67 68
NO. PARTS CODE PARTS NAME DESCRIPTION Q’TY REMARK
C28 7122502011 SCREW TAPPING T2S TRS 5X20 MFZN 2
C29 4509M10032 FIXTURE PP 2
C30 3617700400 LEG FIX RUBBER BUTYL 2
C31 7112401411 SCREW TAPPING T1 TRS 4X14 MFZN 13
C32 7122401211 SCREW TAPPING T2S TRS 4X12 MFZN 6
C33 3610904100 CAP LEG ABS, AL COATING 2
C34 3618900700 UNIT LEG RUBBER+BOLT 2
C35 3612000200 FIXTURE LEG PPG 2
C36 3613000600 HOLDER LEG ABS 2
C37 3610303600 BASE U PP 1
C38 3610800700 CABINET PCM 0.7T 1
C39 3611604820 DECORATOR AS AL COATING LABEL 1
3613501800 LABEL POWER UV COATING 1 OPTION
C40 3612200200 FRAM,E T PP 1
C41 7112401411 SCREW TAPPING T1 TRS 4X14 MFZN 19
T01 3610085500 ASSY FILTER PP(NYLON 74X130) 1
T02 3612501800 GUIDE FILTER AS DWF-1080R2 1
T03 3616004700 SPECIAL SCREW T2S TRS 4X8 SUS, 2-LINE 2
T04 7122401208 SCREW TAPPING T2S TRS 4X12 SUS 2
T05 3610900700 CAP PULSATOR PP 1
T06 4505E3203A SC PULSATOR FIX AS 6X26.5, O-RING+SILOCK 1
T07 3619701400 PULSATOR PP 1
T08 4509G3221 INSERT PULSATOR SMS 1025 1
T09 4509G83080 SPECIAL SPIN NUT ZNC2 CU, NI COATING 1
T10 4509L83070 SPECIAL WASHER SUS304, T2.0, P144 1
T11 3616101500 BALANCER AS DWF-1080R2 1
T12 3616003700 SPECIAL SCREW 5.5X16 SUS 24
T13 3618801600 TUB YUS430D 1
T14 3618801910 TUB U FRPP 1
T15 3617200200 FLANGE TUB ADC-10 1
T16 4505E83100 SPECIAL BOLT BASE 6.5X23 12
T17 7122401611 SCREW TAPPING T2S TRS 4X16 MFZN 4
T18 4500D83100 NOZZLE AS BUBBLING 1
T19 4509M83030 COVER TUB *O PP(J-360) 1
T20 4509M83013 TUB *O PP 1
T21 4509M25020 PIN SUSPENSION HSW3 4
T22 3615300300 SUPPORTER UPPER NYLON6(1021ST) 4
T23 4509M25031 ROD SUSPENSION SWRCH 4
T24 2610900100 CAP NYLON 4
T25 3615100800 SPRING SUSPENSION SWA L=100mm YELLOW 2 RIGHT
3615100900 SPRING SUSPENSION SWA L=100mm WHITE 2 LEFT
NO. PARTS CODE PARTS NAME DESCRIPTION Q’TY REMARK
C01 3614508300 PLATE UPPER PP 1
C02 7122401265 SCREW TAPPING T2S TRS 4X12 BSNI 6
C03 3611402800 COVER BACK PP 1
C04 712401011 SCREW TAPPING T1 TRS 4X10 MFZN 1
C05 3614509600 PLATE LOWER PP 1
C06 7122401265 SCREW TAPPING T2S TRS 4X12 BSNI 4
C07 3611301200 CORD POWER AS 3X1.25SQX2.3 125V/15A 1 PT/PS/PA
3611301800 T2S TRS 4X16 MFCR 1
C08 7122401613 SCREW TAPPING T2S TRS 4X16 MFCR 1
C09 3610032630 ASSY CONDENSER 400VAC(13.5µ+60µH) 1 PN
3610045630 400VAC(11.4µ+60µH) 1 PM
36100B2100 400VAC(15.0µ+60µH) 1 PL
3610076130 200VAC(54.0µ+60µH) 1 PT
3610076230 200VAC(41.6µ+60µH) 1 PS
3618904120 200VAC(45.6µ+60µH) 1 PA
C10 3612600700 HANDLE CABINET PE-HD 2
C11 4505A63030 C.E.C. SMALL ST CE-230 2
C12 5FKGD1032S FUSE GLASS TUBE AC 250V/10A 1 PN/PM/PL
5FKGD1832S AC 250V/18A 1 PT/PS/PA
C13 3618905100 UNIT FUSE FILTER 471D-14A 1 PN/PM/PL
3618905110 471D-14A 1 PT/PS/PA
C14 3612502300 GUIDE DRAIN HOSE PP (JI-360) 1
C15 3613203101 HOSE AS DWF-5230PN 1
C16 3611200200 CLAMP B SW 2.6D ZN8-C 1
C17 5F3GB1022S FUSE GLASS TUBE 250V 1A T/L 51T V/S 1 PN/PM/PL
5F1GB3121S 125V 3.15A T/L 51SB U/C 1 PT/PS/PA
C18 3611405300 COVER PUMP HFH-400, FRPS(466FWU) 1
C19 4505E05050 SPECIAL SCREW 5.2X18 3
C20 7341601611 SPECIAL BOLT 6B-1-6X16 MFZN 4
C21 3963513430
MOTOR SHADED POLE
AC 220~240V/50Hz 1 PN/PM
3963220330 AC 110V/60Hz 1 PT
3963322730 AC 220V/60Hz 1 PL
3963821530 AC 120V/60Hz 1 PS/PA
C22 3611109700 CASE FILTER FRPP 1
C23 3610903800 CAP FILTER PP(J-150, H350F) 1
C24 3616004300 SPECIAL WASHER PC FILM T0.5 1
C25 3614002000 PACKING NBR 1
C26 3611901800 FILTER LINT PP(J-150, H350F) 1
C27 7122401211 SCREW TAPPING T2S TRS 4X12 MFZN 2
PARTS LIST (DWF-1095Px MODEL)
