PARTS DIAGRAM
NO. PARTS CODE PARTS NAME DESCRIPTION Q'TY REMARK
A22 3611796700 DOOR B ABS 1
3611796720 ABS, TRANSPARENCY
3611796740 ABS, UV_BASE UV COATING
A23 3615111200 SPRING DOOR SUS 304 1
A24 3612604600 CAP DOOR ABS 1
A25 3611796600 DOOR F ABS 1
3611796620 ABS, TRANSPARENCY
3611796640 ABS, UV_BASE UV COATING
A26 3612604500 HANDLE DOOR PP 1
A27 3611305100 POWER CORD 3X0.75 2.3M 1 KOREA
3611305500 A-VCTFK 2X0.75 2.3M GY TAIWAN
3611304610 N LFC-2R 3X0.75 2.3M GY AUSTRALIA
3611336650 F H05W 3X0.75 2.3M WH CHILE
3611304810 RW-300/500 3X0.75 2.3M CHINA
3611304910 VCTF 3X0.75 2.3M INDIA
3611305310 H05W-F 3X0.75 2.3M WH MALAYSIA
3611305410 H05W-F 3X0.75 2.3M BK SINGAPORE
3611305810 H05W-F 3X0.75 2.3M GY SOUTH AFRIACA
3611305610 F H05W 3X0.75 2.3M BK USSR
3611306030 H05W-F 3X0.75 2.3M GY ARGENTINA
3611302900 3X0.75 300X2 L=1800 KOREA(INVERTER)
A28 3618957000 UNIT FUSE FILTER AC250V/8A 1 INVERTER
A29 3612760800 HARNESS AS 220/240V 50/60HZ 2-WAY 1 DOUBLE VALVE
3612760810 100/127V 50/60HZ 2-WAY
3612760820 220V/240V 50/60HZ 1-WAY SINGLE VALVE
3612760830 100/127V 50/60HZ 1-WAY
3612760840 220V/240V 50/60HZ PUMP PUMP
3612760850 100/127V 50/60HZ PUMP
3612760900 DWF-101MI, INVERTER 1 INVERTER
B01 3613220210 HOSE DRAIN O AS LDPE, L=1250MM 1 NON-PUMP
3613217800 HOSE DRAIN O PE-LD PUMP
B02 3614514600 PLATE UPPER PP 1
B03 7112501411 SCREW TAPPING T1 TRS 5X14 MFZN 8
B04 3615302210 SUPPORTER TUB BL SPG 1.4T 1
B05 3615302310 SUPPORTER TUB BR SPG 1.4T 1
B06 3615302410 SUPPORTER TUB FR SPG 1.4T 1
B07 3615302510 SUPPORTER TUB FL SPG 1.4T 1
B08 3611413600 COVER BACK SPG 0.5T 1
B09 3618919900 CABINET PCM ∂«¥¬ PAINTING 1
B10 4509D10020 FOOT BUTYL RUBBER 2
B11 3610310200 BASE U PP 1
3610312200 PP(1398)
B12 3617702100 LEG ADJUST SBR, PP 2
B13 3611403710 COVER UNDER PP 1
B14 3611405320 COVER PUMP PP(B360F) 1
3611405301 UL/CSZ(466FWU,HFH-400)
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
