EXPLODE VIEW AND PARTS LIST
No. PART NAME PART CODE SPECIFICATION Q'TY REMARK
D01 BALANCER WEIGHT F L/R 3616106320 FRONT, 5.5kg 2
D02
SPECIAL SCREW(BALANCER)
3616029400 SWCH 8.5X30 8
D03 GASKET 3612321400 EPDM 1
D04 CLAMP GASKET AS 3611204500 HSWR D=1.8 1
D05 TUB FRONT 3618821010 FRPP FH7304GM 1
D06 SPECIAL SCREW(TUB) 3616029800 SWCH 6.5X30 14
D07 FIXTURE HEATER 3612007300 SUS 0.7T 440°ø45 1
D08 DRUM SUB AS 3617004001 SUS 0.5T 1
D09 LIFTER WASH
361A400400 PP
3
361A400410 NANO OPTION
D10 SPIDER AS 361A300500 ALDC+SM45C 1
D11 SPECIAL SCREW(SPIDER) 3616029500 SUS430 8x25 3
D12 HOSE DRAIN 3613267300 EPDM 1
D13 CLAMP AS 3611203200 ID=60,WIRE+GUIDE+BOLT+NUT 1
D14 CLAMP HOSE I 3611201400 HSW3, D2.6, MFZN, D=38 1
D15 AIR TRAP 361A500101 PP 1
D16 CLAMP HOSE 3611204700 D27 1
D17 HOSE AIR 3613268600 ID=4, OD=8, L=700 1
D18 TUB REAR 3618821110 FRPP FH7304GM 1
D19 BEARING OUTER 3616303200 6205Z FAG 1
D20 BEARING HOUSING 3616303300 ALDC 1
D21 BEARING INNER 3616303100 6206Z FAG 1
D22 WATER SEAL 361A600100 NBR 1
D23 GASKET TUB 3612321600 EPDM L=1675 1
D24 DAMPER FRICTION 361A700120 120N, AKS, ST=170-160, DL=197.5 2
D25 DAMPER PIN 361A700200 AKS, D=14.5 2
D26 HOSE VENT 3613267100 EPDM 1
D27 CLAMP HOSE 3611204700 D27 1
D28 UNIT STATOR BLDC 36189L4820 AL-16T 36SLOT 2SNESOR 1
D29 SPECIAL BOLT AS 3616029920 SWCH M8+SILOCK, 35MM 6
D30 UNIT ROTOR BLDC 36189L4910 MAGENT24 SERRATION 1
D31 SPECIAL BOLT AS 3616029600 SWCH M10xL30, F/L BOLT 1
D32 HEATER WASH 3612802440 120V 1KW.1R0A721005.RW8TF1PE.IRCA 1
D33 UNIT BUBBLE PUMP 36189L4G10 100-130 DBK-115DB RP-CUSH 1 OPTION
D34 SPRING SUSPENSION 3615115300 D3.2, L164 2
