2. STRUCTURE OF THE WASHING MACHINE
3
STRUCTURE
• HOSE DRAIN
• POWER CORD
• LINT FILTER(2EA)
• HOT WATER TAP
• COLD WATER TAP
After using the washer,
close the water tap, In case
of the single valve model,
there is no hot water valve.
After using the washer,
close the water tap
In case of 3-wire power cord
ground wire will not be provided
• CASE DETERGENT
AND SOFTENER
• BLEACH INLET
• ADJUSTABLE LEG
• PULSATOR
• CONTROL PANEL
• GROUND WIRE(OPTION)
RINSE
1
1
3
5
7
9
6
2
3
4
10
14
18
SPIN
ECO.
HEAVY
FUZZY
NIGHT
WOOL
SOAK
BLANKET
FEED
DRYTEN [OPTION]
HOSE DRAIN [FOR PUMP]
COVER UNDER [OPTION]
HOSE DRAIN CLAMP
WATER TAP ADAPTER
HOSE DRAIN[FOR NONPUMP]
INLET HOSE
CONNECTOR INLET [OPTION]
Accessories
UP
The parts and features of your washer are illustrated on this page.
Become familiar with all parts and features before using your washer.
NOTE
• The drawing in this book may vary from your washer model. They are designed to show the different fea-
tures of all models covered by this book, Your model may not include all features.
