Specifications and Wiring Diagram
| 30 |
Product specifications are subject to change without prior notice for the improvement of product quality.
Model Wall-Mounted Front Load Washer
Dimensions 550(W) X 600(H) X 292(D)
Weight 16.5Kg
Power 220~240V / 50Hz
Max. Laundry Load 2Kg
Operating Water Pressure 98.1kPa~784kPa(1kgf/cm2~8kgf/cm2)
Wiring Diagram
