTION FOR DISASSEMBLY
