Service Manual
Programmable Washing Machine
DWF-1095xE
DWF-1095Px
Series
DAEWOO ELECTRONICS CO., LTD.
NO. PARTS CODE PARTS NAME DESCRIPTION Q’TY REMARK
T26 4507E76000 CAP SUSPENSION 4
T27 3613205400 HOSE OVERFLOW E526F 1
T28 36171005410 ELBOW DRAIN PP(J-150, H350F) 1
T29 4508E83120 SCREW BASE FIX SM 5X13 6
T30 4500D08180 CLAMP SWC 1
T31 4500D08170 HOSE ID=0.8, OD=12.0 1
T32 3611502101 CUSHION DOWN POM(H=13mm) 2
T33 3964821000 MOTOR CONDENSER AC 240V/50Hz 1 PN/PM
3964820800 AC 110V/60Hz 1 PT
3964820900 AC 120V/60Hz 1 PS/PA
3964320800 AC 220V/60Hz 1 PL
T34 7650804211 BOLT HEX 6B-1 8X42 S.P/W MFZN 4
T35 3611201000 CLAMP SW, D2.6, MFZN 2
T36 3613209510 HOSE DRAIN I LDPE+EVA, L=168mm 1
T37 3618401300 PULLEY MOTOR ADC-12, DP=60.5, 50Hz 1 PN/PM
3618400700 ADC-12, DP=52.5, 60HZ 1
PT/PS/PL/PA
T38 3616000701
SPECIAL BOLT-PULLEY
6B-1-6X20 SM20CK(ZN) 1
T39 7393600011 NUT HEX 6N-3-6 MFZN 1
T40 4507D34020 BELT V M20 1 PN/PM
4507B34020 M19.5 1
PT/PS/PL/PA
T41 7341601611 SPECIAL BOLT 6B-1-6X16 MFZN 4
T42 3618300100
PLATE GEAR PROTECT
SBHG1 1.6T 1
T43 7640801611 BOLT HEX 6B-1 8X16 SW MFZN 4
T44 3617301000 GEAR MECHANISM, GM-6685, NTN 1
T45 4505E34091 SPACER GEAR SUS304 1
T46 7650802511 BOLT HEX 6B-1 8X25 HS MFZN 2
T47 7401008011 WASHER SPRING SW-8 MFZN 2
T48 7400108011 WASHER PLANE PW-1-8 MFZN 2
T49 3616100600
BALANCER WEIGHT
FC-20, 3550GR 1
T50 3617801000 LINK BRAKE POM (F20) 1
T51 4505E83100 SPECIAL BOLT BASE 6.5X23 3
T52 3966010140
MOTOR SYNCRONOUS
AC 220~240V/50Hz 1 PN/PM
450ED45040 AC 110~120V/60Hz 1 PT/PS/PA
3966320230 AC 220V/60Hz 1 PL
T53 4509M34010 BASE SBHG 2.0T 1
T54 4500D08170 HOSE ID=0.8, OD=12.0, L=195 1
T55 4500D08180 CLAMP SWC 1
T56 7122401211 SCREW TAPPING T2S TRS 4X12 MFZN 2
T57 DTPMK51FD1
SENSOR THERMISTOR
PTM-K51F-D1 L=470mm 1
To Next Page
