PARTS DIAGRAM
■
Parts List
NO. PARTS CODE PARTS NAME DESCRIPTION Q'TY REMARK
A01 3619044110 SWITCH SAFETY DWF-1098 CUSH=18MM 1
A02 5EP1048050 TRANS POWER T11-V2F 1 INVERTOR
A03 3614801600 SENSOR PRESSURE 90•Ï•Ï,CDN-D7N,CUS-D7 1
A04 3614232101 PANEL REAR ABS 1
3614232160 ABS, UV_BASE UV COATING
A05 3610017100 RADICAL GENERATOR 220/60, DRG-220 1
3610019800 110/60, DRG-110
3610018400 220/50, DRG-230
A06 3616007400 SPECIAL SCREW T2S TRS 4X10+24 2 FOR RADICAL
A07 3615407100 VALVE INLET AS AC 220V/60HZ, C&H&R 1
3615407110 AC 100V/50,60HZ, C&H&R
3615407120 AC 110V/60HZ, C&H&R
3615407130 AC 220V/50HZ, C&H&R
3615407140 AC 100V/50,60HZ, C&R
3615407150 AC 110V/60HZ, C&R
3615407160 AC 220V/60HZ, C&R
3615407170 AC 220V/50HZ, C&R
A08 3612902400 HINGE DOOR POLYACETAL 1
A09 3618911400 UNIT CAPACITOR 13.5•ÏF, 400VAC, AL-CAN 1 220/230V
3618912400 54•ÏF, 400VAC, AL-CAN 110V
3618911200 11.4•ÏF, 400VAC, AL-CAN 240V
3618911800 41.6•ÏF, 230VAC, CAN TYPE 127V
A10 3614519900 PLATE T PP, COLD&HOT&RINSE 1 DOUBLE VALVE
3614519910 PP, COLD&RINSE SINGLE VALVE
A11 3618102300 NOZZLE DETERGENT PP 1
A12 3611121200 CASE DETERGENT ABS, RINSE 1
A13 3610911400 CAP SOFTENER PP 1
A14 3617504000 INLET BLEACH CONN. PP 1
A15 3610909900 SCREW TAPPING T1S TRS 5X30 MFZN 2 FOR PLATE T
A16 3614231900 PANEL SIDE L ABS 1
3614231930 ABS, UV_BASE UV COATING
A17 3614232000 PANEL SIDE R ABS 1
3614232030 ABS, UV_BASE UV COATING
A18 52G043J000 REACTOR 4.2MH, 3.7A 1
A19 3614233010 PANEL F 100M'S INMOLD 1
3614233060 100M'S UV+INMOLD UV COATING
A20 PRPSSWZ300 PCB AS 2WAY 1 DOUBLE VALVE
PRPSSW1G00 1WAY SINGLE VALVE
PRPSSW1H00 PUMP PUMP
PRPSSW1A00 PCB AS(MAIN) DWF-100MV(MAIN) INVERTER
A21 PRPSSW1B00 PCB AS(SUB) DWF-100MV(SUB) 1 INVERTER
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
